- Page 1 User Manual HDMI Recorder, Writer and Hot Plug Simulator with RS232 control AT-HDSync Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515...
-
Page 2: Table Of Contents
..........2 4. Specifications ..........3 5. Panel Description ..........4 6. Installation ..........5 7. Software Operation ..........6 8. Safety Information ..........9 9. Warranty ..........10 10. Atlona Product Registration ..........11 Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... -
Page 3: Introduction
INTRODUCTION Atlona Technologies AT-HDSync HDMI™ EDID Recorder-Writer with Serial Control is a device that can emulate the EDID (Extended Display Identification Data) information. It stores and recalls a default EDID setting in non- volatile memory and supports HDCP handshaking. ATHDSync allows your HDMI™ source boot directly from AT-HDSync, and users can detach HDMI™... -
Page 4: Specifications
SPECIFICATIONS Model Name AT-HDSync Technical HDMI™ compliance HDMI™ 1.3c DVI compliance DVI 1.0 HDCP compliance Video bandwidth Video support Input 1x HDMI™ + 1x RS-232 Output 1x HDMI™ HDMI™ connector Type A (19-pin female) RS-232 connector DE-9 (9-pin D-sub female) -
Page 5: Panel Description
Display Side 1. Connect to a 5V DC power supply unit. 2. Red light indicates the power on/off status. Green light indicates if the AT-HDSync is in the process of reading or writing EDID or sync detection. 3. Connect to a HDMI™ display. -
Page 6: Installation
3. Plug in the 5V DC power supply unit. 4. Connect the AT-HDSync to the serial port of PC and run the control software. 5. Click on “HDMI Monitor Reader” button to read the EDID information from the HDMI™ display. -
Page 7: Software Operation
RS-232 serial port is automatically detected and successfully connected. 2. If the error message as shown below appears, inappropriate setup has occurred. Check at the power supply and RS-232 serial port connection. Toll free: 1-877-536-3976 www.atlona.com Local: 1-408-962-0515... - Page 8 2) Read EDID from AT-HDSync 1. If users would like to read EDID info from the AT-HDSync, simply click ”Read Machine EDID.” You can see the following message to inform you the correct reading of the EDID has been done.
- Page 9 2. Click “HDMI Monitor Writer” Click “HDMI Monitor Writer” and wait for the following message window showing up. 3. The AT-HDSync may not work on the monitors with EDID write-protection. At this time , you can see the following error message window showing up .
-
Page 10: Safety Information
It may also cause damage to your AT-HDSync. Opening the product will void the warranty. Do not attempt to service the unit. Disconnect the product and contact your authorized Atlona reseller or contact Atlona directly. -
Page 11: Warranty
Atlona Technologies’ decision, either return of the price paid for the product, repair, or replacement of the product that does not meet this Limited Warranty and which is returned to Atlona Technologies with a copy of the Customer’s receipt. This Limited Warranty is void if failure of the product has resulted from accident, abuse, misapplication, or natural occurrence. -
Page 12: Atlona Product Registration
ATLONA PRODUCT REGISTRATION Thank you for purchasing this Atlona product. - We hope you enjoy it and will take an extra few moments to register your new purchase. Registration creates an ownership record if your product is lost or stolen and helps ensure you’ll receive notification of performance issues and firmware updates.
