Icom IC-M401EURO Service Manual page 21

[MAIN UNIT]
REF ORDER
NO. NO.
C261 4030006860 S.CERAMIC
C262 4030007090 S.CERAMIC
C264 4030007090 S.CERAMIC
C265 4030007090 S.CERAMIC
C266 4030006860 S.CERAMIC
C267 4030007040 S.CERAMIC
C268 4030007040 S.CERAMIC
C270 4030007080 S.CERAMIC
C271 4030007040 S.CERAMIC
C272 4550006700 S.TANTALUM
C275 4030006860 S.CERAMIC
C276 4030011600 S.CERAMIC
C277 4030006860 S.CERAMIC
C278 4030007090 S.CERAMIC
C279 4030011600 S.CERAMIC
C280 4030011060 S.CERAMIC
C281 4030007090 S.CERAMIC
C282 4030006880 S.CERAMIC
C283 4030007010 S.CERAMIC
C284 4030007170 S.CERAMIC
C285 4030007010 S.CERAMIC
C286 4030007170 S.CERAMIC
C287 4030007010 S.CERAMIC
C288 4030007170 S.CERAMIC
C289 4030007010 S.CERAMIC
C290 4030007170 S.CERAMIC
C291 4030007010 S.CERAMIC
C292 4030007170 S.CERAMIC
C293 4030006850 S.CERAMIC
C294 4030007170 S.CERAMIC
C295 4030009510 S.CERAMIC
C296 4030007120 S.CERAMIC
C297 4030007120 S.CERAMIC
C298 4030006860 S.CERAMIC
C299 4030011600 S.CERAMIC
C300 4030017200 S.CERAMIC
RL1 6330001670 RELAY
J4 6510018970 S.CONNECTOR B4B-PH-SM3-TB
J5 6510019420 S.CONNECTOR B8B-ZR-SM3-TF
J6 6510022470 S.CONNECTOR 40FLT-SM1-TB
J7 6510015540 S.CONNECTOR B4B-ZR-SM3-TF
T1 5920000570 TRANSFORMER 12T01
W1 7120000470 JUMPER
W6 7030003860 S.JUMPER
W8 7030003860 S.JUMPER
EP1 0910054092 PCB
[FRONT UNIT]
REF ORDER
NO. NO.
MC1 0800006230 MICROPHONE HM-132B ACC <KN>
MC1 0800006240 MICROPHONE HM-132W ACC <KN>
SP1 2510001110 SPEAKER
W1 7120000470 JUMPER
W2 7120000470 JUMPER
W3 8900010500 CABLE
DESCRIPTION
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 180J-T-A
C1608 CH 1H 390J-T-A
C1608 CH 1H 180J-T-A
ECST1AY106R
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
C1608 JB 1H 102K-T-A
C1608 CH 1H 470J-T-A
C1608 JB 1C 104KT-N
GRM42-6 CH 040C 500PT
C1608 CH 1H 470J-T-A
C1608 JB 1H 472K-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 100D-T-A
C1608 CH 1H 221J-T-A
C1608 JB 1H 471K-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 010B-T-A
C1608 CH 1H 820J-T-A
C1608 CH 1H 820J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 104KT-N
GHM1030 R 102K 630PT
FTR-P3CP012W1
ERDS2T0
ERJ3GE JPW V
ERJ3GE JPW V
B 5678B
DESCRIPTION
[BLACK]
[WHITE]
045P1601 <KS>
ERDS2T0
ERDS2T0
OPC-1046
6-2 MH-132
[MAIN UNIT]
REF ORDER
NO. NO.
R1 7010006890 RESISTOR
R2 7010006880 RESISTOR
R3 7010006900 RESISTOR
R4 7010006910 RESISTOR
C1 4010008030 CERAMIC
MC1 7700002500 MICROPHONE KUC3523-040245 <KN>
S1 2260002330 SWITCH
S2 2260002340 SWITCH
S3 2260002340 SWITCH
S4 2260002340 SWITCH
EP1 0910053701 PCB
6 - 5
DESCRIPTION
R20J 12 kΩ
R20J 6.8 kΩ
R20J 15 kΩ
R20J 33 kΩ
DD104 B 471K 50V
SKHHLP014A
SKHHAM024A
SKHHAM024A
SKHHAM024A
B-5587A
S.=Surface mount
