Onkyo DV-SP300 Service Manual

Schematic diagram & printed circuit board view only
Hide thumbs Also See for DV-SP300:
Table of Contents

Advertisement

Quick Links

See also: Instruction Manual
Schematic diagram & Printed circuit board view only
SAFETY-RELATED COMPONENT
WARNING!!
THE MARK
PARTS INDICATES THE CRITICAL FOR RISK OF
FIRE AND ELECTRIC SHOCK.
WHEN REPLACING, BE SURE TO USE PARTS OF
IDENTICAL DESIGNATION.
MAKE LEAKAGE-CURRENT OR RESISTANCE
MEASUREMENTS TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE
SUPPLY CIRCUIT BEFORE RETURNING THE
APPLIANCE TO THE CUSTOMER.
SERVICE MANUAL
SERVICE MANUAL

DVD PLAYER

DV-SP500
MODEL
Black model
BUDD1N
120V AC, 60Hz
BUUS4P
110-240V AC, 50/60 Hz
FOUND ON SOME COMPONENT
DV-SP300
Ref. No. 3735
082002
RC-501DV

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-SP300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onkyo DV-SP300

Summary of Contents for Onkyo DV-SP300

  • Page 1: Dvd Player

    DV-SP300 Ref. No. 3735 082002 SERVICE MANUAL SERVICE MANUAL Schematic diagram & Printed circuit board view only DVD PLAYER DV-SP500 MODEL RC-501DV Black model BUDD1N 120V AC, 60Hz BUUS4P 110-240V AC, 50/60 Hz SAFETY-RELATED COMPONENT WARNING!! THE MARK FOUND ON SOME COMPONENT PARTS INDICATES THE CRITICAL FOR RISK OF FIRE AND ELECTRIC SHOCK.

  • Page 2: Specifications

    DV-SP300 SPECIFICATIONS DVD Player Power supply AC 120V, 60 Hz (North America models) AC 110-240V, 50/60 Hz (Other models) Power consumption 16 W Weight 8.2 lbs External dimensions " x 3 " x 12 " (W/H/D) Signal system NTSC (North America models)

  • Page 3: Service Procedure

    DV-SP300 SERVICE PROCEDURE-1 REPLACING THE FUSES This symbol located near the fuse indicates that the fuse used is show operating type, For continued protection against fire hazard, replace with same type fuse , For fuse rating, refer to the marking adjust to the symbol.
  • Page 4 DV-SP300 SERVICE PROCEDURE-2 1.Remove the solder of Laser Diode shorting Connect Pickup and DVD main circuit PC board by FFC(CP21 and B04). Fix it with the DVD Mecha Remove the solder of Laser Diode shorting on Pickup. Pickup Short Land 2.

  • Page 5: Panel View

    DV-SP300 PANEL VIEW-1 FRONT PANEL POWER button PLAY/PAUSE button Turns on the main power supply Begins to play disc (close disc tray first if it is open.) Temporarily stops playback when a disc is playing. Press this STANDBY indicator button again for normal playback.

  • Page 6: Rear Panel

    DV-SP300 PANEL VIEW-2 REAR PANEL VIDEO OUTPUT COMPONENT DIGITAL ANALOG DVD PLAYER OUTPUT OUTPUT DV-SP300 MODEL NO. OPTICAL COAXIAL VIDEO S VIDEO DIGITAL OUTPUT OPTICAL jack VIDEO OUTPUT VIDEO jack Use optical cable to connect your DVD Player to an AV Connect a video cable to this jack and to the Video Input jack on component that features digital input capability.

  • Page 7: Display Examples

    DV-SP300 PANEL VIEW-3 DISPLAY 10 11 12 PROGRESSIVE RESUME RANDOM REPEAT 1ALL INTRO MEM. TITLE CHAPTER TRACK HOUR 13 14 Display Examples Inserted disc indicators Indicate the type of current disc that is loaded. During DVD-Video playback: Play/Pause indicators Illuminate in play or pause mode.

