- Page 1 AtlonA ™ HDMI Audio De-Embedder MODEL: AT-HD577 User’s Manual Rev.1006...
-
Page 2: Table Of Contents
............... 4. Specifications ............... 5. Panel Description ............... 6. Installation ............... 6 7. EDID Learning ............... 7 8. Output Format Selection ............... 7 9. Notice ............... 7 10. Safety Information ..............11. Warranty ..............12. Atlona Product Registration ..............10... -
Page 3: Introduction
7.1 channel analog audio outputs and stereo S/PDIF in both Toslink and RCA connectors are seamlessly integrated in AT-HD577. AT-HD577 is designed to enrich your full digital video and audio experiences at the least expense ™... -
Page 4: Features
(Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio) through HDMI input and output ports ™ EDID learning ability to support all HDMI displays PACKAGE CONTENTS 1x AT-HD577 1x 5V power supply unit 1x User's manual... -
Page 5: Specifications
SPECIFICATIONS Model Name AT-HD577 Technical Role of usage Audio de-embedder & 2x1 switch ™ ™ HDMI compliance HDMI 1.3c HDCP compliance Video bandwidth Single-link 225MHz (6.75Gbps) Video support 480i / 480p / 720p / 1080i / 1080p60 24/30/36-bit color DTS-HD Master Audio & Dolby TrueHD [pass-through]... -
Page 6: Panel Description
PANEL DESCRIPTION Front Panel 1. Power on/off indicator ™ ™ 2. Red light – HDMI 1.2 signal output; green light – HDMI 1.3 signal output ™ ™ ™ 3. Push-in button for enforcing HDMI output format selection between HDMI 1.2 and HDMI ™... -
Page 7: Rear Panel
Rear Panel 7. 2-pin DIP switch Pin Position Off-Off () Off-On (] On-Off () On-On () Input A EDID Default EDID Default EDID Display's EDID Display's EDID Input B EDID Default EDID Display's EDID Default EDID Display's EDID ™ ™ 8. -
Page 8: Installation
3. Connect your stereo S/PDIF AV receiver into the RCA output ports. 4. Connect your 7.1ch or 5.1ch speakers into the RCA output ports. 5. Power up the AT-HD577. 7.1 channel audio layout and speaker setup 5.1 channel audio layout and speaker setup... -
Page 9: Edid Learning
EDID LEARNING EDID LEARNING 1. Power up the AT-HD577. Connect to HDMI OUT with the display you want the AT-HD577 to learn its EDID. 2. To learn the display’s EDID for source device connected to HDMI IN A to play normally, pull DIP switch pin-1 up-and-down to stay at ON () and wait for about 5 seconds to complete the... -
Page 10: Safety Information
If the wall plug does not fit into your local power socket, hire an electrician to replace Use only accessories recommended by ATLONA your obsolete socket. to avoid fire, shock or other hazards. Do not modify the wall plug. -
Page 11: Warranty
Atlona Technologies and its suppliers’ entire liability and Customer’s exclusive remedy shall be, at Atlona Technologies’ option, either return of the price paid for the Product, or repair or replacement of the Product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of Customer’s receipt. -
Page 12: Atlona Product Registration
At Atlona, we respect and protect your privacy and assure you that your registration information is completely secure. Of course, Atlona product registration is totally voluntary and failure to register will not diminish your limited warranty rights.
