- Page 1 M SERIES ANALOG CORDED USER GUIDE For M100B5, M100B10, M100BW5, M100BW10, M200B5, M200B10, M200BW5, M200BW10...
-
Page 2: Table Of Contents
1 .3 .2 Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . .14 www.teledex.com... -
Page 3: Section A
2 . Or press the SPKR key . The phone will end into the wall jack . automatically select the correct, ringing line . 3 . To end the call, press the SPKR key again . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 4: Adjusting Ring Volume For Base
The CONF key allows for three-way conversations . 2 . The red LED will return to blinking Depending on the situation, you may initiate a illumination, indicating the line is active . conference call using one of these methods: www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 5: Auto-Dial Keys-Faceplate On
(that is, *#78*# + 5 system features . To program the auto-dial keys + Redial – Pause = 5 seconds) . (programming can only be done from base unit): www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 6: Important Safety Instructions
2 . This device must accept any interference work is required . Opening or removing received, including interference that may covers may expose you to dangerous cause undesired operation . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... - Page 7 . compliance could void the user’s authority to The termination on an interface may consist operate the equipment . www.teledex.com M SERIES ANALOG CORDED USER GUIDE...
-
Page 8: Fcc Rules
Any changes made by the user not approved by service may be required . But if advance notice is the manufacturer can void the user’s authority to not practical, the telephone company will notify operate the telephone . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 9: Technical Specifications
5 .8” (w) x 8 .56” (l) x 3 .64” (h) repair or warranty information, please contact WEIGHT Teledex at (800) 462-9446 . If the equipment is causing harm to the telephone network, the telephone With handset: 3 .3 lbs . -
Page 10: Section B
M Series bluetooth distance (range of about 30 ft/10 meters), interface to 2222 . the M series terminal will automatically delete the registered mobile phone within 15 seconds . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 11: Bluetooth Use Cases
MAC address, so that you may (Europe)/14 Channels (Japan) easily find the the Wi-Fi unit’s new IP address in • IEEE 802 .1x your network’s DHCP lease tables . • Software Upgrade Via HTTP www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 12: Analog Guest Service Key Programming
100 mS increments . • The default Flash timing is 600 mS . • Pause timing options are 1 .0 s through 5 .0 s . The default Pause timing is 3 .6 s . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 13: Section C
Both the initial username and password are admin. Input the username and password of admin/admin, click Sign in, and enter the system . At this point you are able to begin configuring the phone’s optional Wi-Fi module . 1.3 Homepage www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 14: Operation State
LAN: The IP address of current LAN port, subnet mask, and MAC address . 1.3.2 SETUP WIZARD The wizard mode helps you properly setup your WAN . Step 1: Configure the Internet connection, click “Next” to access the WAN mode option . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... - Page 15 Step 2: Here the network name (SSID) can be changed per your preference . The selection of safe mode depends on your own actual demand . The analysis for safe mode has been noted in the following Wireless Parameters–Security Setup . www.teledex.com M SERIES ANALOG CORDED USER GUIDE...
-
Page 16: Operation Mode
IP address: The IP address of the gateway against LAN . The factory set is 192 .168 .1 .1 which could be changed at your request . If you have changed the IP address, you must use the new IP address to login www.teledex.com M SERIES ANALOG WI-FI MODEL USER GUIDE... -
Page 17: Wan Setup
The user can select the connection manner according to the use environment . The Wide Area Network has 5 available modes for selection: static (fixed IP), dynamic (auto-obtain), and PPPoE (ADSL) as well as L2TP and PPTP . Each mode can configure the corresponding parameters . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 18: Static Ip
Apply button to finish the setting . 2.2.3 PPPOE If the network operator provides you with the login account and account, please select the PPPoE (ADSL) mode and properly fill them, click Apply button to finish the setting . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 19: Mac Address Clone
Network name: Can be changed to use for labeling the wireless network which will be shown in the list of wireless networks sought by wireless network card . It’s recommended to change it into another name for recognition . Several options can be set . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 20: Security Setup
Encryption approach: Select the required encryption approach from the pull-down list . If selected, more parameters will be visible to be further set . If Disable is selected, this means no encryption is chosen . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 21: Wep
WEP encryption approach . If you select the WEP encryption approach, the router might operate in the low transmission rate . See the below figure for the specific setting options . WEP safe mode includes OPENWEP, SHAREDWEP, and WEPAUTO . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 22: Protected Access
TKIP (Temporal Key Integrity Protocol), AES, and TKIP/AES . The 802 .11N mode does not support TKIP algorithm, so the gateway might operate in a low transmission rate . It’s recommended to use AES encryption . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 23: Wpa/Wpa2
Radius port: The Radius server is used to authenticate the identification of base unit within the wireless network . The item is used to set Port # for Radius authentication service . Radius shared key: The item is used to set the password for access to Radius service . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 24: Advanced Setting
Transmission request limit: Specify the RTS (Request to Send) threshold for a data packet . When the length of a data packet exceeds the RTS threshold, the gateway will send RTS to the destination www.teledex.com M SERIES ANALOG CORDED USER GUIDE... - Page 25 CWMax = Contention Window Maximum AIFSn = Arbitration inter-frame spacing (AIFS), in wireless LAN communications, is a method of prioritizing one Access Category (AC) over the other, such as giving voice or video priority over email . www.teledex.com M SERIES ANALOG CORDED USER GUIDE...
-
Page 26: Wps
MAC address and link rate etc .) . 4 DHCP Server 4.1 DHCP Service Here select enable or disable of the DHCP server . Set the scope of DHCP IP address, subnet mask, DNS server, gateway, and release time . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 27: Client List
You can check the MAC address and IP address of equipment terminal connected through DHCP service . 4.3 Static Address Assignment Here can assign a fixed IP address to the MAC address . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 28: Security Setting
Respectively set the relevant MAC address, IP address, and the filtering option of port . 6 Routing Function Manually add the static routing table information, check the current routing table information, enable or disable RIP function . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 29: System Tools
7 System Tools 7.1 Change Login Password You can set the account and password of administrator here . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 30: Language Setting
7.2 Language Setting You can reset the interface language display: simplified Chinese or English . 7.3 Time Setting You can reset NTP (Network Time Protocol) server to configure the system time . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 31: Upgrade Firmware
You can restore the factory default settings and restart the system . There is also a reset button at the rear of the phone that can be accessed via a small tool such as a paperclip . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 32: Back And Load The Configuration
You can save the system setting by exporting a configuration file and you also can import the exported file into the system . 7.7 Dynamic DNS You can configure the dynamic DNS (Domain Name Service) here . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 33: Restart The System
You can restart the system here . 7.9 System Log It records the relevant operation and error warning, etc ., by which you can check the system events that occurred on the terminal . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... -
Page 34: Section D
3 . Press to decrease the sound volume . 4 . Press to select the previous music, press to select the next music . Note: During the play, the Bluetooth LED automatically blinks . www.teledex.com M SERIES ANALOG CORDED USER GUIDE... - Page 35 3 . Press to decrease the sound volume . 4 . Press to select the previous music, press to select the next music . Note: During the play, the Bluetooth LED automatically blinks . www.teledex.com M SERIES ANALOG CORDED USER GUIDE...
- Page 36 Toll Free: +1 .800 .462 .9446 Tel: +1 .719 .638 .8821 Email: info@teledex .com www .teledex .com © 2014 Cetis, Inc . Product specifications and descriptions in this document subject to change without notice . Cetis , Teledex , TeleMatrix...
