MONTICELLO
INSTALLer: Leave this manual with the appli-
ance.
cONSuMer: retain this manual for future ref-
erence.
wArNINgS
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of
life.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
wHAT TO DO If YOu SMeLL gAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from
neighbor's phone. follow the gas supplier's
instructions.
•
If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
INSTALLATION INSTrucTIONS
AND OwNer'S MANuAL
LOg SeT fOr
veNTeD AND uNveNTeD
gAS LOg
MODeLS
ALS-18MN-1
ALS-24MN-1
ALS-30MN-1
Log sets comply with ANSI Z21.11.2 unvented
Heaters and also comply with ANSI Z21.60
Decorative vented Appliances for Solid fuel
Burning fireplaces. State or local codes may only
allow operation of log sets in a vented configuration.
check your state or local codes.
wArNINg: If not installed, operated and main-
tained in accordance with the manufacturer's
instructions, this product could expose you to
substances in fuel or from fuel combustion which
can cause death or serious illness.
GAS-FIRED
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALS-18MN-1 and is the answer not in the manual?

Questions and answers

Related Manuals for American Hearth ALS-18MN-1

Summary of Contents for American Hearth ALS-18MN-1

  • Page 1 INSTALLATION INSTrucTIONS AND OwNer'S MANuAL LOg SeT fOr MONTICELLO veNTeD AND uNveNTeD gAS LOg MODeLS ALS-18MN-1 ALS-24MN-1 ALS-30MN-1 GAS-FIRED INSTALLer: Leave this manual with the appli- ance. cONSuMer: retain this manual for future ref- erence. wArNINgS If the information in this manual is not followed...
