Lincoln Electric Cobramatic K2259-1 Technical Specifications

Cobramatic
Push-Pull Cabinet
The Cobramatic ® push-pull wire feeding system is a great example of Lincoln's
MIG welding expertise. The Cobramatic incorporates a push-pull drive system
that virtually eliminates the problems associated with wire feeding. This unique
master-slave drive system prevents tangling and damage to the wire, resulting in
increased weld quality and productivity. Combine that with some great new fea-
tures that make set-up easier and adjustments virtually unnecessary, and the
Cobramatic is a great MIG welding choice for all wire types.
Processes
MIG Pulsed
Advantage Lincoln
• Push-pull wire drive system yields reliable, consistent,
trouble-free wire feeding up to 50 ft. (15.2m) from the cabinet.
• Compatible with complete line of Lincoln push-pull torches.
• Feeds aluminum wire from diameters .030-1/16" (0.8-1.6mm)
with only a contact tip change.
• Patented paddle holds wire straight and level during feeding
to minimize damage to the wire.
• Patented clutch/brake system keeps wire from over running
on shut-off.
• Tool-less spool brake adjustment knob allows for easy
tension adjustment.
• Simplified wire tension adjustment using two position
steel/aluminum selector for foolproof operation.
• Three year manufacturers limited warranty.
Product Product
Name Number
Cobramatic K2259-1
(1)
With appropriate gun.
®
TECHNICAL SPECIFICATIONS
Rated Output
(1)
Input Power Current/Duty Cycle
42 VAC 400A/100%
Note: Cobramatic
SEMIAUTOMATIC WIRE FEEDERS
Description
Output Input
Required Options
Prince XL ® , CobraMax TM , or Python
Recommended Power Sources
CV-250, CV-300, CV-400, CV-655, V350 PRO, DC-400, DC-600,
DC-655
Order
K2259-1 Cobramatic
Wire Feed Speed Wire Size Range
Range ipm (m/min)
ipm (m/min.) Solid Cored
0-800 Max. .030-1/16 .030-1/16
(0-20.3) (0.8-1.6) (0.8-1.6)
® , Prince ® XL, CobraMax TM and Python ®
42
VAC
® push-pull guns.
Dimensions
H x W x D Net Weight
inches (mm) lbs.(kg)
14.8 x 9.5 x 19.3 42
(376 x 241 x 490) (19.0)
are registered trademarks of MK Products, Inc.
Publication E8.300 7/03
Web Update 10/03
