- Page 1 OPERATOR Hydro-Retriever™ 2067 Models 463684 (G), 463683 (P), 463685 (D) 4/98 Form Number 041410 FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 27...
-
Page 2: Table Of Contents
Lubrication ..................22 Hydraulic Oil ..................23 Engine Oil ..................23 Engine Coolant ................23 Engine Air Filter ................24 Dust Control Filter ................25 Fuse Location .................. 25 Specifications ................26 FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 1... -
Page 3: Introduction
FORD VSG 413I-6005-A Propane 463684 FORD VSG 413I-6005-A Gasoline 463685 KUBOTA V1903E-1 Diesel Note: Reference the separately supplied engine manufacture’s maintenance and operator manual for more detailed engine specification and service data. 2 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 4: Uncrating The Machine
Use extreme care when working on this machine. Loose clothing, long hair, and jewelry can get caught in moving parts. Turn the Key Ignition Switch OFF and remove the key before servicing the machine. Use good common sense, practice good safety habits and pay attention to the yellow decals on this machine. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 3... -
Page 5: Safety Instructions
Use caution when moving this machine in below freezing temperature conditions. Any water in the solution or recovery tanks or in the hose lines could freeze. Before use, all doors and hoods should be properly latched. SAVE THESE INSTRUCTIONS 4 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 6: General Information
Before transporting the machine on an open truck or trailer, make sure that . . . • All access doors are latched securely. • The machine is tied down securely - see tie-down locations (4 & 5). • The machine parking brake is set. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 5... -
Page 7: General Information
(A) (vertical). Tow or push machine no faster than a normal walking pace (2-3 miles per hour) and for short distances only. If the machine is to be moved long distances the rear drive wheels needs to be raised off the floor and placed on a suitable transport dolly. 6 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 8: Know Your Machine
Solution Tank Cover Engine Access Door Tie-down Location (2 tie-downs on back bumper) Tie-down Location (one on each side) Side Broom Dust Control Filter Compartment Jacking Points (under bumper when side doors are open) FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 7... - Page 9 13 Oil Pressure Gauge 30 Fuel Storage Access Door 14 Water Temperature Gauge 31 Glow Plug Indicator Light (Diesel) 15 Battery Meter 32 Head Light Switch 16 Hour Meter 17 Hopper Dump Door Switch 8 - FORM NO. 041410 / HYDRO-RETRIEVER 2067...
- Page 10 19 KEY IGNITION SWITCH - controls the engine and some parts of the electrical system. 20 THROTTLE CONTROL SWITCH - controls the speed of the engine. When operating the machine, the throttle control switch should be in the full throttle position (lll). FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 9...
-
Page 11: Know Your Machine
30 FUEL STORAGE ACCESS DOOR - provides access for LP tank installation & gasoline/diesel tank filling. 31 GLOW PLUG INDICATOR LIGHT - turns red when the glow plugs are pre-heated for cold starts (Diesel). 32 HEADLIGHT SWITCH - turns on the headlights. 10 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 12: Preparing The Machine For Use
Chemical mixed with water according to the manufacturer’s recommendations. If using a powdered chemical, mix it with water in a bucket before putting it into the machine’s solution tank. CAUTION ! Use only low-sudsing, non-flammable, non-caustic cleaning chemicals intended for machine application. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 11... -
Page 13: Fuel
Mount a standard 33 lb. liquid withdrawal propane tank on the machine, connect the fuel hose and open the shutoff valve on the tank. Wear gloves when connecting or disconnecting the fuel hose. Shut the propane tank service valve OFF when the machine is not in use. 12 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 14: Operating The Machine
____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ The Hydro-Retriever 2067 is a rider-type automatic floor sweeping and scrubbing machine. It is designed to sweep up debris, lay down cleaning solution, scrub the floor, and vacuum dry all in one pass. The sweeping and scrubbing operations can also be performed separately. Reference specifications on page 26. -
Page 15: Starting The Gasoline Engine
Switch - to control the speed of the machine. The speed of the machine will increase as the pedal is pushed closer to the floor. Do not press the Forward/Reverse Pedal until the engine has started. 14 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 16: Sweeping
Back the machine away from the receptacle until the hopper will clear it, then lower the hopper. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 15... -
Page 17: Scrubbing
Direct the hose to a proper disposal site, remove the drain plug. Flush the tank and drain hose with clean water. Put the plug back into the hose and return the hose to its storage compartment. 16 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 18: After Using The Machine
Place the Throttle Control Switch in the IDLE position and run the engine until all the LP gas is dispelled from the line. Apply the Parking Brake. Turn the Key Ignition Switch OFF and remove the key. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 17... -
Page 19: Maintenance
Inspect the dust control filter. Clean using method “C” if necessary. (see page 25.) Change the oil in the upper impeller shaft housing. ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ EVERY 1500 HOURS OF OPERATION Drain and flush the cooling system. Add new coolant. 18 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 20: Main Broom Maintenance
The width of the polished strip should be the same at both ends of the broom. If the strip is tapered, move the machine to a different area and repeat steps 1-4. If the polished strip is still tapered, contact your Advance Dealer for service. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 19... -
Page 21: Side Broom Maintenance
To raise or lower the side broom (without changing its angle), loosen Bolt (D) and the lock nut on Bolt (E). Turn Bolt (E) clockwise to lower or counter-clockwise to raise the broom. Tighten Bolt (D) and the Locknut (G) when adjustment is complete. 20 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 22: Squeegee Maintenance
Adjust the height of the Squeegee Support Wheels (B) so the squeegee blades contact the floor at a 45° angle when they are bent over to their “operating position”. Move the wheels up to lower the squeegee or down to raise the squeegee. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 21... -
Page 23: Impeller Maintenance
Adjust the tension or replace the belt if necessary. ____________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________________ LUBRICATION Lubricate the two Grease Fittings (C) on the lower impeller shaft every 150 hours of operation. These can be easily lubricated with a grease gun from the engine compartment. 22 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 24: Hydraulic Oil
Lift the engine cover and allow the engine to cool completely. Then remove the cap from the radiator. If coolant is not visible at the bottom of the filler neck, add a mixture of half water and half automotive type anti-freeze. FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 23... -
Page 25: Engine Air Filter
(maximum pressure 100 psi) or wash it with water (maximum pressure 40 psi). Do not put the element back into the Canister (E) until it is completely dry. To reset the air filter service indicator, press down on the top of the indicator. 24 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... -
Page 26: Dust Control Filter
F5 - 15 amp fuse - hydraulics, beacon, timer F6 - 20 amp fuse - shaker motor, turn signals (optional) F7 - 20 amp fuse - optional accessories F8 - 10 amp fuse - optional accessories FORM NO. 041410 / HYDRO-RETRIEVER 2067 - 25... -
Page 27: Specifications
12.5 gallon (47 liters) total system Fuel 12 gallons (45.4 liters) diesel 12 gallons (45.4 liters) gasoline 33 pound (15 kg) LPG Gradeability Transport 14% (8 Cleaning 10% (6 Specifications are subject to change without notice. 26 - FORM NO. 041410 / HYDRO-RETRIEVER 2067... - Page 28 Nilfisk-Advance, Inc. 14600 21st Avenue North Plymouth, MN, 55447-3408 www.nilfisk-advance.com Phone: 800-989-2235 Fax: 800-989-6566 ©2000 Nilfisk-Advance, Inc., Plymouth, MN 55447-3408 Printed in the U.S.A.
