The manual provides us with general principles and methods concerning the
introduction of PTZ Domes' operation and installation. Please have a careful reading
before making installation.
This integrated PTZ Dome series, with built-in DSP of high performance, can combine integreated
camera and decoders. It adopts pan-digital controlling, ensuring a flexible program. Reaching all-round
and complete clearance monitoring in the true sense, due to high-accuracy rotating system, freely and
fast position and successive track scanning. Exview performance makes it possible to adapt all the
environment (bright / dark) and different goals (far / near). In other words, it belongs to one kind of
integreated design with a system of high reliability.
This series can combine many protocols, such as PELCO-P/D and so on. The specific operation may
vary while using different systems. And we should take the present system as basis. Concerning the
specific operation details, please contact system manufacturers and the corresponding distributors
directly!
1. Don't take it apart freely
To prevent electric shocks, don't separate screw
or housing。
All the componence of the machine must be
prepared by the professionals。
As for the maintenance, it should be carried out
by qualified experts。
2. Please use the camera carefully
Don't use it as you like, to avoid striking and
shocking, be sure to use or store it appropriately。
3. Don't expose the camera to rain or
moisture (except outdoor used model)
It is designed inside of the house, so be sure to
avoid rain and moisture。
Turn off the power supply and maintain it by
qualified person。
The moisture may affect the cameras and lead to
electric risk。
English
Preface
Safty Announcements
4. Don't install indoor PTZ Dome outside
the house
It may influence the life expectation of the dome
5. Don't use intensified or grinded detergent
to clean it
Please use dry and soft clothto clean it when it
isdirty. If seriously dirty, please use moderate
detergent. Pay more attention to its appearance
while cleaning and erase the remains.
6. Don't aim at the sun
Be sure not to aim it at the sun or any other
brightobjects, whether in use or not. Or, it may
cause the pisture unclear.
7. Avoid exposing it to the light source or
hard light too long
If the facula appears on the screen due to the light
source, the image may fade to some extent
1
