- Page 1 ® Overland ULTAMUS RAID 1200 Storage Hardware Setup Guide January 2008 10400165-101...
- Page 2 EQUIPMENT AND THE SOFTWARE. 1. Single User License. Subject to the terms and conditions of this EULA, Overland Storage, Inc. (“Overland”) grants to you (“Customer”) a non- exclusive, non-transferable license to use (a) Overland software which provides the basic operating environment for Overland equipment and whether pre-installed on, embedded in or provided with Overland equipment, and (b) the specific Overland program modules or features which have been enabled by security keys supplied by Overland and for which Customer had paid any applicable license fees (collectively, the “Software”),...
- Page 3 Overland Storage. Overland Storage provides this manual as is, without warranty of any kind, either expressed or implied, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Overland Storage may make improvements or changes in the product(s) or programs described in this manual at any time.
-
Page 4: Table Of Contents
Rack Mounting Rail Kit .......................... 2-2 Installing Slide Rails on Chassis ......................2-3 Installing Rack Brackets in 19-Inch Rack .................... 2-3 Mounting the ULTAMUS RAID 1200 Array in the Rack ............... 2-4 Controller Card Connections ........................2-5 Storage Array Connectors ........................2-5 Expansion Array Connectors ....................... - Page 5 Faulty Cords ............................A-1 Alarm Sounds On Power Up ........................A-1 Green Controller OK LED on RAID Controller Not Lit .................A-1 Computer Doesn’t Recognize the ULTAMUS RAID 1200 Array ............A-2 Status Indicators (LEDs) ..........................A-2 Disk I/O Module LEDs ..........................A-2 Drive Carrier LEDs ..........................A-2 OPS Panel LEDs ............................A-3...
-
Page 6: Chapter 1 - Introduction
Expansion is achieved by connecting ULTAMUS RAID 1200x expansion units to the main array. Multiple arrays are connected together using SAS patch cables, up to a total of five chassis, including the ULTAMUS RAID 1200 main array. See “Connecting Multiple Arrays” on page 2-10. -
Page 7: Ultamus Raid 1200X Expansion Array
ULTAMUS RAID 1200 Hardware Setup Guide Introduction The ULTAMUS RAID 1200 as supplied (Figure 1-2 on page 1-1) contains: • Chassis and backplane with integral (front panel mounted) Operator’s Panel (see “Operator’s Panel” on page 1-3). • Up to twelve (12) drive carrier modules, using either SAS or SATA disk drives. -
Page 8: Operator's Panel
(Figure 1-4). Figure 1-4: Drive Carrier Layout • At the rear, the ULTAMUS RAID 1200 chassis assembly contains five plug- in module bays to house two Power Supply modules, a Cooling Fan module and two RAID Controller modules (fitted horizontally). -
Page 9: Audible Alarms
ULTAMUS RAID 1200 Hardware Setup Guide Introduction Audible Alarms The ULTAMUS RAID 1200 array includes an Audible Alarm which indicates when a fault state is present. The following conditions will activate the Audible Alarm: • Fan Fault • Voltage Out Of Range •... -
Page 10: Chapter 2 - Installing And Connecting
Installing and Connecting CHAPTER The following procedures describe the installation of an ULTAMUS RAID 1200 storage or expansion array and highlight some prerequisite requirements and good handling practices which we encourage you to follow to ensure a successful installation in the safest manner. -
Page 11: Rack Installation Prerequisites
ULTAMUS RAID 1200 arrays can be installed without loss of space within the rack. Use of other mounting hardware can cause some loss of rack space. -
Page 12: Installing Slide Rails On Chassis
ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Installation Procedures Installation consists of assembling the rails, mounting the rails in a rack, and inserting the unit into the rack using the rails. Installing Slide Rails on Chassis Refer to the detail drawings supplied with the rack mounting rail kit for further information. -
Page 13: Mounting The Ultamus Raid 1200 Array In The Rack
Figure 2-2: Rack Rail Assembly Procedure Mounting the ULTAMUS RAID 1200 Array in the Rack WARNING: Due to the weight of each rack-mounted array when it is fully extended, you should install arrays in the rack cabinet from the bottom up. Extending a array that has empty spaces beneath it might cause the rack to tip forward and cause personal injury. -
Page 14: Controller Card Connections
ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting 4. Withdraw the chassis until it reaches the hard stops (approximately 400mm (15.75 inches)). Tighten the front rack bracket mounting screws (previously left loose). 5. Push the array completely into the rack cabinet and secure to the front of the rack using the captive fasteners on the front flanges. -
Page 15: Expansion Array Connectors
Figure 2-5: Expansion Array Labeling Schemes Management Interfaces The following management interfaces are provided and used to configure, manage, and monitor the ULTAMUS RAID 1200 storage array. ULTAMUS RAID manager Software ULTAMUS RAID manager software is a full-featured graphical HTML-based software suite designed to configure, manage and monitor the ULTAMUS RAID 1200 storage array. - Page 16 ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Two SFP modules per RAID Controller module are included in the accessory kit (up to four). To install the SFP modules 1. With the handle on the SFP module closed, push the SFP fully into the slot until it seats (click).
