  • Page 1 UMH-150 Integrated Receiver Decoder User Manual Wellav Technologies Ltd...
  • Page 2: Table Of Contents

    Table of Content Safety ..........................2 Reference .......................... 3 Features ..........................4 Introduction ........................5 ......................5 RONT ANEL ......................5 ANEL ....................6 IN AND ....................... 7 IN AND ....................7 IN AND CVBS ....................8 IN AND ..................... 8 IN AND Front Panel Control &...
  • Page 3: Safety

    Safety  To avoid electric-shock hazards, do not open the receiver; refer service to qualified personnel only.  Keep the receiver away from flower vases, tubs, sinks, etc., in order to avoid damaging the equipment.  Do not expose the receiver in the sunlight. And keep it away from the heat source. ...
  • Page 4: Reference

    Reference  Connect DiSEqC 1.0/1.2/2.0 The receiver is designed to be DiSEqC 1.0/1.2/2.0 compatible. This allows multiple antennas to be connected to the receiver simultaneously. If you have two or more fixed antennas or LNBs, you can use a DiSEqC 1.0/1.2/2.0 switch. 1.
  • Page 5: Features

    Features  MPEG-2 Digital & Fully DVB-S ETSI/EN300 421 compliant  Input Frequency 950-2150 MHz, Symbol Rate 2 ~ 45 Ms/s  1 LNB Input (F-Type) and Loop-through IF Signal.  2 DVB Common Interface (CI ) for descrambling most common CA system. ...
  • Page 6: Introduction

    Introduction The UHM150 IRD is an advanced MPEG-2 DVB integrated receiver decoder with optional TS-IP mutual conversion function. It can receive signal from different program sources. Its prolific output interface such as IP, SDI, XLR and ASI can meet different system requirements.
  • Page 7: Rf In And Asi Out

    2. TUNER OUT (LOOP OUT): Use it when connecting to another IRD (IF loop through output from digital tuner). 3:ETHERNET : Network remote control. 4. RS-232: Connect to a personal computer for software upgrade. 5. ASI OUT: Output the standard MPEG-2 TS. 6: SDI OUT: Output the SID signal 7.
  • Page 8: Rf In And Ip Out

    2. Motorized System (DiSEqC 1.0/1.2/2.0)  Connect the coaxial cable from the REC of your motorized system (DiSEqC 1.0/1.2/2.0 Motor) to the LNB IN socket on the STB.  Connect the coaxial cable from the LNB to the LNB connector in the DiSEqC 1.0/1.2/2.0 motor.
  • Page 9: Rf In And Cvbs Out

    RF in and CVBS out IP in and ASI out UMH 150 Integrated Receiver Decoder User Manual...
  • Page 10 UMH 150 Integrated Receiver Decoder User Manual...
  • Page 11: Front Panel Control & Operation

    Front Panel Control & Operation This diagram is for DVB-C and DVB-T IRD UMH 150 Integrated Receiver Decoder User Manual...
  • Page 12 This diagram is for DVB-S and DVB-S2 IRD UMH 150 Integrated Receiver Decoder User Manual...
  • Page 13: Input

    Input In this menu, there are two submenu used to select the input source and configure the input parameters. They are SOURCES and PARAMS. Sources In this submenu, there are three options, TUNER,ASI and IPTV. TUNER: when select this item, the receiver will search the signal from the tuner (from LNB).
  • Page 14: Output

     IP Board IP Address: Default setting.  IP Board SubNetMask: Default setting.  IP Board MAC Address: Default setting. Notice: When two or above pieces of UMH150 are working in IPTV at the same time, you’d better set different ‘IP Board IP Address’ and ‘IP Board SubNetMask’ for each equipment.
  • Page 15: Sdi

    Audio: Configure the audio parameter  Audio:0-99  Audio mode: include Stereo, Left, Right, Mono, Dual  Audio Language: Select different audio language. SDI setup: When use SDI output, you need to setup these parameters  Audio PID: Setup the audio PID, the range is 0-99. ...
  • Page 16: System

