Daikin 4PW72362-1-21 Quick Reference

3. Name and function of switches
Quick Reference
a 4PW72362-1-21
The English text is the original instruction. Other languages are
translations of the original instructions. 9
Refer to the cd for more detailed operation manuals. 4
Installation: see page 2.
5
OPERATION
1
3
1. General safety precautions
Also see operation manual attached to the outdoor and
2
indoor unit.
Please read these "1. General safety precautions" carefully before
1 OPERATION MODE SELECTOR BUTTON
installing air conditioning equipment and be sure to install it
To select the operation mode of your preference.
correctly.
Failure to follow these instructions properly may result in property
2 FAN SPEED/AIRFLOW DIRECTION SETTING BUTTON
damage or personal injury, which may be serious depending on the
To enter the fan speed/airflow direction setting screen.
circumstances.
3 MENU/ENTER BUTTON
WARNING
To enter the main menu or the selected setting item.
Do NOT play with the unit or its remote controller.
Accidental operation by a child may result in impairment of 4 UP/DOWN BUTTON
bodily functions and harm health.
To raise/lower the set temperature, to highlight the next item on the
upper/lower side or to change the selected item.
WARNING
5 RIGHT/LEFT BUTTON
Never disassemble the remote controller. Touching the
To highlight the next item on the right/left-hand side.
interior parts may result in electric shocks or fire. Consult
your Daikin dealer or authorized contactor for internal
6 ON/OFF BUTTON
inspections and adjustments.
To start or stop the system.
WARNING INFORMATION
To avoid electric shocks, do not operate with wet hands. This is the only button that works when the backlight is not
lit.
WARNING
7 OPERATION LAMP
 Do NOT modify or repair the remote controller. This
Lights up during operation or blinks if a malfunction occurs.
may result in electric shocks or fire. Consult your
Daikin dealer. 8 CANCEL BUTTON
 Do NOT relocate or reinstall the remote controller by
To return to the previous screen.
yourself. Improper installation may result in electric
shocks or fire. Consult your Daikin dealer. 9 LCD (with backlight)
 Do NOT use flammable materials (e.g. hairspray or
When pushing any operation button, the backlight will be lit for
insecticide) near the product. Do not clean the
approximately 30 seconds. When 1 indoor unit is controlled by 2
product with organic solvents such as paint thinner. remote controllers, the backlight of the remote controller operated
The use of organic solvents may cause crack damage
earlier than the other one will be lit.
to the product, electric shocks, or fire.
4. Name and function of icons
2. Features and functions
To change between the standard display and the detailed display
The BRC1E52B7 is a state of the art remote controller that offers
refer to "15.2 To select the display mode".
full control over your installation.
Standard display
1 BASIC REMOTE CONTROLLER
The basic remote controller functions are:
 ON/OFF,
 operation mode change-over,
 temperature adjustment,
 air volume adjustment,
 air flow direction adjustment.
2 CLOCK FUNCTION
The clock functions are:
 12/24 hours real time clock,
 automatic daylight saving time.
3 SCHEDULE FUNCTION Detailed display
The schedule timer functions are:
 a maximum of 5 actions can be programmed for each day of
the week,
 3 independent schedules can be programmed,
 schedule can be enabled/disabled at any time,
 linked to a cool temperature and/or heat temperature or an
OFF operation (with or without a setback temperature),
 "last command" overrules previous command until next
scheduled command.
1 OPERATION MODE
4 SETBACK
Indicates the current operation mode (Cool, Heat, Vent, Fan, Dry, or
The setback function maintains the room temperature in a specific Auto).
range when the occupants are out for a longer period and the
2 FAN SPEED
airconditioning is switched OFF.
Indicates the fan speed that is set for the air conditioner. If the air
5 PROHIBIT BUTTON/FUNCTION
conditioner does not have fan speed control function, the fan speed
Buttons and/or functions can be locked to limit the user action. will not be displayed.
