Summary of Contents for Achieve F000017
- Page 1 OWNER’S MANUAL MODEL: F000017 BFE Service Centre: 07 3272 7010 www.bfe.net.au...
-
Page 2: Table Of Contents
Table of Contents Page Exploded View ______________________ Part List ___________________________ Important Safety Information _____________ Before You Start _____________________ Assembly Instruction _________________ __ Console ___________________________ Warranty / Service ___________________ BFE Service Centre: 07 3272 7010 www.bfe.net.au... -
Page 3: Exploded View
Exploded View BFE Service Centre: 07 3272 7010 www.bfe.net.au... -
Page 4: Part List
Part List ITEM Q’TY PART NAME ITEM Q’TY PART NAME l with Strap t l e v l i ) r e x " e r i h t i Crank with Pulley Assembly TP M3x8mm Screw e r i Tension Knob Assembly Tension Cable Bracket Bottom Left Housing... -
Page 5: Important Safety Information
Important Safety Information WARNING! Before using this unit or starting any exercise program, consult your physician. This is especially important for persons over the age of 35 and/or persons with pre-existing health problems. The manufacturer or distributor assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 6: Before You Start
Before You Start Thank you for purchasing this new Achieve Mag Bike! This quality product you have chosen was designed to meet your needs for cardiovascular exercise. Before you start, please read the Owner's Manual and become familiar with the operation of your new unit. -
Page 7: Assembly Instruction
Assembly Instruction REMOVE ALL SECURITY TAPE AND WRAPPING BEFORE BEGINNING 1. Attach Foot Tubes (4 & 4A) to Main Frame (1) using : Qty 4 –(16) Carriage Bolt Qty 4 –(27) Washer Qty 4 –(42) Acron Nut Make sure that the Foot Tube (4 &4A) with Front Foot Caps (13) 2. - Page 8 Assembly Instruction 3. Turn Locking Knob (5) counterclockwise to loosen and slide the Seat Post (3) into Main Frame (1), then secure the Locking Knob(5) into the hole of Seat Post for proper seat height. * IMPORTANT Locking Knob (5) must be to locked clockwise tightly into hole in Seat Post (3) before you sit on the seat.
- Page 9 Assembly Instruction 5. Connect the Extension Wire (38) in the console tube to the Sensor Wire (36) in the main frame. Connect the Tension control wire (8) in the console tube into the slot of the Tension Cable Bracket (39). Then slide the Console Tube (2) onto the Main Frame Assembly and secure the Console Tube (2) to the main frame.
- Page 10 Assembly Instruction 7. Insert the batteries into the back of the Monitor (14) 8. Connect the Extension Wire (38) to the wire out from Monitor (14). Insert the Monitor (14) into the top area of Console Tube( 2) directly and secure with the screws (58). Note: The two Screws (58) are installed under the console.
-
Page 11: Console
Console Auto On/Off While the user starts to do exercise, the Display will show the workout value automatically. Once stop exercising over 256 sec, the Display will turn off. But the workout value of odometer will be stored. When user starts exercise again, workout value of odometer will accumulate continuously. -
Page 12: Warranty / Service
Please read and retain this manual as it will assist with identification for parts and service. LIMITED WARRANTY BOYLES FITNESS warrants its C105 Mag Bike (F000017) to be free from defects in material and workmanship under normal use and service conditions for a period of 12 months from the date of purchase of this article.
