XP Metal Detectors DEUS V4 Manual

Updates to the V3.0 manual
• Reactivity 2.5, this new reactivity level is fast and deep, offering a good compromise especially when
searching new terrain.
• Program No10 GOLD FIELD : Improved Audio Response and reactivity.
Goldfield will give excellent results especially when combined with the new HF coils...Now difficult
targets can easily be detected in mineralized ground. The Tone menu has been removed.
• Lower discrimination range : For those who want more control over ferrous targets.
Negative discrimination of 0 to -6.4 makes it possible to locate previously rejected ferrous items, the
lower discrimination range can also enhance the signature from deep targets which may have in the
past been ignored. These new options also offer a big advantage when searching for specific targets
such as ceramics or even meteorites.
• Ground Effects: Improved Tracking.
• Improved display and signal processing compatible with the new HF 21 frequencies. The display now
has the ability to handle detection frequencies up to 81kHz (18kHz before), now with 7 frequency
offsets (compared to 3 previously).
• DEUS is now compatible with a smartphone: Target information and other data can be sent by radio
link to a smartphone. An app will soon be available to unlock these features.
• New program No9 "HOT" : "Pro setting" this is a find everything program, based on the Full Tone audio
mode with a very low discrimination. Hot is a very interactive program offering excellent feedback and
target information.
• New program No6 "DEEP": "Pro setting" for locating deep targets, with moderate discrimination and
specific signal processing.
• Improved Non motion / static mode: Non motion modes are now more advanced offering better
overall performance, with an improved sensitivity to small targets.
• New processing : Dual processing power improves navigation and a range of other parameters.
remote and headset battery life has slightly decreased to 18 and 20 hours respectively.
• Normalization display is now a menu feature on the WS4 and WS5 headphones.
• The headset volume is now stored when switched off.
• The coil name in the coil menu have gone, the serial number is now used as the coil reference.
• Erasing a coil from the list is done by replacing all characters with 0.
• Audio tone can now be raised up to 993 hertz
• Target Normalization mode is on by default (Normalization is not active with HF coils)
• When turning OFF the remote control to use only the wireless headphone, the coil restart
New Optional High Frequency coils:
14 kHz
13 < >15.7
30 kHz
26 < > 31
55 kHz
50 < > 59
22.5cm HF Elliptical HF 24 x 13 cm
Interchangable battery mounted in the lower stem
The v4 manual is available soon from our web site:
www.xpmetaldetectors.com
14 kHz
HF COILS Battery
13 < >15.7
Frequency 14 kHz
30 kHz 20 hours
26 < > 31
80 kHz
Frequency 30 kHz
27 hours
68 < > 81
Frequency 55 kHz
28 hours
Frequency 80 kHz
28 hours
NEW PROFILE : OSCILLOSCOPE XY DISPLAY
OPTION > CONFIGURATION > PROFILE
OSCILLOSCOPE DISPLAY XY: The target signature is displayed on an oscilloscope.
PROFILE
The XY screen provides a visual assistance and may improve the identi cation of
di cult targets.
XY
GRAPHIC
For example: The identi cation of targets that do not have a precise signature
ID NORM.
(some ferrous, cans ...). The XY pro le can be selected as the default display.
The display magni cation of the XY trace has 10 levels of adjustment using the
Zoom function.
Alternating display
Between target reading
and battery level.
Display Area for
Ferrous targets
Display Area for
Non-ferrous targets
XY screen target examples :
6 - DEEP
GB
Typical non ferrous
Signature for coins.
6 - DEEP
OPTION MENU GB
Typical signature for cans and di cult to reject large ferrous items.
Zoom XY mode
3 - DEUS FAST
Press the Pinpoint button for 2 seconds to display the zoom function.
zoom 4x
Adjust the zoom by pressing the
OPTION MENU GB
Corrections and modi cations to the V3 manual
Ground phase reading
6 - DEEP
F NF
Display Area for
Non-ferrous targets
NF
F Display Area for
Ferrous targets
OPTION MENU GB
6 - DEEP
OPTION
OPTION MENU GB
Typical signature for
Typical non ferrous
signature for foil.
6 - DEEP
OPTION MENU GB OPTION
Typical signature from
ferrite and ceramics.
or key
6 - DEEP
MENU GB
rejected ferrous.
6 - DEEP
MENU GB
