MONTICELLO
INSTALLer: Leave this manual with the appliance.
cONSuMer: retain this manual for future reference.
wArNINg
If the information in this manual is not followed ex-
actly, a fire or explosion may result causing property
damage, personal injury or loss of life.
–
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
wHAT TO DO If YOu SMeLL gAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any
phone in your building.
•
Immediately call your gas supplier from neighbor's
phone. follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire
department.
–
Installation and service must be performed by a
qualified installer, service agency or the gas sup-
plier.
Log sets comply with ANSI Z21.11.2 unvented Heaters
and also comply with ANSI Z21.60 Decorative vented
Appliances for Solid fuel Burning fireplaces. State or
local codes may only allow operation of log sets in a
vented configuration. Check your state or local codes.

INSTALLATION INSTrucTIONS

AND OwNer'S MANuAL
The QR Code below provides a link to our helpful
"how-to" vido. To get started, scan the code with your
smart phone or tablet.
LOg SeT fOr
veNTeD AND uNveNTeD
gAS LOg
MODeLS
ALS-18MN-1
ALS-24MN-1
ALS-30MN-1
wArNINg: If not installed, operated and maintained
in accordance with the manufacturer's instructions,
this product could expose you to substances in fuel
or from fuel combustion which can cause death or
serious illness.
GAS-FIRED
Page 1
