Detroit Radiant Products Co.
SW Series
Overhead Short Wave Electric Infrared Heater
Installation, Operation, Maintenance and Parts
1, 2 and 3 Lamp Units
All persons involved with the installation, operation and maintenance of the heater system must read and
understand the information in this manual .
Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury or death . Read and understand the installation, operating
and maintenance instructions thoroughly before installing or servicing this equipment .
INSTALLER: Present this manual to the end user.
Keep these instructions in a clean and dry place for future reference .
Model#: ___________________ Serial #: _________________________
Manual
!
WARNING
!
(located on rating label)
LIOSW-Rev . 06311
Print: 3M-12/13_r4-4/15 (CDS)
Replaces: LIOSW-1M-9/12 (CDS)
Advertisement
Table of Contents
Related Manuals for Detroit Radiant Products SW-24
Summary of Contents for Detroit Radiant Products SW-24
- Page 1 Detroit Radiant Products Co. SW Series Manual Overhead Short Wave Electric Infrared Heater Installation, Operation, Maintenance and Parts 1, 2 and 3 Lamp Units All persons involved with the installation, operation and maintenance of the heater system must read and understand the information in this manual .
-
Page 2: Table Of Contents
Series Contents 1.0 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Safety Symbols . -
Page 3: Safety
Safety • Safety Symbols • Applications Series Safety WARNING Improper installation, adjustment, alteration, service or maintenance can cause property damage, serious injury or death . Read and understand the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment . -
Page 4: Model Number Designation Chart
Type Qty. Code Code (Color) A = 120 VAC B = 208 VAC 16 = 1,600 SW-24 B = Black Powder Coat R= Ruby Lamp C = 240 VAC 25 = 2,500 SW-33 D = 277 VAC 36 = 3,600... -
Page 5: Clearance To Combustibles
Series Safety • Clearance to Combustibles Clearance to Combustibles WARNING Placement of explosive objects, flammable objects, liquids and vapors close to the heater may result in explosion, fire, property damage, serious injury or death . Do not store, or use, explosive objects, liquids and vapor in the vicinity of the heater . - Page 6 Series Safety • Clearance to Combustibles Chart 1.1 • Clearance to Combustibles in Inches (see Figure 1 . 1 ) Side Model Mounting Front Behind* Below Wattage Angle 0° 1,600 45° 0° 2,500 45° 0° 3,200 45° 0° 3,650 3,800 45°...
-
Page 7: Safety Signs And Labels
6.67 EL-073 DESIGN COMPLIES WITH: Serial No. 10 10 DETR 021400 0001 UL2021 1997 & C22.2 No. 46-M1988 - Electric Air - Heaters DETROIT RADIANT PRODUCTS COMPANY 21400 HOOVER ROAD - WARREN, MI (586) 756-0950 www.drp-co.com Rating Plate F/N: LL01 - Clearance Safety Tag... -
Page 8: Standards, Certifications And Government Regulations
, local ordinances, and any special diagrams from the manufacturer . Canada: Refer to Canadian Electrical Code CSA C22 . 1 Part 1 (latest edition) . Detroit Radiant Products Company units comply or are certified by one or more of the following organizations or standards: •... -
Page 9: Installation
Installation • Design Series Installation WARNING Read and understand, the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment . Design To ensure a safe, properly designed heating system, a layout should be developed for the correct placement of the infrared heater(s) . - Page 10 Series Qty. [Dim. A] Heaters (Ft.) [Dim. B] Coverage Square Foot 8 to 10 3 to 8 SW-24 8 to 10 4 to 10 10 to 12 5 to 12 8 to 10 4 to 10 SW-33 10 to 12...
-
Page 11: Heater Mounting
• Heater Dimensions (Center of Mounts) 10.50 Mount Heater Level - Side to Side - Chart 2.3 • Physical Dimensions (inches) Model No. SW-24-X1 23 .50 9 .25 24 .00 SW-24-X2 23 .50 15 .00 24 .00 Figure 2.3 •... - Page 12 Installation • Heater Mounting Series Top Channel Assembly Attach the mounting brackets to the top wire raceway . On each end, place (1) 1/4” x 1/2” bolt through the bottom hole of the mounting bracket and through the bottom hole of the top wire raceway . Place (1) 1/4”...
-
Page 13: Lamp Installation
Element NOTE: SW Series heaters are designed for use with Quartz lamp infrared heating elements only . They are NOT intended to be used with straight metal rod heating elements. Replace lamps with parts from Detroit Radiant Products Company only. -
Page 14: Outdoor Application
Installation • Outdoor Application • Electrical Series Totally Exposed Outdoor Applications CAUTION For totally exposed outdoor applications (not ceiling protected) ensure connections are made as illustrated in Figure 2 .6 Figure 2.6 • Exposed Outdoor Application 6” Minimum NOTE: All conduit, conduit fittings, and junction boxes are field supplied . Must be NEMA Type 4x or equivalent . -
Page 15: Wiring Diagrams
Series Installation • Wiring Diagrams Wiring Diagrams Figure 2.7 • SW Wiring Diagram • Units with 1 Lamp LAMP NO. 1 Figure 2.8 • SW Wiring Diagram • Units with 2 Lamps LAMP NO. 1 LAMP NO. 2 Figure 2.9 •... -
Page 16: Maintenance
Maintenance • Series Maintenance Checks & Log Maintenance It is recommended that the following become a standard yearly procedure to obtain maximum operating efficiency and trouble free operation . During long periods of non-usage, remove or cover heater with a polyethylene bag and disconnect from power supply . -
Page 17: Troubleshooting Guide
Series Maintenance • Troubleshooting Guide Troubleshooting Guide Start Corrective Process Turn Heater on from power source. Question Action Question Are the heating lamps Does the heating Replace heating lamp(s) . lamps turn on? physically damaged? Are the heating lamps Rewire lamps as indicated wired as indicated in in this manual . -
Page 18: Heater Assembly Components
Maintenance Series • Heater Assembly Components Heater Assembly Components For complete information on SW Series replacement parts, visit the online replacement parts library at www . d etroitradiant .com/partscenter . For discontinued models, consult the factory . Figure 3.1 • Components 152, 153, 154 252, 253, 254... -
Page 19: Parts Listing
Series Maintenance • Parts Listing Electric Parts Listing • Chart 3.1 General Parts List Part Description Part Description EL-002 Gold Anodized Reflector, 24 Inch Model EL-076A Lamp; 2500W 480V Clear EL-003 Gold Anodized Reflector, 33 Inch Model EL-077A Lamp; 3650W 480V Clear EL-004 Gold Anodized Reflector, 46 Inch Model EL-078A Lamp;... -
Page 20: Limited Warranty
Series Limited Warranty One-Year Limited Warranty. Detroit Radiant Products Company (hereinafter referred to as the Company) warrants to the original purchaser or original user that all Detroit Radiant Gas Infrared Heaters sold by it and all parts thereof are free from defects in material or workmanship under normal use and service . The Company’s sole obligation under this warranty shall be limited to furnishing replacement parts, F .O .B .
