PARTS LIST

REF NO. PART NAME
A00 DOOR ASS'Y
B00 C/PANEL ASS'Y
F01 COVER WAVE GUIDE
F02 BUTTON LOCKING
F03 INSULATOR HEATER AS
F04 COUPLER
F05 GUIDE ROLLER AS
F06 TRAY
F07 TRAY RACK AS
F08 CABINET
F09 SCREW TAPPING
F10 SCREW SPECIAL
F11 NUT HEX
F12 CAVITY AS
F13 SCREW TAPPING
F14 SCREW TAPPING
F15 THERMOSTAT
F16 SCREW TAPPING
F17 NUT HEX
F18 CLAMP POWER CORD
F19 CORD POWER AS
F20 MAGNETRON
F21 SCREW SPECIAL
F22 SCREW TAPPING
F23 SCREW MATCHINE
F24 COVER *B
F25 MOTOR SHADED POLE
F26 FAN
F27 SCREW TAPTITE
F28 HOLDER HV CAPACITOR
F29 CAPACITOR H.V
F30 DIODE H.V.
F31 TRANS H.V.
F32 SCREW SPECIAL
F33 SCREW TAPPING
F34 BASE
F35 FOOT
F36 SCREW TAPTITE
F37 STOPPER HINGE *U
F38 SCREW TAPPING
F39 SW MICRO
F40 SW MICRO
F41 SW MICRO
F42 LEVER LOCK
F43 LOCK
F44 LAMP
F45 NOISE FILTER
F46 SCREW TAPPING
F47 MOTOR SYNCRO
F48 FUSE H.V
F49 SLOW ACTING RELAY
F50 SCREW TAPPING
PART CODE
EXPLODED AND PART LIST
3511403500 MICA T0.5
4078502031 PP
3513301400 KOG-36150S
3517400600 PPS
3512510600 KOR-61150S
3517203600 GLASS
3517204410 KOG-361Q0S 99MM
3510801300 PCM T0.6
7S312X40A1 T1 TRS 4X10 SE MFZN
3516003700 TT3 FLG HEX 4X8 MFZN
7S627W50X1 FLG NUT M5X0.8P MFZN
3516104810 KOG-36150S
7122401211 T2S TRS 4X12 MFZN
7121300611 T2S PAN 3X6 MFZN
3513902200 OFF:130 ON:115
7112401011 T1 TRS 4X10 MFZN
7S627W50X1 FLG NUT M5X0.8P MFZN
4413A90012 NYLON 66
35113AAQ95 3X0.75 60X60 120-RTML
3518002200 2M 218H(MF) I
3516002700 T2S FLG HEX 4X13 SE MFZN
7S312X40A1 T1 TRS 4X10 SE MFZN
7601400811 PAN 4X8 PW MFZN
3511402500 SBHG T0.8
3963512100 MW10CA-R01
3511800300 PP+30% GLASS
7272400811 TT3 TRS 4X8 PW MFZN
3513001900 SECC T0.8
441U667020 2100VAC 0.95uF
4416V24000 HVR-1X-32B
3518106210 JY-N80S0-61T
3516003700 TT3 TRS 4X8 MFZN
7112401011 T1 TRS 4X10 MFZN
3510308700 SBHG T0.8
3512100900 PP DASF-130
7272400811 TT3 TRS 4X8 MFZN
3515201101 SCP-1 T2.5
7122401211 T2S TRS 4X12 MFZN
4415A17352 VP-533A-OF
4415A66910 VP-531A-OF
4415A17352 VP-533A-OF
3513701300 POM
3513805700 POM
3513601600 BL 240V 25W T25
3518603700 DWLF-M
7121400611 T2S TRS 4X6 MFZN
3966310100 GM-16-24FD12
3518700900 HV-41A 5KV 0.55A #250
3518570400 DWSR-1
7122401211 T2S TRS 4X12 MFZN
30
DESCRIPTION Q'TY REMARKS
1
1
1
2
1
1
1
1
1
1
3
2
2
1
1
1
1
3
2
1
1
1
3
2
2
1
1
1
1
1
1
1
1
4
5
1
2
2
1
2
1
1
1
1
1
1
1
2
1
1
1 for Germany
1
