CleanFreak CPL17FB Owner's Manual page 5

1) Place cord wrap assembly (2 pieces) in place and snug them together
with 6mm hex bolt. (Actual cord wrap faces to the left of the machine when
you are standing behind it.)
2) Assemble hardware in the following order: spacer, left handle bracket,
nylock nut. (Do not over tighten nylock nut, only tighten it enough to hold
handle in place when compression lever is in the down position.)
1) Connect power cords together.
2) Connect power cord covers together.
1) Remove nut and space from handle bracket
assembly.
2) Push the two handle brackets forward so
they lean against the motor.
5
1) Remove handle clamp blocks
with 5 mm hex head bolts.
2) Place handle assembly into
handle clamp blocks.
3) Reattach the blocks to the
base with 5mm hex head bolts.
