Teledex Millennium Series 2005 User Manual

CONNECTING THE MILLENNIUM 2005/2010
Included with the Millennium 2005/2010 are (one each):
• Base unit • Coiled handset cord
• Handset • Clear plastic overlay
Contact your supplier or Teledex for information on ordering
custom designed and printed faceplates to enhance the look of your
Teledex telephone.
1) Located on the left side of the Millennium (as the phone is fac-
ing you) is a modular jack labeled
of the coiled handset cord into this jack (you should hear the
coil cord click when properly inserted).
2) Insert the other end of the coiled handset cord into the handset.
3) Turn the telephone so the back panel is facing you. Insert either
end of the line cord into the jack on the back of the telephone
TO TEL.
labeled
4) Insert the other end of the line cord into a telephone wall jack.
5) Once your telephone is connected, remove the plastic overlay
and place the paper faceplate over the keys. Replace the plastic
overlay by hooking the tabs on the overlay into the recessed
slots located on both sides. The overlay is easiest to insert when;
the left or right side tabs are inserted first, and the middle of the
overlay is slightly bowed to allow for insertion of the other tabs.
SELECTING LINE 1 AND LINE 2
The Millennium's MPC technology makes selecting the correct line
TM
as easy as lifting the handset. MPC technology prioritizes the ringing
or idle line and reduces the confusion of manually having to select a
line.
PLACING A CALL
USING THE HANDSET
1) Lift the handset. The Millennium will select the appropriate
"idle" line.
2) Listen for dial tone. Dial the desired number, or press a
SERVICE AUTO DIAL
key to automatically dial a pre-pro-
grammed number.
3) To end the call, hang up by placing the handset back in the cra-
dle.
USING THE SPEAKERPHONE
1) With the handset in the cradle, press the
The Millennium will go off hook on the selected line with speak-
erphone active.
-OR-
SPEAKER
Press the key. The Millennium will select the appropri-
ate "idle" line.
SPEAKER LED
NOTE: The red
phone is active.
2) Listen for dial tone. Dial the desired number, or press a
SERVICE AUTO DIAL
key to automatically dial a pre-pro-
grammed number.
3) To end call the call press the
RECEIVING A CALL
An audible ring and a flickering red LED indicate an inbound call.
USING THE HANDSET
1) Lift the handset. The Millennium will select the ringing line.
2) To end the call hang up the handset.
USING THE SPEAKERPHONE
1) With the handset in the cradle, press the line key associated with
the ringing line. The Millennium will go off hook answering the
ringing line with the speakerphone active.
-OR-
SPEAKER
2) Press the key. The Millennium will select the ringing
line and answer with the speakerphone active.
NOTE: The red SPEAKER LED will indicate that the speaker-
phone is active.
• User guide
• Line cord
TO HANDSET.
Insert one end
GUEST
LINE 1 LINE 2
or keys.
will indicate that the speaker-
GUEST
SPEAKER
key again.
MILLENNIUM 2005/2010
GUESTROOM TELEPHONE

USERS GUIDE

CONFERENCE CALLS
CONFERENCE
The key allows the user to originate or to include two
parties in a three-way phone conversation. Typical conference calls
would be initiated by;
- User initiates two (2) calls
- User initiates one (1) call after receiving a call
- User includes two (2) callers
USER INITIATES TWO (2) CALLS:
1) Place call to first party.
2) Place the first party on hold by pressing the
3) Place call to second party using the available, unused line.
CONF
4) Press the key. The parties will be connected.
USER INITIATES ONE (1) CALL:
1) Receive call from first party.
2) Place caller on hold by pressing the
3) Place call to second party using the available, unused line.
CONF
4) Press the key. The parties will be connected.
USER INCLUDES TWO (2) CALLERS:
1) Receive call from first party.
2) Place caller on hold by pressing the
3) Receive call from second party.
CONF
4) Press the key. The parties will be connected.
ADJUSTING THE HANDSET VOLUME
HANDSET VOLUME
The function has eight (8) levels. When the
handset is first lifted, the handset volume is set at Level One (1).
VOLUME
Locate the keys, labeled "
-
phone. Pressing the " " key decreases the volume level while pressing
+
the " " key will increase it. Returning the handset to the cradle for
over two seconds will reset the volume to Level One (1). If the hand-
set is in the cradle for less then two seconds, the handset volume will
not be reset and be set at the last used volume level.
ADJUSTING SPEAKERPHONE VOLUME
SPEAKERPHONE
The also has eight (8) levels. When the speaker-
phone is activated, the volume is set at Level Four (4).
VOLUME
Locate the keys, labeled "
-
phone. Pressing the " " key decreases the volume level while pressing
+
the " " key will increase it. Disconnecting the call for over two sec-
onds will reset the volume to Level Four (4). If the speakerphone is
off for less then two seconds, the volume will not be reset and be set
at the last used volume level.
TO MUTE SPEAKERPHONE AND HANDSET CALLS
MUTE
1) Press the key, the red LED below the
light. The party on the other end will not hear you when the
MUTE
key is depressed.
MUTE
2) Press the key again to turn off the mute feature, the
MUTE LED will go out.
MUTE
When the key is used during a conference call, both parties on
the other end will not be able to hear you.
ADJUSTING THE RING VOLUME
Locate the respective "Line Ringing Volume" adjustment control on
the back of the telephone labeled
Slide the switch to the desired LOW or HI ring volume for each line.
SPEAKERPHONE TIPS
TO ACTIVATE THE HANDSET FROM SPEAKERPHONE MODE:
1) Lift the handset from the cradle.
SPEAKER LED
2) The red will go out.
TO ACTIVATE THE SPEAKERPHONE FROM HANDSET MODE:
SPEAKER
1) Press the key.
SPEAKER LED
2) The red will indicate speakerphone selection.
3) Place the handset back into the cradle.
HOLD
key.
HOLD
key.
HOLD
key.
- +
" and " " at the bottom of the
- +
" and " " at the bottom of the
MUTE
key will
RINGER LOW/HI
(see diagram).
