Convergent Design Odyssey 7Q Setup Manual

Hide thumbs Also See for Odyssey 7Q:
Table of Contents

Advertisement

Quick Links

See also: User Manual
4K RAW up to 60p
4K RAW to 4K Apple ProRes up to 30p
4K RAW to UHD Apple ProRes up to 30p
2K RAW up to 240p
4K RAW to 2K Apple ProRes up to 60p
4K RAW to HD Apple ProRes up to 60p
4K/UHD Apple ProRes up to 30p (HDMI)
1080p video to Apple ProRes up to 60p
SONY FS7
SETUP GUIDE
Updated March 31, 2015 | Firmware Release v5.10.100
ProRes 422 (HQ)
ProRes 422
ProRes 422 (LT)
Odyssey7Q
Odyssey7Q+

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Odyssey 7Q and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Convergent Design Odyssey 7Q

Summary of Contents for Convergent Design Odyssey 7Q

  • Page 1 SONY FS7 SETUP GUIDE Odyssey7Q Odyssey7Q+ 4K RAW up to 60p 4K RAW to 4K Apple ProRes up to 30p 4K RAW to UHD Apple ProRes up to 30p 2K RAW up to 240p 4K RAW to 2K Apple ProRes up to 60p 4K RAW to HD Apple ProRes up to 60p 4K/UHD Apple ProRes up to 30p (HDMI) 1080p video to Apple ProRes up to 60p...