    System Under this menu, there are three submenu include Local Setup, Properties and Factory Setting. Local Setup  IP address: Local IP setting for connecting to the server. This IP and the server’s IP should be in the same section. ...
  • Page 17: Nms Control & Operation

    NMS Control & Operation Except using the front panel to configure and operate the equipment, UMH150 also supplies the network management function. When you get the equipment, there should be a CD contain the network management software with it. If you want to use the network management software to control and operate the equipment, please copy the software form the CD to your server (Computer).
  • Page 18 Login Interface Chang the Password UMH 150 Integrated Receiver Decoder User Manual...
  • Page 19: Nms Main Interface Configuration

    NMS Main Interface Configuration After successfully logging in, the main interface will display as below: DVB-S (MainBoard) On the main interface of the network management software, there are two menus including twelve parts. All these parts are the same as the front panel display. Main Board: Ⅰ...
  • Page 20 DVB-S2 (MainBoard) DVB-C/T (MainBoard) UMH 150 Integrated Receiver Decoder User Manual...
  • Page 21 DVB-S/S2/C/T (Ethernet)  Symbol rate: Every transponder have one symbol rate, you can get this parameter from the satellite programs provider.  LNB Voltage: LNB need the power supply, for receiving the programs from different band ( C band or Ku band), the LNB need different power supply, the receiver can supply the power to the LNB.(13V is for C band, 18V is for Ku band) ...
  • Page 22 NTSC, PAL.  Screen Mode: set the screen aspect ratio in this item, include Auto, 4:3 Full, 16:9Full and 4:3Letter box.  DVB subtitle Language: DVB subtitle language  EBU subtitle Language: EBU subtitle language  Fail Mode: include Black Screen and Still Screen. Black screen: when the receiver lost the signal, keep the screen black.
  • Page 23 Ⅷ. Programs play In this box, select the programs you want to play, and then click “SendData” button to save the parameters, the programs you select will be played. Ⅸ . Status This box is used to display the information about palying program, CI slot, Tuner status and TS rate.
  • Page 24 Ⅺ. Transmitter  ChannelSelect: Set up the channel number where you want to transmit programs.  EnableChannel: Enable or disable the channel.  Protocol: Optional UDP or RTP.  EncapNum TSPackts: Configuration range is 1—7.(7 is recommended).  TypeOfService: It includes Normal, Min onetary, Max reliabiability, Max Throughput, Min delay.
  • Page 25: Troubleshooting

    Troubleshooting Problem Possible causes What to do The display on the front Check that the main cable is No power. panel does not light up. plugged into the power socket. The unit is in standby mode Check the output connection or The front panel red light is or no output connection.
  • Page 26 Problem Possible causes What to do Signal is good. But No The picture and audio are Change to a FTA channel. picture and no audio. scrambled. The system is connected with RF leads and the There is interference on Change the receiver output output channel of the your digital satellite channel to a more suitable...
  • Page 27: Specifications

    Specifications Frequency Range 950~2150MHz Symbol Rate 2~45Mband Tuner Signal Strength -65~-30dBm FEC Mode Rate Demodulation 1/2,2/3,3/4,5/6,7/8QPSK Audio Decoding MPEG layer I & II Audio Audio Mode Mono/Dual Channel/Stereo Connectors RCA (L , R) Video Decode MPEG-II ISO/IEC 13818-1 Input Bit Rate <=15Mbps Output System PAL/NTSC/SECAM...
  • Page 28: Optional Models

    Optional Models UMH150F UMH150CI UMH150IP Model Function DVB-S input/loop through √ √ √ output DVB-C input/loop through √ √ √ output DVB-T input/loop through √ √ √ output DVB-S2 input/loop √ √ √ through output IP input √ √ √ √...