- Page 17 ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Figure 2-7: Dual Host, Single HBA, and Single Controller Connections Figure 2-8: Single Host, Dual HBAs, and Dual Controller Connections 10400165-101 01/2008 ©2007-2008 Overland Storage, Inc.
- Page 18 ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Figure 2-9: Dual Hosts, Dual HBAs, and Dual Controller Connections Figure 2-10: Dual Host, Single HBAs, and Dual Controller Connections (Switch) 10400165-101 01/2008 ©2007-2008 Overland Storage, Inc.
-
Page 19: Ethernet Connection
ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Ethernet Connection An RJ45 10/100Base-T Ethernet port allows the controller to be connected to a network to enable out-of -band management and monitoring using the embedded ULTAMUS RAID manager software. Ensure that the PC is connected either directly or via a switched LAN to the Ethernet. -
Page 20: Drive Slot Arrangement
Column 4 Figure 2-12: Drive Carrier Layout Drive Location Rules The ULTAMUS RAID 1200 arrays support two different types of disk drives: SAS, and SATA. In order to allow optimal configurations to be built, the following rules should be observed: •... -
Page 21: Ac Power Cord Connection
2. Connect the ULTAMUS RAID 1200 power cord to the rack distribution and the array. 3. If a direct connection is made with the ULTAMUS RAID 1200 power cord, ensure that the power cord is connected to the array. CAUTION: Some electrical circuits could be damaged if external signal cables or power control cables are present during the grounding checks. -
Page 22: Attach Ac Power Cords
ULTAMUS RAID 1200 Hardware Setup Guide Installing and Connecting Attach AC power cords 1. Swing the Cable Strain Relief Bale out of the way and plug the power cord into the PSU socket. 2. Place the bale over and onto the cord. -
Page 23: Chapter 3 - Power Up The Array
If the drives have been recently installed ensure they have had time to acclimatize before operating them. IMPORTANT: Before you power up an ULTAMUS RAID 1200 or 1200x array for the first time, ensure that all the modules are firmly seated in their correct bays at the rear of the unit. -
Page 24: Starting The Drives
ULTAMUS RAID 1200 Hardware Setup Guide Power Up the Array Starting the Drives The drives in the chassis should automatically start when power is applied to the array. If this does not occur, one of the following conditions can exist: •... -
Page 25: Power Off Process
ULTAMUS RAID 1200 Hardware Setup Guide Power Up the Array Power Off Process The array can be powered down at any time. If cached contents are present (see Cache Active LED on the RAID Controller in section “RAID Module LEDs” on page A-4), they are preserved by the internal battery. -
Page 26: Chapter 4 - Ultamus Raid Manager Software
To assist you when troubleshooting problems with your system, the Event Logs appendix, located in the ULTAMUS RAID manager User Guide (on your ULTAMUS RAID 1200 Software and Documentation CD) and the online help provide a list of all the events that can occur, along with a possible cause and the action to take. -
Page 27: Setting Up The Ultamus Raid Manager
The default password is password. Setting up the ULTAMUS RAID manager 1. Insert the ULTAMUS RAID 1200 Software and Documentation CD into your CD drive. The autorun program automatically starts the navigation menu. - Page 28 ULTAMUS RAID 1200 Hardware Setup Guide ULTAMUS RAID manager Software Figure 4-2: Searching for Available Modules At the third screen, those modules with their default password intact are displayed with their MAC address in an Uninitialized Systems field. 4. From the Uninitialized screen, select the MAC address of the system you...
