Summary of Contents for Toyota 2010 Sienna
-
Page 1: Quick Reference
SIENNA CUSTOMER EXPERIENCE CENTER 2 0 1 0 1-800-331-4331 QUICK REFERENCE GUIDE Printed in U.S.A. 4/09 00505-QRG10-SIE 08-TCS-03079 I n f o r ma t i o n P r o v i d e d b y :... - Page 2 Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Four-wheel drive models Inc. wish you many years of satisfied driving in your new Sienna.
-
Page 3: Table Of Contents
EMERGENCY FEATURES Seatbelts Seatbelts-Shoulder belt anchor Spare tire & tools Tire Pressure Monitoring (warning) System Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. ® HomeLink is a registered trademark of Johnson Controls, Inc. - Page 4 OVERVIEW Instrument panel Overhead console Steering wheel switches Headlight, turn signal and front fog light controls Wiper and washer controls Rear window and outside rearview mirror defogger and windshield wiper de-icer switch Emergency flasher button Audio system or navigation system 115V AC Power outlet ON/OFF button AUX adapter Intuitive parking assist switch and indicator...
- Page 5 Tilt and telescopic steering lock release Tire Pressure Monitoring (warning) System reset Power rearview mirror controls Power quarter window switch Headlight beam level control dial Conversation mirror Front personal lights Microphone Power sliding door button Power back door button Electric moonroof switch Steering wheel audio controls Telephone controls Dynamic Laser Cruise Control distance switch...
-
Page 6: Instrument Cluster
If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. For details, refer to “If a warning light turns on or a warning buzzer sounds...,”... - Page 7 Low engine oil pressure warning Open door warning Airbag SRS warning Vehicle Stability Control/Traction Control warning Low Tire Pressure Warning Low windshield washer fluid level warning Engine oil replacement reminder Third seat fold incomplete warning Theft deterrent/Engine immobilizer system indicator AIR BAG ON indicator AIR BAG OFF indicator Headlight low beam indicator...
-
Page 8: Hood Release
OVERVIEW Keyless entry Locking operation Unlocking operation Push ONCE: Driver door TWICE: ALL doors NOTE: If a door is not opened within 60 seconds of unlocking, all Push doors will relock for safety. Power sliding door operation (if equipped) Right side power sliding door Left side power sliding door... -
Page 9: Engine Maintenance
Fuel tank door release and cap Driver seat Pull up Turn Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Engine maintenance Power steering fluid reservoir Windshield and rear window washer fluid tank Engine oil filler cap Engine oil level dipstick Engine coolant reservoir... -
Page 10: Auto Lock Functions 2
FEATURES/OPERATIONS Auto lock functions Automatic door locks can be programmed to operate in four different modes, or turned OFF. -Doors lock when shifting from Park. -Doors lock when the vehicle speed goes above approximately 12 mph. -Doors unlock when the engine key is turned to the “ACC” or “LOCK” position and driver’s door is opened. - Page 11 Lights & turn signals Headlights AUTO* High beam Headlights Parking lights Low beam High beam flasher * If equipped -Daytime Running Light system (if equipped) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after 30 seconds when any of the doors are opened and closed with the engine off.
-
Page 12: Parking Brake
FEATURES/OPERATIONS Windshield wipers & washers Front Single wipe Adjust frequency* Interval wipe Pull to wash and wipe Slow Fast * Intermittent windshield wiper frequency adjustment Rotate to increase/decrease wipe frequency. Rear Wash and wipe Wipe Interval wipe Wash and wipe Parking brake Set: Depress Release: Depress again... -
Page 13: Moonroof
Windows Driver side Window lock switch Down Down Automatic operation (driver side only) (If equipped) Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. -
Page 14: Door-Power Back
FEATURES/OPERATIONS Doors-Sliding ON/OFF switch Instrument panel Push Opening/Closing Center pillar Front overhead console Open: Push Open: Push Close: Push again Close: Push again Power • Sliding doors will not fully open if the sliding door window is open. • When the engine switch is in the “ON” position, power sliding doors will open only when gear selector is in the “P”... -
Page 15: Clock
Console box (if equipped) Install Remove Front seat Second row seat Lock release lever Auxiliary box The console box can be removed and installed between the front or second row seats. To remove Open the auxiliary box on the rear side, and pull the lock release lever. -
Page 16: Seat Adjustments-Front
FEATURES/OPERATIONS Seat adjustments-Front Manual seat Power seat Seat position (forward/backward) Height crank (driver side only) Seatback angle Lumbar support (driver side only)(If equipped) Seat position, cushion angle and height Seatback angle Seat adjustments-Rear Second row seat Outer Center Third row seat Manual Power Seatback release (from third row seat) -
