MOUNTING CGO1™ ON GB200 (C)
1. Remove the 5.8GHz Wi-Fi antenna from the CGO1™.
2. Install the CGO1™ into the CGO1™ camera mount.
3. Connect the 5.8GHz Wi-Fi antenna by pressing it onto the
5.8GHz antenna socket on the CGO1™ and turn it 90° to secure the
antenna to the CGO1™ and camera mount.
4. Install the 3mm mounting screw to secure the CGO1™ to the
mount.
MOUNTING GOPRO® ON GB200™ (D)
1. Install GoPro3/3+® in the GoPro3/3+® mount
2. use the GoPro3/3+® mounting sleeve to secure the camera to the
mount. (see illustration)
MOUNTING GB200™ ON BLADE® 350QX (E,F,G and H)
1. Install the GB200™ gimbal mounting plate on the 350QX using
the (4) included screws.
2. Slide the GB200™ into place with the arm side toward the back
of the model.
3. Connect the Blade® 350 QX2 control cable to the camera pitch
control port on the GB200™ and the corresponding port on the
Blade® 350QX V2.
4. Place the Blade® 350 QX2 on a at and stable surface. Switch
on the Blade® 350 QX2. Do not move, sway or shake the model
during the automatic calibration process. After the automatic
calibration is complete, your GB200™ is ready to use.