6 DETAILED DISPLAY POSSIBILITY 3 SET/SETBACK TEMPERATURE DISPLAY
Additionally possible to display the outdoor temperature or room When the unit is turned on, Set to indicates the temperatures that
temperature. are set for the air conditioner.
When the unit is turned off, Setback indicates the temperatures that
are set for the setback function.
4 DEFROST/HOT START
Indicates that the defrost/hot start mode is active.
5 MESSAGE
Messages can be displayed.
6 VENTILATION/CLEANING
 Ventilation mode icons
ventilation mode (HRV only) (AUTOMATIC, ENERGY RECLAIM VENT.,
BYPASS).
 Air Cleaning unit icon
(option) is operational.
Quick Reference
1
7 DISPLAY
Indicates that the key lock is set or the menu button is prohibited.
8 DISPLAY
Indicates that schedule timer or OFF timer is enabled.
DISPLAY
Indicates that the clock needs to be set. The schedule timer
function will not work until the clock is set.
9 EXTERNAL CONTROL ICON
7
Indicates that another controller with higher priority is controlling or
disabling your remote controller.
6 10 CHANGEOVER UNDER CENTRALISED CONTROL ICON
8
Indicates that the changeover of the installation is under
centralised control assigned to another indoor unit or optional cool/
heat selector connected to the outdoor unit (= master remote
controller).
11 SETBACK ICON
Flashes when the unit is turned on under the setback control.
12 AIRFLOW DIRECTION
Is displayed when the airflow direction and swing are set.
13 CLOCK (12/24 Hours real time clock)
Is displayed when the clock is set. If the clock is not set, - : - is
displayed.
14 DETAILED SELECTION
Is displayed when the detailed display items are selected.
5. Description of the operation modes
1 FAN ONLY OPERATION
In this mode, air only circulates without heating or cooling.
2 DRY OPERATION
In this mode, the air humidity will be lowered with a minimal
temperature decrease.
The temperature and fan speed are controlled automatically and
cannot be controlled by the remote controller.
Dry operation will not function if the room temperature is too low.
3 AUTOMATIC OPERATION
In this mode, the controller will automatically switch between
heating and cooling as required by the setpoint.
4 COOLING OPERATION
In this mode, cooling will be activated as required by the setpoint or
limit operation.
5 HEATING OPERATION
In this mode, heating will be activated as required by the setpoint or
setback operation.
6 VENTILATION (HRV only)
10 11 The ventilation mode operates the HRV; refer to the HRV manual
for more details.
9
7 SETBACK
7
1
Auto
Set to SETBACK is a feature that enables to keep the room temperature
Cool 3
in a specific range when the occupants are out and the
2
Heat
airconditioning is switched OFF.
6 4
For example:
This function not available
 If the room temperature drops below 10°C, heating is started
5
automatically. As soon as 12°C is reached, the controller
returns to its original status.
 If the room temperature goes above 35°C, cooling is started
automatically. As soon as 33°C is reached, the controller
13
returns to its original status.
Auto
The differential can be adjusted in the Setback configuration menu.
12 Room
3
The setback temperature can be set during the unit is turned off on
Cool
14
basic screen or set in the schedule.
Heat
6. Basic operation method
Return Setting
a
Cool
c
a Operation mode
b Temperature:
• When the unit is turned on, Set to indicates the
temperatures that are set for the air conditioner.
• When the unit is turned off, Setback indicates the
temperatures that are set for the setback function.
c Fan speed/Airflow direction
1 Push several times until the desired operation mode Cool,
Heat, Vent, Fan, Dry, or Auto is selected.
2 Push . The operation lamp will light and the system starts
operating.
indicate the current
3 Use to set the temperature.
INFORMATION
indicates that the air cleaning unit
When in Dry or Vent mode, the fan speed can not be set.
4 Push .
5 Use to select fan speed or airflow direction setting.
Air Volume/direction
Air Volume Direction
Low
Return Return Setting Setting
6 With fan speed setting selected, use
fan speed from Low, Medium, or High.