  • Page 2: Recording Capabilities

    2048x1080, 12-bit linear data, recorded as Uncompressed .DNG TYPICAL DOWNLOAD TIME IN MINUTES Media USB3.0 Thunderbolt 256G SSD 512G SSD 1TB SSD Actual transfer rates are dependent on computer system and capture media. USB 3.0 or Thunderbolt connections are recommended by Convergent Design for efficient data rates.
  • Page 3 RECORDING CAPABILITIES APPLE PRORES RECORDING Odyssey now supports recording Apple ProRes 422 (HQ), Apple ProRes 422 and Apple ProRes 422 (LT). Files are saved in .MOV format. The Sony FS7 Recording Option Upgrade is not required for recording 4K to Apple ProRes over HDMI. The Sony FS7 outputs 4K as a RAW signal, which is processed and coverted by Odyssey.
  • Page 4 RECORDING CAPABILITIES SUPPORTED FRAME RATES 4K (4096x2160) ü ü ü 4K HDMI (4096x2160) ü ü ü UHD (3840x2160) ü ü ü UHD HDMI (3840x2160) ü ü ü 2K (2048x1080) ü ü ü ü ü 2K High-Speed RAW (2048x1080) ü ü ü...
  • Page 5 4K/2K RAW RECORDING FS7 CONFIGURATION The Odyssey Sony FS7/FS700 Recording Option Upgrade (available on our website) is required for recording 4K, 2K, RAW and HFR. The Sony XDCA-FS7 Extension Unit for the FS7 is required for RAW output from the FS7. 1.
  • Page 6 4K/2K RAW RECORDING 6. SET RECORD COMMAND FOR SDI/HDMI TRIGGERING MENU » RECORDING » SDI/HDMI REC CONTROL » SETTING » ON 7. SET CAMERA FOR RAW HIGH SPEED If you are not recording 2K RAW 100/120 please skip this step. MENU »...
  • Page 7 4K/2K RAW RECORDING ODYSSEY CONFIGURATION (RAW RECORDING) Use this section to set up the Odyssey for RAW recording. For RAW to ProRes recording please refer to the next section of this guide. The Odyssey Sony FS7/FS700 Recording Option Upgrade (available on our website) is required for recording 4K RAW to ProRes.
  • Page 8 4K 50/59p = RAID (two drives) RAID is set up automatically upon detecting the input signal - no setup is required. NOTE You can use any Convergent Design media; they need not be matching (ie, one 256GB card and one 512GB card).
  • Page 9 4K RAW TO PRORES RECORDING ODYSSEY CONFIGURATION (4K RAW TO PRORES RECORDING) Camera must be set to 4K RAW output to record to 4K RAW to Apple ProRes. The Odyssey Sony FS7/FS700 Recording Option Upgrade (available on our website) is required for recording 4K RAW to ProRes.
  • Page 10 4K RAW TO PRORES RECORDING 5. FORMAT SSDs ☼ » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a second SSD drive installed.) 6. CONNECT TO CAMERA AND VERIFY STATUS INPUT Connect FS7 3G-SDI output to Odyssey SDIA input NOTE Use only 3G-SDI rated cables from FS7 to Odyssey.
  • Page 11 FS7 422 TO PRORES RECORDING FS7 CONFIGURATION 1. SET COUNTRY (NTSC/PAL) MENU » USER » COUNTRY » NTSC/PAL AREA » (NTSC | PAL) 2. SELECT A CODEC MENU » USER » CODEC » (SELECT) RAW + XAVC-I RAW + XAVC -L RAW + MPEG HD422 XAVC-I XAVC -L...
  • Page 12 FS7 422 TO PRORES RECORDING ODYSSEY CONFIGURATION (422 TO PRORES RECORDING) 1. SET MODE TO APPLE PRORES RECORDING HD RECORDING ☼ » SETUP » CAMERA » SONY FS7 » HD ->HD PRORES 4K/UHD HDMI TO 4K/UHD PRORES (ODYSSEY7Q+ ONLY) ☼ » SETUP » CAMERA » SONY » 4K/UHD PRORES(.MOV) UHD HDMI TO HD PRORES (ODYSSEY7Q+ ONLY) ☼...
  • Page 13 FS7 422 TO PRORES RECORDING 5. FORMAT SSDs ☼ » ODYSSEY » SSD’S » FORMAT BOTH (or FORMAT SSD1 if you do not have a second SSD drive installed.) 6. CONNECT TO CAMERA AND VERIFY STATUS INPUT Connect FS7 3G-SDI output to Odyssey SDIA input SDI CABLES Use only 3G-SDI rated cables from FS7 to Odyssey.
  • Page 14 UNCOMPRESSED DPX RECORDING FS7 CONFIGURATION 1. SET COUNTRY (NTSC/PAL) MENU » USER » COUNTRY » NTSC/PAL AREA » (NTSC | PAL) 2. SELECT A CODEC MENU » USER » CODEC » (SELECT) RAW + XAVC-I RAW + XAVC -L RAW + MPEG HD422 XAVC-I XAVC -L MPEG HD422...
  • Page 15 UNCOMPRESSED DPX RECORDING ODYSSEY CONFIGURATION 1. SET ODYSSEY TO FS7 TO UNCOMPRESSED DPX MODE ☼ » SETUP » CAMERA --> SONY FS7 » HD->4:4:4 (.DPX) Click OK - The unit will restart. 2. MAKE FS7 THE RECORD TRIGGER ☼ » SETUP » RECORD TRIGGER » CAMERA 3.

  • Page 16: Off-Loading Data

    1) Navigate to Applications » Utilities » System Preferences 2) Select Security and privacy 3) Under General » Allow applications downloaded from: Select Anywhere. You will now be able to run the installer for installing any Convergent Design Applications. CONTINUED »...

  • Page 17: Post Production

    POST PRODUCTION Apple ProRes The Odyssey can record in Apple ProRes 422 (HQ), Apple ProRes 422 and Apple ProRes 422 (LT) compressed codecs. This allows for high quality recording while avoiding high data rates of working with uncompressed video. NATIVE APPLE PRORES SUPPORT Adobe CC 2014 Final Cut Pro 7 Autodesk Smoke...
  • Page 18 The Media Pool settings are helpful if you have a mix of different clip types, you can sort by codec, select a group and adjust. For your convenience, Convergent Design has generated several example LUTs that can be applied to your RAW footage. Keep in mind these LUTs are an approximation, and may need adjustment depending on your application.

  • Page 19: Working With Recorded Files

    Apple FCP Pro Apple FCP Pro X Meta Fuse Avid Media Composer ☎ ++(720)221-3861 ✉ CDSupport@convergent-design.com ☁ Convergent-Design.com © 2015 Convergent Design, Inc. - All Rights Reserved. All copyrights and trademarks remain the property of their respective owners. Updated March 31, 2015...

This manual is also suitable for:

Odyssey 7q+
