- Page 1 LD700-24 Operating Manual Serial No _____________________________ Purchase Date ______________ Note - Your warranty can only be valid once your warranty card is completed and returned to Selectronic Australia...
-
Page 2: Table Of Contents
LD700-24 Volt Owners Manual Contents Page No. Introduction Warranty Card Installation Batteries and Connections Getting Started Quickly Parts Identification Operation STATUS Indicators Demand Start Setting Low Voltage Shutdown Setting Maintenance Inverter Batteries Handy Hint Radio Frequency Interference Fault Finding Product Warranty Conditions... -
Page 3: Introduction
Introduction Thank you for choosing to purchase the Selectronic LD700-24 TRUE SINE WAVE inverter. Many hours of Research and Development have gone into the LD700-24 to ensure this inverter provides you with many years of reliable service Warranty Card It is imperative that you complete your warranty card NOW. Your LD700- 24 is covered by a TWO-year warranty;... - Page 4 Large amounts of DC current can be drawn by your LD700-24, care must be taken. Fixed Installation All fixed installation battery connections must be securely bolted, using stainless steel nuts and bolts. To protect the connection from corrosion smear a small amount of Vaseline or similar over the joint.
- Page 5 (see your auto electrician). The LD700-24 has sufficient battery cable length to allow it to sit underneath the vehicle whilst in use. If the ground is wet, place the LD700-24 on a waterproof liner.
-
Page 6: Batteries And Connections
Batteries and Connections Batteries are the key to maximum performance from your LD700-24, if a battery is too small or not fully charged it may result in de-rated performance from your LD700-24. Battery ratings Batteries can be rated in one of two ways: 1. - Page 7 The Ah rating of a battery will also be reduced if the discharge current is higher than the rated discharge current. See your battery specifications for full details. LD700-24 Manual Selectronic Australia...
-
Page 8: Getting Started Quickly
3. Check unit for any damage that may have resulted during transport, if any damage is evident report this to your supplier immediately. 4. Make sure the LD700-24 ON/OFF switch (12) is in the off position. 5. Connect battery positive wire (red) (10) to battery positive or battery fuse. -
Page 9: Operation
ON. Once the load has been removed (e.g. the light switch is turned off) the inverter will wait 10 seconds and return to SLEEP mode. It is good practice to have your LD700-24 in SLEEP mode as often as possible. When the LD700-24 is in SLEEP mode it uses 0.03 amps from the battery, when the inverter is in the ON mode it uses at least 0.50 amps from the battery. - Page 10 AC load being drawn from it then LED (2) will come ON. The LD700-24 will remain in this condition for 1 minute after the AC load has been decreased to a safe level. LED (2) will flash if the inverter shuts down due to “time to shutdown”.
-
Page 11: Demand Start Setting
LED (5) comes ON, (approximately 1 second) indicating you are ready to adjust this setting. The LD700-24 will leave the factory with a setting of 4 watts. Now press the Mode button (7) until the desired value is sought. -
Page 12: Low Voltage Shutdown Setting
Low Volts Adjust LED (5) (green) FLASHING To avoid total discharging of your battery the LD700-24 shuts down at a pre- set low voltage. As all batteries are different, so too is the minimum voltage they should be discharged to. The LD700-24 will leave the factory with a setting of 22.0 volts, change this setting if required. -
Page 13: Maintenance
Maintenance Inverter Periodic maintenance of your LD700-24 inverter involves little more than checking for any obstructions to the black cooling heatsink at the rear of the inverter. The heatsink must be cleared of any accumulated foreign matter that may have lodged itself between the fins since the last maintenance check, e.g. -
Page 14: Handy Hint
This will indicate the inverter's operation by flashing when the inverter is in SLEEP mode and remaining ON when the inverter is brought ON by a load. LD700-24 Manual Selectronic Australia... -
Page 15: Radio Frequency Interference
Connection from the aerial to the radio should be via a low loss coaxial cable. Please note the aerial must be an AM RADIO type; a TV aerial will not work. LD700-24 Manual Selectronic Australia... -
Page 16: Fault Finding
Check again to make sure that there are no appliances left ON, the sequentially switch off appliances at the wall and by watching your night light (as described in Handy Hint, check to see if the LD700-24 returns to pulsing (SLEEP) mode after a 10 second delay. Once you have found the offending appliance, increase the sensitivity of the “Demand Start”... -
Page 17: Product Warranty Conditions
The manufacturer will not be held responsible for any misleading or incorrect information conveyed by any salesperson or installer not directly employed by the manufacturer. If service is required please contact your installer or retailer before taking any further action. LD700-24 Manual Selectronic Australia... -
Page 18: Specifications
LD700-24 Volt Specifications Inverter Type Microprocessor control circuit with PWM full bridge power stage. True sine wave AC output Current draw from Battery Condition Amperage Demand Start SLEEP mode (average) 0.03 Amps Inverter ON, with no Load 0.25 Amps Maximum Continuous Load (700 Watt) 32 Amps ... - Page 19 Operating Temperature Range 0C to 50º C Transformer Type Toroidal Cooling Method Controlled fan-forced Power Point 2 x 10 Amp Single Pole Chassis Material Zinc Coated Steel Chassis Coating Powder Coated Size 210W x 170H x 3100mm LD700-24 Manual Selectronic Australia...
-
Page 20: Selectronic Authorised Service Network
Selectronic Authorised Service Network Selectronic Australia Suite 5, 20 Fletcher Road Mooroolbark Victoria 3138 Australia Ph: +61 3 9727 6600 Fax: +61 3 9727 6601 www.selectronic.com.au service@selectronic.com.au Burley TV Service Rainbow Power Company 278 Edmondson Ave. 1 Alternative Way Austral...
