Daikin LPM-34 Installation Instructions Manual

LPM-34 NATURAL GAS TO LP GAS
CONVERSION KIT
90% TWO-STAGE FURNACE
INSTALLATION INSTRUCTIONS
ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL,
ADJUST, SERVICE, MAINTENANCE OR REPAIR
(HEREINAFTER, "SERVICE") THE EQUIPMENT SPECIFIED IN
THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
THIS EQUIPMENT IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERN-
ING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE
FOR THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE EQUIPMENT.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR
ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SUPERVISION, SERVICE OR SERVICE
PROCEDURES. IF YOU SERVICE THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY INJURY OR PROPERTY
DAMAGE WHICH MAY RESULT. IN ADDITION, IN
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES
TO SERVICE THE EQUIPMENT SPECIFIED IN THIS
MANUAL, ONLY LICENSED PERSONNEL SHOULD SERVICE
THE EQUIPMENT. IMPROPER SUPERVISION, INSTALLA-
TION, ADJUSTMENT, SERVICING, MAINTENANCE OR RE-
PAIR OF THE EQUIPMENT SPECIFIED IN THIS MANUAL, OR
ATTEMPTING TO INSTALL, ADJUST, SERVICE OR REPAIR
THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT
PROPER SUPERVISION OR TRAINING MAY RESULT IN
PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
Do not bypass safety devices.
RECOGNIZE THIS SYMBOL
AS A SAFETY PRECAUTION
DESCRIPTION
This natural gas to L.P. (liquid petroleum) gas conversion kit
allows White-Rodgers gas valve 36G54 (0151F00000P) and
36J54 (0151M00027) to be used on L.P. gas applications.
Use the following parts list to ensure that all parts listed below
are present and in an undamaged condition. IF ANY DOUBT
EXISTS ABOUT THE CONDITIONS OF ANY COMPONENT
WITHIN THIS KIT, DO NOT USE THIS KIT AND CONTACT
YOUR SUPPLIER FOR A NEW KIT.
WARNING
WARNING
© 2014-2015, 2023
Daikin Comfort Technologies Manufacturing, L.P.
19001 Kermier Rd., Waller, TX 77484
P/N: IO-818B Date: August 2023
PARTS LIST
Quantity Part Number
1
0163F00000P
1
B14933151
1
B40899125
1 IO-818*
1
0151K00000S
1 20328701
1 M0021305
1 20328801
1 W1821016027104
1 0259F00077
1 20346001
1 0140F01167
Field Supplied
1
1
1/2" Pipe (length dependent on model and
1
With the exception of the natural gas burner orifices, all of
the fasteners and other components removed to perform
this conversion are to be reused. Any component found to
be damaged due to this conversion must be replaced with
factory authorized replacement parts before this furnace can
be put into operation.
This furnace is equipped for two-stage heating operation.
The gas valve manifold pressure must be set with first stage
operating at 6" +/-0.3" W.C. manifold pressure and the second
stage must be set at 10" +/-0.3" W.C. manifold pressure. The
accuracy of these pressures must be checked as shown in
steps 25 and 26 of these instructions.
The gas valve is equipped with a 3-pin polarized plug which
prevents this wiring from being installed incorrectly.
Label all wires prior to disconnection when servicing
controls. Wiring errors can cause improper and dangerous
operation. Verify proper operation after servicing.
NOTE: Do not use power tools for any adjustments on
gas valves.
Description
White-Rodgers LP Conversion Kit
F92-1008
Conversion Label
1.25mm Spud Orifice Assembly
Installation Instructions
36G54/36J54 Pressure Check Kit
Valve
Gas Pressure Switch
1/2" x 1/8" Bushing
Two-Stage Harness
Long Jumper Wire
Long Single-Stage Harness
LP Low Pressure Kit Label
Wiring Diagram
1/2" X 1-1/2" Nipple
1/2" Tee
application)
CAUTION
