58UVB
DEDICATED UPFLOW CONDENSING
GAS FURNACE
Owner's Information Manual
NOTE TO INSTALLER:
THIS MANUAL MUST BE LEFT WITH THE EQUIPMENT
USER.
USER: Please read all instructions in the manual and retain all
manuals for future reference.
WARNING
!
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in
injury, death, or property damage.
Do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
- -Do not try to light any appliance.
- -Do not touch any electrical switch; do not use any
phone in your building.
- -Leave the building immediately.
- -Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
- -If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas supplier.
WARNING
!
CARBON MONOXIDE POISONING HAZARD
Failure to follow this warning could result in personal
injury and/or death.
Carbon Monoxide is invisible, odorless, and toxic!
Carrier Corporation recommends a carbon monoxide
alarm in your home, even if you do not own a gas
appliance. Locate the carbon monoxide alarm in the
living area of your home and away from gas appliances
and doorways to attached garages. Follow the alarm
manufacturer's instruction included with the alarm.
As an ENERGY STAR® Partner,
Carrier Corporation has deter-
mined that this product meets
the ENERGY STAR® guidelines
for energy efficiency.
Do not use this furnace if any part has been under water.
A flood- -damaged furnace is extremely dangerous.
Attempts to use the furnace can result in fire or
explosion. A qualified service agency should be
contacted to inspect the furnace and to replace all gas
controls, control system parts, electrical parts that have
been wet or the furnace if deemed necessary.
1
CERTIFIED
A05097

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 58UVB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carrier 58UVB

Summary of Contents for Carrier 58UVB

  • Page 1 ENERGY STAR® guidelines for energy efficiency. Do not use this furnace if any part has been under water. A flood- -damaged furnace is extremely dangerous. Attempts to use the furnace can result in fire or explosion.

  • Page 2: Table Of Contents

    ......WELCOME TO A NEW GENERATION OF COMFORT Congratulations! In light of rising energy costs, the 58UVB WeatherMaker Infinity,...

  • Page 3: Furnace Components

    18. Junction box for 115- -v electrical power supply. (May be located on right or left side) 19. Transformer (24v) behind furnace control board provides low- -voltage power to furnace control board and thermostat. Collects moisture Fig. 2 - - Model 58UVB Furnace (Upflow Only) A02264...

  • Page 4: Safety Considerations

    Recognize safety information. This is the safety- -alert symbol . When you see this symbol on the furnace and in instructions or manuals, be alert to the potential for personal injury. Understand the signal words: DANGER, WARNING, and CAUTION. DANGER identifies the most serious hazards which will result in severe personal injury or death.

  • Page 5: Starting And Shutting Down Your Furnace

    Wait 5 minutes to clear out any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety information above on this furnace label. If you don’t smell gas, go to the next step. If a suspected malfunction occurs with your gas control...
  • Page 6 Fig. 14 - - Control Switch to ON 7. Replace main furnace door. (See Fig. 15.) A05099 8. Turn ON the electrical supply to the furnace and wait 1 minute. (See Fig. 16.) 9. Open the external manual gas valve. (See Fig. 17.) 10.

  • Page 7: Shutting Down Your Furnace

    NOTE: If the burners fail to ignite after 4 attempts, the furnace control system will lock out. If lockout occurs, main burners fail to light, or blower does not come on, shut down the furnace and call your dealer for service.

  • Page 8: Filtering Out Trouble

    All other operations must be performed by trained and qualified service agency personnel. Observe safety precautions in this manual, on tags, and on labels attached to the furnace, and other safety precautions that may apply. With proper maintenance and care, your furnace will operate economically and dependably.
  • Page 9 Fig. 24 - - Removing Side Filter Cabinet Door Fig. 25 - - Removing Bottom Filter Cabinet Door Fig. 26 - - Sliding Filter Retainer Sideways A06190 Fig. 27 - - Slide Air Filter Out of Furnace Fig. 28 - - Removing Filter Retainer from Latch A06191 A93010 Fig.
  • Page 10 32 and 33.) or filter cabinet door. (Fig. 34 and 35.) 9. Turn on electrical supply to furnace. If your furnace air filter needs to be replaced, be sure to use a factory- -authorized filter of the same size that was orginally supplied.

  • Page 11: Combustion Area And Vent System

    Check the combustion- -air intake and vent pipe on the outside of your home for blockage. When dirt, soot, scale, or rust is allowed to build up, your furnace can suffer a loss of efficiency and perform improperly. Accumulations on the main burners can result in firing out of normal sequence.

  • Page 12: Heading South For The Winter

    Do not use ethylene glycol (Prestone II antifreeze coolant or equivalent). Failure of plastic components may occur. 2. Turn off electrical supply to the furnace. (See Fig. 19.) 3. Remove main furnace door. (See Fig. 22.) 4. Remove upper inducer housing drain connection cap.

  • Page 13: A Check- -Up Checklist

    55_F db, such as when used with a night setback thermostat. Return- -air temperature must not exceed 85_F If you choose to leave your furnace on during extended absences do not set your thermostat lower than the limits shown in the Caution box above.

  • Page 14: Installation Data

    Have available the Model No., Series Letter, & Serial No. of your equipment to ensure correct replacement part. Copyright 2006 Carrier Corporation 7310 W. Morris St. Indianapolis, IN 46231 Manufacturer reserves the right to change, at any time, specifications and design without notice and without obligation.