  • Page 8: Remote Controller

    DV-SP300 PANEL VIEW-4 REMOTE CONTROLLER ON SCREEN button Press this button while you're playing a disc to see Banner Display on the screen.The Banner Display contains various pla yback features and gives you the information about the disc you're playing.
  • Page 9 DV-SP300 EXPLODED VIEW CHASSIS 25 S2...
  • Page 10 EXPLODED VIEW DRAWING PARTS LIST DV-SP300 PART NO. DESCRIPTION REMARK 55367120 WINDOW DISPLAY 55186750 LOGO BADGE 55382170 FRONT PANEL 55186710 FACET 55367100 STANDBY BUTTON 55367110 POWER KNOB 55371590 SHAFT 55367090 OPEN/CLOSE BUTTON 55366990 PLAY BUTTON 55491360 DISPLAY CIRCUIT PC BOARD <USS>...
  • Page 11 DV-SP300 DAC LAT12S BA4560 DAC SCKDSO L AUDIO L CH MIXD DAC MUTEB L. P. F. DAC SIDIM CSBWL MUTE DAC ZERO BA4560 JK83-1 PCM DATA R AUDIO CVBS-VIDEO PCNCLK R CH MIXD L. P. F. PCM MCLK PCM LRC...

  • Page 12: Block Diagram

    BLOCK DIAGRAM Display circuit PC board CN91 +5VS FL AC FL AC -27V FL91 PWR. COT. IC91 FL DISPLAY F OE (DRAM OE) F CE ADDR+ F WE F RESET F DE DATA AC IN AUDI MUTE DATA RDNOTWR D RAS0- ADDR D CAS0- D CAS1-...
  • Page 13 DV-SP300 BLOCK DIAGRAM Display circuit PC board CN91 +5VS FL AC FL AC -27V FL91 PWR. COT. IC91 FL DISPLAY F OE (DRAM OE) F CE DAC LAT12S BA4560 DAC SCKDSO L AUDIO L CH MIXD DAC MUTEB L. P. F.
  • Page 14 DV-SP300 AD JIG 5P_1mm +3V3 0(SMD) J201 0(SMD) DXX_INTERRRUPT J202 (IRQ2) +3V3 +2V5 CP23 FPC-ST-15P-1mm TRIGOUT TRIIN GND(Option) 47(SMD) R237 47(SMD) R238 47(SMD) R239 C221 47(SMD) R240 100/10 +5VD TXD(JIG) C220 RXD(JIG) (SMD) JTAG_RST/ R241 TRST 47(SMD) F_RESET +3V3 R247...

  • Page 15: Schematic Diagram

    SCHEMATIC DIAGRAM +5VD IC51 74HCU04 L501 100N(SMD) FCM2012H-102 MAIN CIRCUIT C504 DOWN LOAD JIG 0R-03 D3V3 R235 100(SMD) R503 PC BOARD R501 1M(SMD) X501 X-TAL 0(S) R511 22P(S) R512 FPCD_ST_15P_1mm 0(S) CP22 R405 47(SMD) R403 47(SMD) R402 47(SMD) R401 47(SMD) +3.3VM F_DATA00 RA41 47R...
  • Page 16 DV-SP300 SCHEMATIC DIAGRAM +5VD IC51 74HCU04 L501 FCM2012H-102 100N(SMD) MAIN CIRCUIT C504 DOWN LOAD JIG 0R-03 D3V3 R235 100(SMD) PC BOARD R503 R501 1M(SMD) X501 X-TAL 0(S) R511 22P(S) R512 FPCD_ST_15P_1mm 0(S) CP22 +3V3 0(SMD) J201 0(SMD) DXX_INTERRRUPT J202 (IRQ2)
  • Page 17 DV-SP300 PLY UNIT FROM POWER SUPPLY UNIT FROM MAIN PCB...
  • Page 18 SCHEMATIC DIAGRAM FROM POWER SUPPLY U OUTPUT TERMINAL PC BOARD V-MUTE...
  • Page 19 DV-SP300 SCHEMATIC DIAGRAM FROM POWER SUPPLY UNIT OUTPUT TERMINAL PC BOARD V-MUTE FROM POWER SUPPLY UNIT FROM MAIN PCB...
  • Page 20 DV-SP300...
  • Page 21 SCHEMATIC DIAGRAM PROGRESSIVE SCAN CIRCUIT...
  • Page 22 DV-SP300 SCHEMATIC DIAGRAM PROGRESSIVE SCAN CIRCUIT...
  • Page 23 DV-SP300 SCHEMATIC DIAGRAM POWER SUPPLY UNIT EER2829 D1 to D4 1N4007 x 4 10D7 AC125VT2A HER105 + C9 152P 100uF 104P 10D221 104P 222P 3.3V FL5V+ 1N4937 150K -27V 100uF FL5V- 200V 1/8W 5.5VS 47uF HER107 11, 12 2.2K 100uF 3.3K...
  • Page 24 DV-SP300 WIRING CONNECTION DIAGRAM AC IN CNB1 CN83 CP10 CN-2.2-12P CN-2.2-12P CN-2.0-12P CN-2.0-12P +8VA AGND -8VA PROGRESSIVE SCAN PC BOARD +12VA +5V5S +3V5D DGND POWER SUPPLY UNIT +2V5D +5VD CYBS CP11 FPC-35P-1.25mm GND (MOTOR) +9V (LOADING) OUTPUT TERMINAL PC BOARD FFC-19P-1.25mm...

