AWS Bioweight Manual

Wireless body fat scale 330lb x 0.2lb 150kg x 0.1kg
Hide thumbs

Advertisement

Quick Links

Download this manual
W i r e l e s s B o d y F a t S c a l e
330lb x 0.2lb
150kg x 0.1kg
1

Advertisement

loading

Related Manuals for AWS Bioweight

Summary of Contents for AWS Bioweight

  • Page 1 W i r e l e s s B o d y F a t S c a l e 330lb x 0.2lb 150kg x 0.1kg...
  • Page 2 BioWeigh-IR Manual Thank you for purchasing the American Weigh BioWeigh- IR Wireless Body Fat Scale. Please read all operating instructions carefully before use. Scales are precision instruments and should always be handled with care. Special Note on Body Fat Scales Body fat scales and analyzers use bioelectrical impedance analysis (BIA) technology to calculate body fat %.
  • Page 3 I. Remote Display Overview DOWN ST LB KG ft cm MODE II. Key Functions DEL - Delete the current record DOWN - Down key; Scrolls down through records; Press and hold to change the clock faster during clock setup. UP - Up key; Scrolls up through records; Press and hold to change the clock faster during clock setup.
  • Page 4 III. Battery Installation This scale should come with batteries in the box. To install the batteries, turn the scale over and remove the battery cover. Insert two (2) AAA batteries according to the diagram inside the battery compartment. Replace the battery cover.
  • Page 5 value. Now press to accept. • The hour will begin to flash. Press and to adjust the value. Now press to accept. • The minute will begin to flash. Press and to adjust the value. Now press to accept. The display will return to clock / temp.
  • Page 6 • Press to edit height. Use and change the value. • Press to edit age. Use and change the value. • Press to confirm. • You may now stand on the scale’s metal contacts (barefoot). • Your weight will be displayed briefly then the scale will begin body fat analysis.
  • Page 7 NOTE: If no record is found ! will be displayed. X. Deleting Records To delete a single record while in Record Inquiry Mode: • Press the key once • icon will flash on the display. • Press and hold for 2 seconds until the icon stops flashing.

  • Page 8: Icon Descriptions

    <28 28-37 37-47 >47 <17 17-25 26-34 >34 Body Water % Female Male Healthy Healthy 10-12 >60 >64 13-18 >58.5 >63.5 19-30 >56 >62.5 31-40 >53 >61 41-50 >52 >60 51-60 >51 >59 >50 >58 Body Muscle % Female Male Healthy Healthy 10-99...

  • Page 9: Troubleshooting

    Icon Delete Record No Record Description Overweight Batteries Record Saved Found XIII. Troubleshooting If in the process of using the scale, the receiver stops working properly, place the receiver on the platform of the scale and press or to enter weighing mode. Then place at least 30lbs of weight on the scale to turn it on.
  • Page 10 Model BIOWEIGH-IR Capacity 150kg / 330lb / 23st:8lb Resolution 0.1kg / 0.2lb / 0.2lb Weighing Units kg, lb, st:lb Memory 10 User Memory; Stores up to 365 records per user. Record includes: year, month, day, weight, fat, water, muscle, and bone Body Analysis Ranges body fat range: 0~80% body fat graduation: 0.1%...