INFORMATION
When in Dry or Vent mode, the fan speed can not be set.
7 With airflow direction setting selected, use
setting to Swing, Pos. 0, Pos. 1, Pos. 2, Pos. 3, and Pos. 4.
0
1
2
3 4
8 Push to display the basic screen.
9 Push . The operation lamp will turn off and the system stops
operating.
Additional features of the controller: KEY LOCK
1 Push for 4 seconds to enable the key lock mode. The key
lock icon is displayed.
Cool
Set to
Return Setting
2 To cancel the key lock mode, push
lock icon disappears.
7. Description of the items in the main menu
1 AIR FLOW DIRECTION (only if the individual air flow function is
installed)
To set the air flow direction for each 4 flaps individually.
2 QUICK START (SkyAir only)
To quickly set the room temperature to a comfortable temperature.
3 VENTILATION
To set the ventilation rate and the ventilation mode (HRV only).
4 ENERGY SAVING OPTIONS
This allows you to restrict the setting temperature range and
display the electricity consumption.
 Setpoint Range Setting
The setting temperature range can be restricted. It is possible
to restrict the temperature range based on a model and the
mode of operation.
 Sensing sensor (Low) (Only if sensing sensor is installed)
This allows you to do a setup which automatically changes the
air conditioning target temperature when there are no people
detected during a fixed time. If people are detected, it will
return to the normal set temperature.
 Sensing sensor (Stop) (Only if sensing sensor is installed)
This allows you to do a setup which automatically stops the air
conditioning function when there are no people detected
during a fixed time.
 Setpoint Auto Reset
Is used to return to the preset temperature after progress of a
definite period of time, even if the set temperature is changed.
 OFF Timer
This allows you to set each operation period of the system in a
range of 30~180 minutes. The system is turned off
automatically after the selected time (each time the system is
activated).
 Electricity Consumption
An indicative electricity consumption until now is displayed.
This enables the customer to evaluate the trend of the
electricity consumption.
Note: Function availability is depending on type of indoor unit.
Set to
Note: This function is not available in case more than 1 indoor
Cool
unit is connected in group to the remote controller.
Note: Displayed electricity consumption is not result of a kWh
b
measurement, but results from a calculation with running data
Return Return Setting
of the unit. Some factors in this calculation are absolute
values, but other factors merely result from interpolations with
tolerance. This explains why the readout may deviate from the
actual electricity consumption.
5 SCHEDULE
To set the startup time and operation stop time for any day of the
week. It is possible to set up to 5 actions per day. Both operation
modes (normal and setback) can be selected. Additionally the
holiday settings and schedule nr can be set.
6 MAINTENANCE INFORMATION
Is used to display the service contact and model info.
7 CONFIGURATION
To set the LCD contrast. You can also switch between standard
and detailed display. When detailed display is selected, the detailed
display settings can be changed.
8 CURRENT SETTINGS
This shows a list of the current settings for the available items.
9 CLOCK & CALENDAR
This allows you to set the date and time. Time can be displayed in
either 12 hour or 24 hour time format.
10 LANGUAGE
Position 0
This allows you to set the displayed language.
8. Air flow direction
For detailed information refer to the Operation Manual on the cd.
to select the desired
9. Quick start (SkyAir only)
1 Display the Main Menu and proceed step (9) to display the basic
screen (Refer to "20. Main menu structure" and "Appendix").
2 Quick Start will appear on the basic screen when the Quick Start
to change the
function is turned ON.
INFORMATION
Repeat this procedure to turn Quick Start function off.
0 4
10. Ventilation setting
1 3
2
Only in case an HRV is connected. Refer to the HRV manuals for
more information.
11. Energy saving options
For detailed information refer to the Operation Manual on the cd.
