Achieve C150 Owner's Manual

Mag bike
Hide thumbs

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
WA0046
C150 Mag Bike

Advertisement

loading
Need help?

Need help?

Do you have a question about the C150 and is the answer not in the manual?

Questions and answers

Related Manuals for Achieve C150

Summary of Contents for Achieve C150

  • Page 1 OWNER’S MANUAL WA0046 C150 Mag Bike...

  • Page 2: Table Of Contents

    Table of Contents Page Important Safety Information _____________ Before You Start _____________________ Assembly Instruction _________________ __ Console ___________________________ Monitoring Your Heart Rate ____________ Exploded View _____________________ Parts List __________________________ Warranty / Service ___________________...

  • Page 3: Important Safety Information

    Important Safety Information WARNING! Before using this unit or starting any exercise program, consult your physician. This is espe- cially important for persons over the age of 35 and/or persons with pre-existing health prob- lems. The manufacturer or distributor assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Start

    Before You Start Thank you for purchasing this new Achieve Mag Bike! This quality product you have chosen was designed to meet your needs for cardiovascular exercise. Before you start, please read the Owner's Manual and become familiar with the operation of your new unit.

  • Page 5: Assembly Instruction

    Assembly Instruction REMOVE ALL SECURITY TAPE AND WRAPPING BEFORE BEGINNING 1. Attach the front and rear Foot Tubes (4&4A) to Main Frame (1) using : Qty 4 – (19) Carriage Bolt Qty 4 –(49) Washer Qty 4- (68) Nut Cap Make sure that the front Foot Tube (4) with the Transport Wheels (13) is assembled to the front of the Main Frame (1).
  • Page 6 Assembly Instruction 3. Thread the Right Pedal (31) into the hole of Right Crank(23). Secure in place by turning it clockwise to tighten. Note: Right Pedal (31) is marked with an “R”. Thread the Left Pedal (30) into the Left Crank (22). Secure in place by turning counter-clockwise to tighten.
  • Page 7 Assembly Instruction 5. Connect the Extension Wire(58) in the console tube to the Sensor Wire (38) in the main frame. Connect the Tension control wire(8) in the console tube into the slot of the Tension Cable Bracket (57) as showed in the diagram. Then slide the Console Tube (2) onto the Main Frame Assembly and secure the Console Tube (2) to the main frame.
  • Page 8 Assembly Instruction 7. Insert the batteries provided into the back of the Monitor(15) 8. Connect the Pulse Wires (66) and Extension Wire (58) to the cables from the Monitor (15). Secure Monitor (15) to Console Tube using four Screws (39). Note: The four Screws(39) will already be installed into the back of Monitor (15) when you remove it from the box...

  • Page 9: Console

    Console Batteries Installation Please install 2 pieces of AA 1.5V batteries in the battery case on the back of monitor. (Whenever Batteries are removed, all the functions values will be reset to zero.) Auto On/Off While the user starts to do exercise, the Display will show the workout value automatically.

  • Page 10: Monitoring Your Heart Rate

    Monitoring Your Heart Rate To obtain the greatest cardiovascular benefits from your exercise workout, it is important to work within your target heart rate zone. The American Heart Association (AHA) defines this target as 60%-75% percent of your maximum heart rate. Your maximum heart rate may be roughly calculated by subtracting your age from 220.
  • Page 11 Monitoring Your Heart Rate...

  • Page 12: Exploded View

    Exploded View...

  • Page 13: Parts List

    Part List ITEM Q’TY ITEM Q’TY PART NAME PART NAME Frame V-Belt Console Tube Locking Knob(31mmL) Seat Post Slider Seat Round Bushing Front Foot Tube Sensor w/Wire Rear Foot Tube M5x10mm Metal Screw Locking Knob (22mmL) Eyebolt 6x40mm Pulley Adjustment Channel Mag Brake 3/8”x26mm Nut Cap Tension Knob Assembly...

  • Page 14: Warranty / Service

    (as detailed in this instruction manual), or repairs not provided by ACHIEVE. Nor does this warranty extend to products used for commercial or rental purposes. This warranty does not cover ordinary wear, tear and weathering, failure to follow directions, improper installation, improper maintenance or acts of God (such as damage caused by storms, lightning and by snow or ice).
