  • Page 1 Visualizer DC450 Document Camera User Manual English TS-82-913-90010...
  • Page 2 • Welcome: Thanks for purchasing this product. Please read the instructions carefully before using this product. • FCC Compliance Statement (Class A): This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received;...
  • Page 3 Warning 1. Do not look directly at the LED light source, which may cause retinal damage. 2. Carry the product by holding the base of the main unit in both hands. Never hold the product by the arm or the camera head only. 3.

  • Page 4: Preparing The Document Camera

    Preparing the Document Camera Knowing the Document Camera Parts Gooseneck Arm HDMI Intput Port Microphone Remote Control Signal Receiver LED Lamp Antitheft Slot Camera Head Remote Control Signal Receiver DC 5V Power Socket Control Panel VGA Output Port Speaker VGA Input Port SD Card Slot HDMI Output Port USB Port...

  • Page 5: Control Panel

    Control Panel Button Function Button Function Zoom out Power On/Off. Zoom in Invert image 180°. Macro/Normal switch. One-time auto focus Pass the signal from PC via RGB Freeze the current image. input port to RGB output port. Turn on/off the LED lamp and Capture a still image.

  • Page 6: Remote Control

    Remote Control Button Function Button Function Brightness hotkey Increase / decrease the sound volume. Power on / off Picture in Picture function on / Freeze current image. off *For displaying a still image as * Pause the clip while playing videos an insert while displaying another image.

  • Page 7: Rotate Function

    Setting Up This section provides useful tips on how to adjust the document camera smoothly for your needs. Rotate Function Roll the lens rotator to rotate image 90° 90° Illumination Lamp If you are in a dark environment, please turn the LED lamp on to make better exposure.

  • Page 8: Working Area

    Working Area ▶ working area Height 18.5” for Max. working (16.54”x 11.69”) 16.54” If the document is not put in the recommend working area, the image should be rotated by FLIP button ( ) on control panel or remote control. Minimum height 7.09”...

  • Page 9: Adjusting The Brightness

    Adjusting the brightness 1. Press BRIGHTNESS button on the control panel ( ) or remote control ( 2. Use ( ) buttons to increase or decrease the brighness level. Zoom Function Use the Zoom buttons ( ) to zoom in or zoom out the screen. Flip Function Press the Flip Button ( ) to flip image...

  • Page 10: Adjusting The Focus

    Functions indicated by can only be used by the remote control. Adjusting the Focus ▶ Automatic Focus Press AF button ( ) to do an one-time auto focus. This function provides a one-time auto- focus. ▶ Manual Focus Use the manual focus buttons ( on remote control to finetune the focus.
  • Page 11 Adjust the White Balance 1. Default white balance setting of the document camera is “Auto”. 2. There are various modes (Auto, Flurescent, Tungsten and Custom) for user to choose and fit in different surroundings. 3. Custom white balance: Press “MENU” ( ) button →...
  • Page 12 Inserting and Ejecting a SD / SDHC card (Not supplied) 1. Insert a memory card (SD/SDHC/MMC/MMC 2.0) with the label facing up until it reaches the end of the slot. 2. When the card is inserted successfully, the icon ( ) will appear on screen and the internal memory will become inaccessible.

  • Page 13: Making The Connections

    Making the Connections System Diagram Step 1 / Plugging in the Power Outlet Use power adapter to connect DC IN connector on the product to a standard 100V~240V AC power outlet. The type of power adapter is depending on your countries / regions. Step 2 / Output Resolution and Aspect Ratio.

  • Page 14: Step 2 / Connecting With Components

    Step 2 / Connecting with Components Product Display Cable PC Port Port Device Port RGB OUTPUT RGB INPUT RGB INPUT RGB OUTPUT Mini HD HDMI-INPUT HDMI Mini HD HDMI- OUTPUT TYPE A Port TYPE A Port TYPE B Port ▶ Standard TV and Projector •...

  • Page 15: Connect To A Computer

    Connect to a computer ▶ Passthrough Function Use VGA Cable to connect VGA IN connector on the document camera to the VGA OUT connector on the computer ▶ Use HDMI Cable to connect HDMI IN Connector on the document camera to the HDMI Out connector on the computer. To display computer image, press PASSTHROUGH button ( ) on the control panel.

  • Page 16: Basic Operation

    Basic Operation 1. Press MENU button on the remote control ( ) or control panel ( 2. Press ( ) button to toggle between tabs. 3. Press OK button on the remote control( ) or control panel( ) to make a selection and display the setting selections.
  • Page 17 Name icon Option Description 0.8M / 2M Still Resolution Select the desired still image resolution. 5M / 8M Beep On / Off Enable beep sound on / off Set flicker frequency to 50Hz or 60Hz Flicker 50Hz / 60Hz The flicker setting is based on the frequency standard of your local power supply.
  • Page 18 Functions indicated by can only be used by the remote control. Recording a video clip / Taking a still picture 1. Set the caputre or record resolution. aceording to the setting, please refer to the table below: Output Switch Resolution Setting Capture resolution Recording resolution 1024 x 768...
  • Page 19 Copying Files to Computer Please notice that the video clips are recorded in AVI format and are compiled as CLIPxxxx.avi (xxxx are four serial numbers). Before viewing these videos on your PC, you may need to install some media programs. 1.

  • Page 20: Advance Operation

    Functions indicated by can only be used by the remote control. Advance Operation Highlight function / Mask function( ) Highlight function 1. Use the Highlight function to draw attention to a particular section of the output image. 2. Press the Highlight button ( ) on the remote control, and use the direction buttons to move the highlighted area.

  • Page 21: Connect To A Microscope

    Connect to a microscope Connect to a microscope enables you to examine microscopic objects on a big screen. 1. Adjust the microscope and focus objects. 2. Choose an appropriate micoscope adapter. 3. Microscope adapter accessaries are applicable to Ø28mm ,Ø31mm, Ø33mm, and Ø34mm eyepieces.
  • Page 22 Functions indicated by can only be used by the remote control. 5. Switch the focus mode to Macro. Press MENU ( )--> select Focus ( ) --> select Macro or press Macro button ( ) on remote controller. 6. Connect the lens with microscope adapter to the microscope.
  • Page 23 Storing 1. Power off the product. 2. Unplug the AC adapter from the wall outlet. Then , disconnected the AC Adapter and all cables. 3. Fold the camera head and arms in the direction shown in the figure.

  • Page 24: Troubleshooting

    Troubleshooting When using the document camera : Problem Cause Solution The AC adapter is not Re-connect one end of the Cannot be powered on correctly connected to the AC adapter to the docu- normally. wall outlet or the document ment camera and the other camera.
  • Page 25 When using the document camera : Problem Cause Solution Press AF button to auto focus or adjust by pressing Probably the distance of Manual Focus. The image is fuzzy. object is too close to the lens. Select Macro mode if the distance is less 25cm.
  • Page 26 When using the document camera : Problem Cause Solution It happens when you insert Cannot delete the pictures a memory card after taking The lost recordings are a few pictures or video clips. and video clips, and also saved cannot find them in the You can access those files in the internal memory.
