- Page 1 AeraMax ® Pro AM IV Please read these instructions before use. Do not discard: keep for future reference.
- Page 2 Follow the instructions in this manual to reduce the risk of electric shock, short circuit, and/or fire: • When drilling into mounting surface, do not damage electrical wiring and • Do not use this air purifier as sole protection against harmful pollutants. other hidden utilities. • Use this unit only in the manner intended by the manufacturer. If you have questions, contact the manufacturer. • Do not use unit without filters installed. • Installation work and electrical wiring must be done by qualified • Do not wash and reuse any of the filters. person(s). All electrical installation work must be conducted and carried • Do not use attachments or filters other than AeraMax ® PRO brand, as out in accordance with all federal, state and local codes and regulations. unit will not function. • Before servicing or cleaning the unit, switch power off at service panel. • Do not spray aerosols on, or into the unit. Lock service panel, or affix a warning tag, to prevent power from being • Do not use detergent to clean the unit. switched back on accidentally.
- Page 3 PACKAGING CONTENTS • AeraMax ® PRO Air Quality Control System • Mounting Template • True HEPA Filter with AeraSafe™ Antimicrobial Treatment (1 filter) • Pan Head Phillips Screws - M6 x 50mm (4) • Activated Carbon Filter w/Pre-Filter (1 of each filter) • Drywall Anchors - 10mm OD (4) • Keys for Locking Front Panel (2) • Registration information PRODUCT SPECIFICATIONS AeraMax ® PRO AM VI Dimensions (H x W x D) 19.6 x 34.7 x 9 inches / 49.7 x 88.1 x 22.8 cm Weight of System (including filters) 33.3 lbs. / 15.1 kg Power Requirements 120 volt, 60 Hz, 2 amp Power Consumption (5 fan speeds) 8, 12, 18, 35, 166 watt...
- Page 4 DISPLAY PANEL NOTE: after the unit is turned on the “AQ” light will flash for a few minutes while the system self-calibrates. HEPA FILTER REPLACEMENT INDICATOR – NORMAL MODE – This indicator will show Select this mode for restrooms, cafeterias, fitness areas, and other louder areas as rapid purification is initiated when the room is occupied its status when the access panel is open or closed. If the light is red this indicates and / or strong airborne contaminants are present. To select, press and hold the the filter needs replacing. The replacement period will vary depending on the filters used, hours of use, air quality, and rate of air flow. For filter replacement “Normal” indicator until icon illuminates. This mode monitors air quality, motion, and indicator descriptions see FILTER REPLACEMENT INDICATORS section. noise level to adjust the fan speed in order to keep your air purified as quickly as possible. The fan can reach turbo speed to clean the room in the case of high levels CARBON FILTER REPLACEMENT INDICATOR –...
- Page 5 Red = Replace RIGHT filter Amber = Replace LEFT filter Red & Amber Alternating = Replace Right & Left filters Do not wash and reuse any of the filters – they will not work effectively. Only use AeraMax ® PRO brand replacement filters as units will not function using any other replacements. FILTER REPLACEMENT PROCEDURE: Unlock access panel: to unlock, insert...
- Page 6 ® AeraMax Pro AM IV Fellowes, Inc. 1789 Norwood Ave Itasca, Illinois 60143-1095 USA 630-893-1600 1-800-477-7940 Product Support: 1-800-945-4545 www.aeramaxpro.com ©2014 Fellowes, Inc. Part No. 408529 Rev B...
