- Page 1 User’s Manua - Model #MFC1045S-SN35C WINSONIC ELECTRONICS Co., LTD No.290-1, Wen Chung Rd., Taoyuan City, Taiwan, R.O.C l:+886-3-3704789 ax:+886-3-3704722 E-mail:sales@ewinsonic.com www.ewinsonic.com...
-
Page 2: Table Of Contents
Contents Safety Instruction Product Installation Panel Specification General Description Absolute Maximum Ratings Optical Specifications Electrical Specifications Precautions AD Board Specification Assembly Trouble Shooting... -
Page 3: Safety Instruction
Safety Instruction Read and follow these instructions when connecting and using your LCD monitor: Operation: 1. Keep the monitor out of direct sunlight and away from stoves or any other heat source. 2. Remove any object that could fall into ventilation holes or prevent proper cooling of the monitor＇s electronics. -
Page 4: Product Installation
Product Installation 1. Switch off the power on both your monitor and your computer. The Power Switch is located in the right of the monitor. 2. Connect the power cord to the AC outlet, and connect the power to the monitor through the AC/DC adapter. -
Page 5: Panel Specification
GENERAL DESCRIPTION DESCRIPTION MFC1045S-SN35C is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching devices. This model is composed of a TFT LCD panel, a driver circuit and a back-light system. The resolution of a 10.4 〃 contains 800 x 600 pixels and can display up to 262,144colors. -
Page 6: Absolute Maximum Ratings
Panel Specification MECHANICAL INFORMATION MIN. Horizontal (H) 226.0 226.5 225.5 Module Vertical (V) 177.3 177.8 178.3 size Depth (D) 10.5 Weight 1. ABSOLUTE MAXIMUM RATINGS 1.1 ABSOLUTE RATINGS OF ENVIRONMENT SYMBOL MIN. MAX. Storage temperature °C Operating temperature °C (Temperature of glass surface) (2),(4) Shock ( non-operating ) Snop... -
Page 7: Electrical Absolute Ratings
Panel Specification 1.2 ELECTRICAL ABSOLUTE RATINGS (1) TFT LCD MODULE ( Vss = GND = 0 V) MIN. MAX. UNIT NOTE SYMBOL ITEM Power Supply Voltage Vss -0.3 ( 1 ) ( 1 ) Logic Input Voltage Vss -0.3 +0.3 NOTE (1) Within Ta = 25 ±... -
Page 8: Optical Specifications
Panel Specification 2. OPTICAL CHARACTERISTICS The following items are measured under stable conditions. The optical characteristics should be measured in a dark room or equivalent state with the methods shown in Note (5). Measuring equipment : TOPCON BM-5A * Ta = 25 ± 2°C , V =3.3V, fv= 60Hz, f =40MHz, I = 6.0 mA... - Page 9 Panel Specification Note 1) Definition of Viewing Angle : Viewing angle range(10 C/R) Normal Line φ= 0° θ= 0° θ θ φ 12 O’clock φ direction θ = 90 φ 6 O’clock direction θ = 90 φ Note 2) Definition of Contrast Ratio (CR) : Ratio of gray max (Gmax) ,gray min (Gmin) at center point Gray max(Gmax) Gray min(Gmin)
- Page 10 Panel Specification Note 5) After stabilizing and leaving the panel alone at a given temperature for 30 minutes, the measurement should be executed. Measurement should be executed in a stable, windless,and dark room. 30 minutes after lighting the back-light. This should be measured in the center of screen. Lamp current : 6.0 mA Environment condition : Ta = 25 ±...
-
Page 11: Electrical Specifications
Panel Specification 3. ELECTRICAL CHARACTERISTICS 3.1 TFT LCD MODULE Ta = 25 ± 2°C ITEM SYMBOL UNIT NOTE Voltage of Power Supply Differential Input +100 High Voltage for LVDS Receiver Threshold -100 Vsync Frequency Hsync Frequency 37.879 Main Frequency 40.0 DCLK Rush Current RUSH... - Page 12 Panel Specification *c) Vertical stripe pattern R G B 5) Rush current measurement condition 3.3V 2SK1059 LCD INPUT) DD ( FUSE CONTROL SIGNAL (HIGH to LOW) 2SK1399 10000pF rising time is 470us 3.3V 0.9V 0.1V 470us...