12. Schedule
12.1 To enable/disable the schedule
1 Display the Enable/Disable setting screen (12.1) (Refer to "20. Main
menu structure" and "Appendix").
2 Use to change the setting to Enable or Disable.
Cool
Schedule
Enable/Disable
Disable
for 4 seconds. The key
Return Setting
3 Push to display the confirmation screen.
4 Use to select Yes and push .
12.2 To select the schedule number
1 Display the Schedule nr set screen (11.2) (Refer to "20. Main
menu structure" and "Appendix").
2 Use to change the setting to Schedule nr 1, Schedule nr 2,
or Schedule nr 3.
Schedule
Schedule nr set
Schedule nr 1
Return Setting
3 Push to display the confirmation screen.
4 Use to select Yes and push .
12.3 To use the holidays
The schedule timer will be disabled for the days that have been set
as holiday.
1 Display the Holidays screen (12.3) (Refer to "20. Main menu
structure" and "Appendix").
2 Use to select the desired day. Push
set the holiday.
Schedule
Holidays
Multiple Selection
Sun Mon Tue Wed Thu Fri Sat
Return Setting
3 Push to display the confirmation screen.
4 Use to select Yes and push .
12.4 To change the schedule settings of the selected schedule
nr
The schedule timer will be disabled for the days that have been set
as holiday.
1 Display the Settings screen (12.4) (Refer to "20. Main menu
structure" and "Appendix").
2 Use to select the desired day (1).
3 Use to highlight the Operation start Time and
the desired Operation start Time (2).
Schedule nr 1
(2)
Time Act Cool Heat
(1)
– 6 :00
Mon
:
:
:
:
Return Setting
4 Use to highlight the action and to select the desired
Act.
Schedule nr 1
Time Act Cool Heat
Mon – 6 :00
:
:
:
:
Setting
ON OFF
3 1 2
INFORMATION (Act column)
There are 3 types of operations:
1. The temperature setpoints can be configured.
2. The setback temperature setpoints can be configured.
3. The temperature and setback temperature setpoints
are disabled.
5 Use to highlight the temperature and to select the
desired value.
INFORMATION (Cool and Heat column)
__: Indicates that the temperature setpoint for cool/heat
and setback temperature setpoint for this time period is not
specified. The last active setpoint will be utilized.
- -: Indicates that the setback function is disabled for this
time period with action OFF.
6 To set a different day of the week, use to highlight the day.
Use to change the day.
7 To copy all actions of the day previously set, push .
8 When the entire schedule settings are completed, push
display the confirmation screen.
9 Use to select Yes and push .
13. Filter auto clean
This function is available only on the model whose panel has
automatic cleaning function of filter. Needs to be set when
operation is OFF.
14. Maintenance information
1 Display the Maintenance Information screen (14) (Refer to "20. Main
menu structure" and "Appendix").
2 The phone number for the Contact info will appear at the top of the
screen. The model info of the Indoor unit and Outdoor unit of your
product will appear on the bottom of the screen.
3 Push to return to the Main Menu.
15. Configuration
15.1 To select the draft prevention
1 Display the Draft prevention settings screen (15.1) (Refer to
"20. Main menu structure" and "Appendix").
2 Use to select Enable or Disable.
3 Push to display the confirmation screen.
4 Use to select Yes and push .
15.2 To select the display mode
1 Display the Display Mode settings screen (15.2) (Refer to
"20. Main menu structure" and "Appendix").
to display to
2 Use to change the setting to Standard or Details.
Display
Display Mode
Standard
Return Setting
3 Push to confirm the setting. Basic screen is displayed.
15.3 To select the detailed display item
1 Display the Display Item settings screen (15.3) (Refer to
"20. Main menu structure" and "Appendix").
2 Use to change the setting to None, Outside Air Temp,
Room Temp or System.
Display
Display Item
None
to set
Return Setting
3 Push to confirm the setting. Basic screen is displayed.
BRC1E52B7
4PW72362-1-21 – 11.2011
to
