Summary of Contents for Teledex B120D
- Page 1 B120D line powered speakerphone with Caller ID...
- Page 2 RINGER VOLUME ADJUST CONGRATULATIONS AND THANK YOU! Congratulations on your purchase of this quality Teledex analog business telephone. If you have any questions concerning this telephone or its operation, please contact us via one of the methods at right. We appreci-...
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1) FEATURES...……...2 2) UNPACKING THE B120D...2 3) IMPORTANT CALLER ID INFORMATION...3 4) IMPORTANT NOTICE BEFORE INSTALLATION...3 5) INSTALLATION...…...4 DESKTOP INSTALLATION...4 WALL MOUNTING...…...4 WALL MOUNT CLIP…...5 6) USING THE DATA PORT...5 7) ADJUSTING THE RINGER VOLUME ...…...………………5 8) OPERATION ...6 PLACING AND ANSWERING CALLS WITH THE HANDSET...……...6... -
Page 4: Features
DELETE BUTTON – To delete call records individually, or all at once HEARING AID COMPATIBLE The B120D is ETL listed to UL standards and meets all applicable FCC standards and requirements. 2. UNPACKING YOUR B120D Inside the box, you will find all of the items needed for installation, as shown below: B120D BASE UNIT Check to be sure that your package includes all the above items. -
Page 5: Important Caller Id Information
You must not connect your B120D to either coin-operated systems or party-line systems. The B120D also complies with the limits for a Class B device as specified in Part 15 of the FCC Rules. These limits provide reasonable protection against radio and TV interference in a residential area. -
Page 6: Installation
(please refer to figure 3.) Place the handset in the handset cradle. Remove the desk/wall mount bracket from the bottom of the B120D. Rotate the bracket 180º and reinstall it into the four slots the bottom of the B120D. -
Page 7: Wall Mount Clip
7. ADJUSTING THE RINGER VOLUME Your B120D has three ringer volume levels: Off, Low and High. To adjust, slide the switch located along the right hand side of the telephone to the desired ringing level. -
Page 8: Operation
7.1 RING CADENCES Your phone has three ring cadences, or patterns. To change the cadence, slide the switch located along the right hand side of the telephone to one of the musical notes icons located beneath the switch (please refer to Figure 7.) 8. -
Page 9: Using Mute
9.1 REVIEWING CALLER ID RECORDS Each time you receive a call, your B120D stores a Caller ID record that you can review later. A Caller ID record includes: – Call number (in the order the calls are received) –... -
Page 10: Caller Id Messages
You have a message waiting. 9.3 DELETING CALLER ID RECORDS The B120D allows you to delete individual Caller ID records, or all Caller ID records that have been reviewed. It will not allow the deletion of Caller ID records that have not been reviewed. -
Page 11: Requirements Of Part 68- Fcc Rules
2) Use and store the phone only in normal temperature environments. Extreme temperatures can shorten the life of electronic devices and distort or melt plastic parts. 3) Keep the phone away from dust and dirt, which can cause premature wear of parts. -
Page 12: Important Safety Instructions
alterations made by the user to this equipment, or equipment malfunctions, may give the telecommunications company cause to request the user to disconnect the equipment. Users should ensure for their own protection that the electrical ground connections of the power utility, Telephone lines, and internal metallic water pipe systems, if present, are connected together.
