CANON HDMI

NOTES ABOUT USING THE ODYSSEY WITH CANON VIA HDMI

This guide covers using the Odyssey with the following cameras:
Canon 5D Mark III
Canon 1DC
Canon C100
Canon C100 MKII
The Odyssey7/7Q do not support 1080p59.94 or 4K over HDMI due to a hardware constraint. If Auto
HDMI output is used, the camera will output 1080i. (Odyssey7Q+ it will accept 4K or 1080p59.94).
Please note that though the Canon 1DC can record 4K internally, the output is HD only.

APPLE PRORES RECORD TIMES

24 25
1080p 670 643
1080i
720p
1080p
1060 1016
1080i
720p
1080p 1516 1456
1080i
720p
Note: 4K and 1080p50/60 over HDMI is only supported on the 7Q+, to record 1080p50/60 on a Odyssey7 or
Odyssey7Q you must use a HDMI to SDI converter, as 7/7Q are limited to 1080p30 over HDMI due to a hardware
constraint. Note: Odyssey 7 only has 1 SSD slot

FORMAT DETAILS

HD Apple ProRes

FRAME RATE SUPPORT

The following frame rates are supported on the Odyssey while recording from these cameras:
• 1080p59.94/50 (HDMI - Odyssey7Q+ / HDMI to SDI Converter - Odyssey7Q)
• 1080i50/59.94
• 1080p25/29.97
• 1080p23.98 (24p output and 3:2 pulldown)

TYPICAL DOWNLOAD TIME IN MINUTES

Media USB3.0
256G SSD 20
512G SSD 40
1TB SSD 80
Actual transfer rates are dependent on computer system and destination media.
30 50 60
536 322 268
643 536
724 604
848 508 424
1016 848
924 772
1212 728 604
1456 1212
1456 1212
1920x1080,1280x720 10-bit log video, originated from HD 8-bit camera signal, recorded
as Apple ProRes compressed HD video .MOV
Thunderbolt
10
20
40
1
