Summary of Contents for XP Metal Detectors ADX150 Wireless Ready
-
Page 2: Table Of Contents
Contents pages Introduction ............2 Description ............4 Assembly ............5 Alkaline Batteries, Battery Life, Battery Low Alert ..........7 Controls .............. 9 Detecting Techniques ........10 Care Instructions ..........11 Trouble shooting problems ......12 Advice to detectorists ........13 Specifications .......... -
Page 3: Introduction
I N T R O D U C T I O N ONGRATULATIONS ON PURCHASING AN METAL DETECTOR AND WELCOME EXPLORATION! TO THE WORLD OF RESEARCH AND You have invested in a high tech detector with extreme performance, designed and developed in France. - Page 4 I N T R O D U C T I O N ADX150 is been developed and manufactured with quality components and material, thus ensuring your XP detector a maximum useful life. Connector XP : designed to resist movement failures, moulded, completely waterproof, Very resistant Cable, double electromagnetic shield, designed to resist movement failures.
-
Page 5: Description
D E S C R I P T I O N 1 – Full telescopic stem, includes a fibreglass impregnated lower stem. 2 – Robust, waterproof search coil. Diam.9” (22.5 cm), provided with coil cover. 3 - ABS electronics box 4 –... -
Page 6: Assembly
A S S E M B L Y The assembly of your detector will only take you a few seconds. Put the shaft together as shown on the diagram. Put the rubber washers on the side of the fibreglass tube (1). Insert the fibreglass tube on the search head (2). - Page 7 A S S E M B L Y To hold the cable along the telescopic stem you can use Velcro® strip as shown on the photo below(C & D). Option 2 : Electronic box hipmounted Insert the control box into the hipmount bag. Then insert the connector (female) in its panel connector (male) and screw it.
- Page 8 A L K A L I N E R E C H A R G E A B L E B A T T E R Y , B A T T E R Y L I F E , B A T T E R Y L O W A L E R T...
-
Page 9: Battery Low Alert
A L K A L I N E R E C H A R G E A B L E B A T T E R Y , B A T T E R Y L I F E , B A T T E R Y L O W A L E R T... -
Page 10: Controls
C O N T R O L S START I/O, SENSITIVITY _____________ Turn the machine on with the SENSITIVITY I/O control. You will hear some quick "beeps" which will tell you that the detector is correctly operating. Then you can detect. Avoid testing your detector inside your house or in shops because you can encounter a lot of metallic and electromagnetic pollution (reinforced concrete,... -
Page 11: Detecting Techniques
D E T E C T I N G T E C H N I Q U E S ADX150 is a motion detector, which means that a target detection can be carried out only when the search coil is moving. When you detect an area, it is important to sweep with the head as close as possible to the ground with wide movements, but not making contact with the ground. -
Page 12: Care Instructions
C A R E I N S T R U C T I O N S Our detectors are designed to be as robust as possible, however, like any electronic precision instrument, they require some care. The XP search coil cable has been designed so as to resist long term movement. -
Page 13: Trouble Shooting Problems
T R O U B L E S H O O T I N G P R O B L E M S ROUBLE AUSES OLUTIONS Low batteries. Change the batteries . The sound changes its tone, it becomes more Check if you have correctly high pitched when Polarity of the batteries is... -
Page 14: Advice To Detectorists
A D V I C E D E T E C T O R I S T S Detecting is an activity, which like other leisure activities requires some guiding principles. These few recommendations will allow you to fully enjoy it while respecting laws, environment and other people. -
Page 15: Specifications
S P E C I F I C A T I O N S ATTERIES 8 AA Alkaline batteries. Rechargeable batteries NiMh 2300 mA can be used instead of Alkaline batteries. LECTRONIC BOX ABS electronic box. It can be worn under the armrest or hip-mounted. EARCH COIL Wide scan (Double D), Diameter : 9”... -
Page 16: Xp Accessories
A C C E S S O R I E S Standard Search coil DD 9” (22.5 cm) provided with coil cover Search coil DD High Energy 11” (27 cm) provided with coil cover Elliptical Search coil 5” x 10” (11/24cm) provided with coil cover Concentric search coil 10”x8”... - Page 17 A C C E S S O R I E S XP transport bag Batteries charger Wireless Headphone WS2 2 Channels Specially designed for XP Metal Detectors. Wireless Headphone WS3 Specially designed for XP Metal Detectors. WS2 and WS3 specifications 2 selectable channels.
-
Page 18: Warranty Conditions
W A R R A N T Y C O N D I T I O N S ADX150 – 5 YEARS LIMITED WARRANTY XPLORER ensures a contractual warranty from the date of purchase: 5 years on the electronic box, the search coil, detector shaft and its components (armrest, twist lock…) and on the battery charger. - Page 19 D D eclaration of conformity for E.C This declaration is the responsibility of manufacturer: XPLORER Sarl – ZI DE VIC – 8 rue du développement 31320 CASTANET TOLOSAN - France This certifies that the following designated product is in conformity with EEC directives 2004/108/CE &...