-
Page 13: Backlight Unit
Panel Specification 3.2 BACKLIGHT UNIT The back-light system is an edge - lighting type with a single CCFT ( Cold Cathode Fluorescent Tube ). The characteristics of a single lamp are shown in the following tables. Ta=25 ± 2°C ITEM SYMB UNIT NOTE... -
Page 14: Block Diagram
Panel Specification 4. BLOCK DIAGRAM 4.1 TFT LCD MODULE Connector : DF19L-20P-1H Timing User LVDS Controller Connector DF19L- DS90CF364 20P-1H Source 10.4” SVGA Drive TFT-LCD Panel DC-DC Gamma Converter Generator VCOM Generator Video Signal R-String Control Signal Gate VCOM Source/Gate Drive Gamma Connector... -
Page 15: Input Terminal Pin Assignment
Panel Specification 5. INPUT TERMINAL PIN ASSIGNMENT 5.1. Input Signal & Power (LVDS, Connector : DF19L-20P-1H : Hirose) FUNCTION POWER SUPPLY +3.3V POWER SUPPLY +3.3V GROUND GROUND RxIN0- LVDS Differential Data INPUT Negative R0~R5,G0 RxIN0+ LVDS Differential Data INPUT Positive GROUND RxIN1- LVDS Differential Data INPUT... - Page 16 Panel Specification 5.2 LVDS Interface : Transmitter DS90CF363 or Compatible Pin No. Name RGB Signal Pin No. Name RGB Signal TxIN0 TxIN11 TxIN1 TxIN12 TxIN2 TxIN13 TxIN3 TxIN14 TxIN4 TxIN15 TxIN5 TxIN16 TxIN6 TxIN17 TxIN7 TxIN18 TxIN8 TxIN19 TxIN9 TxIN20 Enable TxIN10 TxCLK IN...
- Page 17 Panel Specification 5.3 BACK LIGHT UNIT Connector : JST BHSR - 03VS -01 Mating Connector : JST SM02(8.0)B-BHS Pin NO. Symbol Color Function PINK High Voltage COLD WHITE Low Voltage 5.4 Timing Diagrams of LVDS For Transmission LVDS Receiver : DS90CF364A or Compatible TxCLK OUT RxCLK IN Rx IN2...
- Page 18 Panel Specification 5.5 Input Signal,Basic Display Colors and Gray Scale of Each Colors DATA SIGNAL GRAY COLOR DISPLAY SCALE GREEN BLUE LEVEL R0 R1 R2 R3 R4 R5 G0 G1 G2 G3 G4 G5 B0 B1 B2 B3 B4 B5 BLACK BLUE GREEN...
- Page 19 Panel Specification 5.6 PIXEL FORMAT Line 1 R G B R G B R G B R G B LTA104S1-L01 Panel Line 600 R G B R G B R G B R G B...
- Page 20 Panel Specification 5.7 Power ON/OFF Sequence : To prevent a latch-up or DC operation of the LCD module, the power on/off sequence should be as the diagram below. 0.9 V 0.9 V Power Supply 0.1 V 0.1 V 10 msec 50 msec 50 msec 1sec T...
-
Page 21: General Precautions
Panel Specification 6. GENERAL PRECAUTIONS 1. Handling (a) When the module is assembled, It should be attached to the system firmly using every mounting holes. Be careful not to twist and bend the modules. (b) Refrain from strong mechanical shock and / or any force to the module. In addition to damage, this may cause improper operation or damage to the module and CCFT back-light. - Page 22 Panel Specification 2. STORAGE (a) Do not leave the module in high temperature, and high humidity for a long time. It is highly recommended to store the module with temperature from 0 to 35 °C and relative humidity of less than 70%. (b) Do not store the TFT-LCD module in direct sunlight.
-
Page 23: Ad Board Specification
AD Board Specification LCD monitor GTR24 OSD operation Control Functions The Monitor control functions are located on the lower side of the panel. The control key description 1. MENU Activate the on-screen-display function ∇ Down / Brightness control ∆ Up / Brightness control Auto AUTO-ADJUSTMENT Power Switch... -
Page 24: Adjustment Procedure
AD Board Specification DJUSTING THE MONITOR The LCD monitor is designed to work with a range of compatible video adapters on the market. Due to the possible deviations between these video adapters, you may make some adjustment to fit the monitor for adapter used. -
Page 25: Brightness Adjustment
AD Board Specification AUTO-ADJUSTMENT WE STRONGLY RECOMMEND THAT YOU USE THIS ITEM TO GET THE OPTIMIZED VISUAL QUALITY. Use the ∇ & ∆ key to select auto-adjustment, and then press Menu Key to get the optimized quality. Or press Auto Key to get the optimized directly. ... - Page 26 AD Board Specification best Screen Settings optimization. H.Position ∇ ∆ Use the & key to select the H.Position item, then press Menu Key to get the best optimization. Use the ∇ & ∆ key to adjust H.Position value. Then press menu key to confirm.
- Page 27 AD Board Specification Phase ∇ ∆ Use the & key to select the Phase item, then press Menu Key to get the best optimization. ∇ ∆ Use the & key to adjust increase or decrease video Quality of the picture. ...
-
Page 28: Language Setting
AD Board Specification Auto Gain ∇ ∆ Use the & key to select Auto Gain, then press Menu Key to get the best color optimization that will be activated the auto adjusting input video color level for the picture. sRGB ∇... -
Page 29: Osd Setting
AD Board Specification OSD Setting ∇ ∆ Use the & key to select the OSD Setting item, then press Menu Key to get the item, t OSD setting selection. You could set up the property of Position, Display Timer, and Transparency of OSD menu. ... -
Page 31: Trouble Shooting
Trouble Shooting If your monitor fails to operate correctly, consult the following chart for possible solution before calling for repairs/RMA. Condition Possible Solution The screen is not synchronized? 1. Check if the signal cable is firmly seated in the socket. 2.