-
Page 29: Using The Ultamus Raid Manager
Using the ULTAMUS RAID manager The detailed instructions for setting up and using your ULTAMUS RAID manager software features are provided in a separate document, the ULTAMUS RAID manager User Guide, found on your ULTAMUS RAID 1200 Software and Documentation CD. 10400165-101 01/2008... -
Page 30: Appendix A - Faults And Troubleshooting
Faults and Troubleshooting APPENDIX Overview ULTAMUS RAID 1200 and 1200x arrays include a processor and associated monitoring and control logic to enable them to diagnose problems within the array’s power, cooling, RAID Controller or Disk I/O modules, and drive systems. -
Page 31: Computer Doesn't Recognize The Ultamus Raid 1200 Array
Faults and Troubleshooting Computer Doesn’t Recognize the ULTAMUS RAID 1200 Array 1. Check that the FC interface cables from the ULTAMUS RAID 1200 array to the host computer are fitted correctly. 2. Check that all drive carrier modules have been correctly installed and that the LEDs on all installed drive carrier modules are illuminated Green. -
Page 32: Ops Panel Leds
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting OPS Panel LEDs The OPS Panel displays the aggregated status of all the modules. The LEDs are shown in Figure A-1 and defined in Table A-1. NOTE: The panel is supplied as an integral part of the enclosure assembly and is not user replaceable. -
Page 33: Raid Module Leds
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting Table A-1: OPS Panel LED Displays and What They Mean (Continued) OPS Panel LED Status Power System Logical Fault Fault Identify Other LEDs (Green) (Amber) (Amber) (Blue) and Alarms Description of State... -
Page 34: Cooling Module Led
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting SAS Activity These LEDs appear adjacent to the SAS connectors. Illuminated - Activity on the specific port (4 lanes). FC Activity These LEDs appear adjacent to the Fibre Channel connectors. Illuminated Amber - Activity on the specific port. -
Page 35: Audible Alarm Mute
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting Audible Alarm The chassis subsystem includes an Audible Alarm which indicates when a fault state is present. The following conditions will activate the Audible Alarm: • Fan Fault • Voltage Out of Range •... -
Page 36: Auto Start Failure
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting Auto Start Failure Unless otherwise selected at installation time, all drives in the chassis should automatically start their motors after power is applied. If this has not occurred there is a power problem (an alarm and power fault indication would normally be active). -
Page 37: Thermal Control
Faults and Troubleshooting Thermal Control The ULTAMUS RAID 1200/1200x arrays use extensive thermal monitoring and take a number of actions to ensure component temperatures are kept low and also to minimize acoustic noise. Air flow is from front to rear of the chassis. -
Page 38: Thermal Alarm
ULTAMUS RAID 1200 Hardware Setup Guide Faults and Troubleshooting Thermal Alarm Symptom Cause Action • OPS Panel SYSTEM FAULT • If the internal temperature • Check local ambient LED AMBER. measured in the airflow environment temperature through the chassis is below the upper 40° C •... -
Page 39: Appendix B - Specifications
Maximum Configuration 32kg (70.4 lb.) Empty Chassis 9kg (19.8 lb.) AC Power (350W PSU) Voltage Range 100--240V AC Rated Frequency 50/60 Hz Inrush Current <30A @ 230V AC Power Factor >0.98 Harmonics Meets EN61000-3-2 10400165-101 01/2008 ©2007-2008 Overland Storage, Inc. -
Page 40: Ac Power Cords
ULTAMUS RAID 1200 Hardware Setup Guide Specifications AC Power Cords United States Must be NRTL listed (National Recognized Test Laboratory, e.g., UL). Cord type SV or SVT, 18 AWG minimum, 3 conductor, 4.5 M max length Plug NEMA 5-15P grounding-type attachment plug rated 120V 10A;... -
Page 41: Other Environmental Specifications
ULTAMUS RAID 1200 Hardware Setup Guide Specifications Other Environmental Specifications Parameter Limits Airflow Array must be operated with low pressure rear exhaust installation (Back pressure created by rack doors and obstacles not to exceed 5 pascals [0.5mm water gauge]) Altitude, Operational 0 to 3045m (0 to 10,000 ft.) -
Page 42: Interfaces - Disk I/O Module
ULTAMUS RAID 1200 Hardware Setup Guide Specifications Interfaces - Disk I/O Module Drive support See drive carrier specification Attachment • (1) domain of 12 drives per Disk I/O module • (1) SAS Host Port (IN) • (2) SFF8470 connectors (4 lane) •... -
Page 43: Led Functions
ULTAMUS RAID 1200 Hardware Setup Guide Specifications LED Functions RAID Controller Module LED Status Indicators Description Battery Fault This LED appears between the controller’s ethernet and RS232 ports. Illuminated - Backup battery unit is missing, has low voltage, has experienced a time-out on charge indicated a faulty battery or has experienced a fault in the charging circuitry. -
Page 44: Disk I/O Module Specification
I/O activity on this SAS port lane *These LEDs blink ON & OFF when there is lane activity. Drive Carrier Module Specification IMPORTANT: Operating ULTAMUS RAID 1200/1200x chassis with non-approved drives may invalidate the warranty. Please contact your supplier for details of approved drives.