Page 17: Seat Arrangements
Seats-Head restraints Front Rear Lock release button Lock release button Seat arrangements (examples) These are some possible seat arrangements. Please read the following section and refer to the Owner’s Manual for more information about seat positions. 7-passenger models 8-passenger models 7-passenger models The right seat can be placed in the inside or outboard position. -
Page 18: Seats-Stowing Third Row Seats
FEATURES/OPERATIONS Seats-Tumble/Remove second row seats (1) Lower the head restraint and slide the seat to the rear-most locked position. (2) Pull the strap or lever and tumble the seat. (3) Pass the strap through the assist grip. (4) Pull and hold the strap, then fold down the seat to disengage from front hooks. -
Page 19: Seats-Stowing Third Row Seats
Seats-Stowing third row seats (power)(if equipped) Lower Push Stowing seat Returning seat Third seat fold Third seat fold incomplete warning light* incomplete warning light* Push and hold Push and hold * This light will remain ON until the seat is fully open or stowed. An alarm will also sound for 10 seconds, and the indicator will light up on the instrument panel. -
Page 20: Cruise Control
FEATURES/OPERATIONS Cruise control (if equipped) Turning system ON/OFF System ON/OFF Functions Resume /Increase speed Cancel Set/Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed reaches 25 mph. Dynamic Laser Cruise Control (if equipped) Refer to the Owner’s Manual for more details and complete safety precautions before attempting to use the “Dynamic Laser Cruise... -
Page 21: Light Control-Instrument Panel
Distance control mode Push System ON/OFF The distance control mode will cruise at a set speed, decelerate to maintain a selected distance from a slower vehicle traveling in front of you, and accelerate back up to the selected speed if the vehicle in front changes lanes or speeds up. - Page 22 FEATURES/OPERATIONS Audio Type 1 Preset buttons - functions in other modes indicated above number. Eject CD Push to adjust tone & Push to turn balance ON/OFF Seek station/ Push to skip CD track up/down select folder Mode Station/CD View CD track scan information Type 2 additional functions...
-
Page 23: Telephone Controls (Bluetooth ® )
Steering wheel switches (if equipped) Volume control “ ” -In radio mode Push to select a preset station; push and hold to seek the next strong station. -In CD mode Push to skip up or down to next/previous track. “MODE” Push to turn audio ON and select an audio mode. - Page 24 FEATURES/OPERATIONS Air Conditioning/Heating Front manual Air Conditioning Air Conditioning ON/OFF Fresh or recirculated cabin air Airflow vent In “ ” or “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. Temperature selector Use for quick cooling. MAX A/C changes air intake to recirculate. It is not possible to change intake to fresh.
- Page 25 Front automatic Air Conditioning Temperature selector (driver side) Temperature selector (front passenger side) Air Conditioning ON/OFF Synchronizes front and rear temperature settings Airflow vent In “ ” or “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. Windshield airflow/defogger Temperature selector (rear passenger side) Fan speed...
-
Page 26: Multi-Information Display (Homelink ® ) 3
Refer to “Garage door openers,” Section 3-7 in the Owner’s Manual for more details. For programming assistance, contact the Toyota Customer Experience Center at 1-800-331-4331, or visit http://www.homelink.com. Change display information Garage door opener indicator... -
Page 27: Bottle Holders
Power outlets-12V DC Instrument panel Luggage compartment Power outlets-115V AC (if equipped) ON/OFF switch Instrument panel Power outlets Luggage compartment Beside third row seat Designed for car accessories. Engine switch must be in the “ACC” or “ON” position to be used. Bottle holders Front doors Sliding doors... -
Page 28: Cup Holders
FEATURES/OPERATIONS Cup holders Instrument panel Front side table Third row area Console box Rear side Front side Tray I n f o r ma t i o n P r o v i d e d b y :... -
Page 29: Door Locks
SAFETY AND EMERGENCY FEATURES Door locks Lock Unlock Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Seatbelts-Shoulder belt anchor Push up, or squeeze lock release to lower Seatbelt comfort guide I n f o r ma t i o n P r o v i d e d b y :... -
Page 30: Seatbelts
If the tire pressure indicator flashes for more than 60 seconds and then remains on, take the vehicle to your local Toyota dealer. Note: The warning light may come on due to temperature changes or changes in tire pressure from natural air leakage. If the system has not been initialized recently, setting the tire pressures to factory specifications should turn off the light.