  • Page 25: Power Supply Unit

    DV-SP300 PRINTERD CIRCUIT BOARD VIEW POWER SUPPLY UNIT...
  • Page 26 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (1/6) IC21: STI5519 MPEG ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT PIOs and communication PIO2[5] PIO2[5] PIOs and communication PIO2[6] PIO2[6] PIOs and communication PIO2[7] PIO2[7] VDD3_3 3.3V POWER SUPPLY...
  • Page 27 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (2/6) ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT Video DAC I_REF_YCC I_REF_DAC_YCC VDD2_5 2.5V POWER SUPPLY POWER GROUND POWER PIOs and communication PIO4[0] PIO4[0] YC[0] PIOs and communication PIO4[1] PIO4[1]...
  • Page 28 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (3/6) ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT Share memory interface SMI_CS[0] CHIP SELECT BANK0 Share memory interface SMI_CS[1] CHIP SELECT BANK1 Share memory interface SMI_RAS RAS SDRAM Share memory interface...
  • Page 29 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (4/6) ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT JTAG TEST DATA IN JTAG TEST CLOCK TIMER PWM2 PULSE WITDH MODULA2 VSYNC TIMER PWM1 PULSE WITDH MODULA1 BOOT FROM ROM3 TIMER...
  • Page 30 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (5/6) ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT GROUND POWER EMI Interface CPU_DATA[8] DATA[8] EMI Interface CPU_DATA[9] DATA[9] EMI Interface CPU_DATA[10] DATA[10] EMI Interface CPU_DATA[11] DATA[11] EMI Interface CPU_DATA[12] DATA[12]...
  • Page 31 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (6/6) ALTERNATE FUNCTION PIN NUMBER DESCRIPTION PIN NAME MAIN FUNCTION TYPE REMARK INPUT OUTPUT PIOs and communication PIO0[2] PIO0[2] ATAPI_WR PIOs and communication PIO0[3] PIO0[3] PIOs and communication PIO0[4] PIO0[4] PIOs and communication PIO0[5] PIO0[5] PIOs and communication...
  • Page 32 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION IC91: CXP82532 Key Control (1/2) PIN NAME MAIN FUNCTION IN/OUT REMARK NUMBE PE3/INT3 INPUT FOR EXTERNAL INTERRUPT REQUEST. PE4/RMC INPUT FOR REMOTE CONTROL RECEIVING CIRCUIT. PE7/TO OUTPUT PIN FOR 16-BIT TIME/COUNTER RECTANGULAR WAVEFORM. PBO/CINT EXTERNAL CAPTURE INPUT FOR 16-BIT TIME/COUNTER.
  • Page 33 DV-SP300 MICROPROCESSOR TERMINAL DESCRIPTION (2/2) PIN NAME MAIN FUNCTION IN/OUT REMARK NUMBE T11/S25 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. T10/S26 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL. T9/S27 DUAL PURPOSE OUTPUT FOR FDP TIMING AND SEGMENT SIGNAL.

  • Page 34: Packing View

    DV-SP300 PACKING VIEW STEP 1 : LABEL FOR SET POSITION JULY 2002 SERIAL STEP 4 : SET IN BOX STEP 6 : PACKED-IN ACCESSORIES For Rear panel (PUT ON THE POLY BAG). 5 1 9 3 8 Serial No. For Carton box 5 1 9 8 Seri a l No.

