MICROWAVE OVEN
OPERATING
INSTRUCTIONS
Before operating this oven, please read these instructions completely.
KOG-311M
DEFROST
AUTO
COMBI
GRILL
WEIGHT
TIME
START
LOCK
M/W
NO/
g
CUPS
MICROWAVE GRILL OVEN RANGE
AUTO COOK
MENU
1. Baked Potato
2. Fresh Vegetable
3. Soup
4. Fish Fillets
WEIGHT
5. Meat Loaf
FROZEN
DINNER
PIZZA
PLATE
SPEEDY
COOK
MORE LESS
BEVERAGE
1
2
3
COMBI
4
5
6
GRILL
7
8
9
AUTO
0
Clock /
Power
DEFROST
A. Start
START
STOP / CLEAR
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Daewoo KOG-311M
Summary of Contents for Daewoo KOG-311M
-
Page 1: Microwave Oven
MICROWAVE OVEN KOG-311M OPERATING DEFROST AUTO COMBI GRILL WEIGHT TIME START INSTRUCTIONS LOCK CUPS MICROWAVE GRILL OVEN RANGE AUTO COOK MENU 1. Baked Potato 2. Fresh Vegetable 3. Soup 4. Fish Fillets WEIGHT 5. Meat Loaf FROZEN DINNER PIZZA PLATE... -
Page 2: Table Of Contents
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY (a) Do not attempt to operate this oven with the door open since open-door operation can result in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks. -
Page 3: Earthing Instructions
¶U This appliance is supplied with cable of special type, which, if damaged, must be repaired with cable of same type. Such a cable can be purchased from DAEWOO and must be installed by a Qualified Person. Examine the oven after unpacking for any damage such as: A misaligned door, Broken door, A dent in cavity. -
Page 4: Safety Instructions For General Use
SAFETY INSTRUCTIONS FOR GENERAL USE Listed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven: 1. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items or for sterilizing purposes. -
Page 5: Specifications
SPECIFICATIONS POWER SUPPLY 220V ~60 Hz SINGLE PHASE WITH EARTHING POWER CONSUMPTION MICROWAVE 1500 W GRILL 1150 W COMBI 2600 W MICROWAVE ENERGY OUTPUT 950 W (IEC 705) MICROWAVE FREQUENCY 2450 MHz OUTSIDE DIMENSIONS (W X H X D) 564 X 310 X 413 mm CAVITY DIMENSIONS (W X H X D) 374 X 233 X 372 mm NET WEIGHT... -
Page 6: Features Diagram
FEATURES DIAGRAM DEFROST AUTO COMBI GRILL WEIGHT TIME START LOCK CUPS MICROWAVE GRILL OVEN RANGE AUTO COOK MENU 1. Baked Potato 2. Fresh Vegetable 3. Soup WEIGHT 4. Fish Fillets 5. Meat Loaf FROZEN DINNER PIZZA PLATE SPEEDY COOK MORE LESS BEVERAGE COMBI GRILL... - Page 7 FEATURES DIAGRAM (continued) DEFROST AUTO COMBI GRILL WEIGHT TIME START LOCK CUPS MICROWAVE GRILL OVEN RANGE AUTO COOK MENU 1. Baked Potato 2. Fresh Vegetable 3. Soup WEIGHT 4. Fish Fillets 5. Meat Loaf FROZEN DINNER PIZZA PLATE SPEEDY COOK MORE LESS BEVERAGE COMBI...
-
Page 8: Operation Procedure
OPERATION PROCEDURE This section includes useful information about oven operation. 1. Plug power supply cord into a 220V AC 60Hz power outlet. 2. After placing the food in a suitable container, open the oven door and put it on the glass tray. The glass tray and roller guide must always be in place during cooking. -
Page 9: Controls
CONTROLS SETTING THE CLOCK When the oven is first plugged in, the display will flash ":0" and a tone will sound. If the AC power ever goes off, the display shows ":0" when the power comes back on. 1. Touch CLOCK/A.START pad. NOTE: This oven has multiple clock CLOCK/ This is a 12 hour clock system. -
Page 10: Time Defrosting
TIME DEFROSTING When TIME DEFROST is selected, the automatic cycle divides the defrosting time into periods of alternating defrost and stand times by cycling on and off. 1. Touch AUTO DEFROST pad. The WEIGHT DEFROST indicator light and AUTO "0" is displayed. And the g indicator starts DEFROST blinking. -
Page 11: Grill Cooking
GRILL COOKING This function allows you to brown food quickly. The heating element is located in the top of the oven. There is no pre-heating the oven for grill cooking. Place food inside the oven when setting the controls. 1. Touch GRILL pad. The GRILL indicator lights and ":0"... -
Page 12: Auto Start
AUTO START Auto start can be programmed for up to two cooking stages. Auto start can not be programmed for auto defrost. 1. Program the desired power level and cooking time for food to be cooked. 2. Touch CLOCK/A.START pad. The AUTO START indicator lights and ":0"... -
Page 13: One Touch Cooking
ONE TOUCH COOKING One touch cook allows you to cook or reheat many of your favorite foods by touching just one pad. To increase quantity, touch chosen pad until number in display is same as desired quantity to cook. (except for DINNER PLATE) 1. -
Page 14: Auto Cook (Menu & Weight)
AUTO COOK (MENU & WEIGHT) Auto cook allows you to cook or reheat many of your favorite foods by repeatedly touching menu pad. After the menu selection, touch chosen pad until number in display is same as desired quantity to cook. 1. -
Page 15: More, Less
MORE, LESS MORE pad: adds 10 seconds to 20 seconds. LESS pad: removes 10 seconds to 20 seconds. This pad only works with one touch cooking. Always input prior to one touch sequence. CHILD SAFETY LOCK The safety lock prevents unwanted oven operation such as by small children. To set, press and hold STOP/CLEAR for 3 seconds, LOCK indicator lights. -
Page 16: Microwave Utensils
MICROWAVE UTENSILS Glass, Ceramic and China Ovenproof glass or ceramic baking dishes are the most used microwave utensils. Many of these items are readily available in most homes : glass measure, custard cups, mixing bowls, covered casseroles, pie plates and round or square cake dishes. Ovenproof dinner ware is usually safe to use in the microwave. -
Page 17: Care Of Your Microwave Oven
CARE OF YOUR MICROWAVE OVEN Turn the oven off before cleaning. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water or in a dishwasher. Keep the inside of the oven clean. When food spatters or spilled liquids adhere to oven walls, wipe with a damp cloth. -
Page 18: Use Your Microwave Oven Safely
USE YOUR MICROWAVE OVEN SAFELY GENERAL USE Do not attempt to defeat or tamper with safety interlocks. Do not place any object between the oven front frame and the door or allow residue to build up on sealing surfaces. Wipe with a mild detergent, rinse and dry. Never use abrasive powders or pads. Do not subject the oven ddor strain or weight such as a child hanging on an open door. -
Page 19: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Refer to following checklist, you may prevent an unnecessary service call. ¶I The oven doesn't work; 1. Check that the power cord is securely plugged in. 2. Check that the door is firmly closed. 3. Check that the cooking time is set. 4.