  • Page 35: Printed Circuit Board Parts List

    PRINTED CIRCUIT BOARD PARTS LIST Nortn America model (AC 120V, 60Hz MAIN CIRCUIT PC BOARD Signal system NTSC) CIRCUIT NOPART NO. PART NAME DESCRIPTION CC21 55490200 19X 1.25MM 130MM CC24 55318530 19X 1.25MM 50MM DV603 CC25 55455560 17X 1.25MM 50MM CC29 55490230 35X 1.25MM 120MM...
  • Page 36 55209110 Finger PIN-STRIP 0.0MM 1 -- U FINGER STRIP DVD10 0 0 FL91 55414960 FL tube HNV-12SM23 IC91 55443260 CXP82532-312Q DV-SP300 MICROCONT IC93 55191090 KIA7045P LOW VOLTAGE DROP LG92 55541050 Socket AS 1P 100MM UL1007 RIBBON 18 1 MCN1 55234770...
  • Page 37 D819 55177710 Diode Zener UDZS 5.1 B 5.1V 200MI0W D820 55177710 Diode Zener UDZS 5.1 B 5.1V 200MI0W D821 55177710 Diode Zener UDZS 5.1 B 5.1V 200MI0W IC81 55291470 WM8728 D/A CONV IC82 55128990 BA4560F DUAL OP AMP L801 10328750 Coil 0 OHM +0% 62MI5W L802...
  • Page 38 Q14B 55133180 Transistor DTC114YKA N 10K0 OHM 47K0 OHM Q14G 55133180 Transistor DTC114YKA N 10K0 OHM 47K0 OHM Q14R 55133180 Transistor DTC114YKA N 10K0 OHM 47K0 OHM Q15B 55137830 Transistor KTN2907AS N 50V -600MI0A Q15G 55137830 Transistor KTN2907AS N 50V -600MI0A Q15R 55137830 Transistor...
  • Page 39 PRINTED CIRCUIT BOARD PARTS LIST Asia area only (AC 110-240V, 50/60Hz Video signal system PAL/NTSC) MAIN CIRCUIT PC BOARD CIRCUIT NPART NO. PART NAME DESCRIPTION CC21 55490200 19X 1.25MM 130MM CC24 55318530 19X 1.25MM 50MM DV603 CC25 55455560 17X 1.25MM 50MM CC29 55490230 35X 1.25MM 120MM...
  • Page 40 FG92 55209110 Finger PIN-STRIP 0.0MM 1 FL91 55414960 FL Tube DISPLAY HNV-12SM23 IC91 55443260 CXP82532-312Q DV-SP300 IC93 55191090 KIA7045P LOW VOLTAGE DROP LG92 55541050 1P 100MM UL1007 RIBBON 18 1 MCN1 55234770 Socket AS 2 80MM UL1617 PVC DOUBLE INSULATED 22 12...
  • Page 41 CN83 55455960 Socket AS 2.0MM 12P 100MM UL1533 SHIELD 26 1 CP81 55455860 Connector AS 1.25MM 17 FE ST WH GF120-17S-TS 0 0 CP82 55124600 Connector AS 1.25MM 19 FE ST WH GF120-19S-TS 2794 A6 CP83 55090070 Connector AS 2.0MM 2 MA ST NAT LW2002P0200T 0 0 D805 20415050 Diode...
  • Page 42 PROGRESSIVE SCAN CIRCUIT PC BOARD CIRCUIT NPART NO. PART NAME DESCRIPTION BK10 55176420 Bracket CP10 55090100 Connector 2.0MM 12 MA ST NAT LW2002P12 0 0 CP11 55209230 Connector 1.25MM 35 FE ST BK GF120-35S-TS 0 0 GNDA 55135980 Terminal LUG GND VR11 55307870 Semi fix resistor...
  • Page 43 C13Y 20269020 Electric capacitor 100U0F +20% 16.0V 85C C14B 20251930 Electric capacitor 22U0F +20% 16.0V 85C C14G 20251930 Electric capacitor 22U0F +20% 16.0V 85C C14R 20251930 Electric capacitor 22U0F +20% 16.0V 85C C14S 20251930 Electric capacitor 22U0F +20% 16.0V 85C C14Y 20251930 Electric capacitor...
  • Page 44 PACKING VIEW PARTS LIST Loc. No PART NO. DESCRIPTION DV-SP300 UDD DV-SP300 UUS 55169520 POLY BAG 820MM X 820MM 55366390 PAD LEFT 20194780 CABLE-TIE 20715540 POLY BAG 70MM X 250MM 55366290 PAD RIGHT 55208740 CUSHION 80.0MM X 35.0MM 55378730 CARTON BOX <UDD>...
