Extension Channel
Rate
Phy Mode
Subnet
Security
Peer Mac Address
Packet-OVERDRIVE This feature can enhance the performance in data transmission
With 802.11n, there is one option to double the bandwidth per
channel. The available extension channel options will be varied
according to the Channel selected above. Configure the
extension channel you want.
If you choose 11g Only, 11b Only or 11n Only, such feature will
be available for you to set data transmission rate.
Data will be transmitted via communication channel, HTMIX.
LAN-A is specified for connection.
Select WEP, TKIP or AES as the encryption algorithm.
Four peer MAC addresses are allowed to be entered in this page
at one time.
about 40%* more (by checking Tx Burst). It is active only when
both sides of Access Point and Station (in wireless client) invoke
this function at the same time. That is, the wireless client must
support this feature and invoke the function, too.
Note: Vigor N61 wireless adapter supports this function.
Therefore, you can use and install it into your PC for matching
with Packet-OVERDRIVE (refer to the following picture of
Vigor N61 wireless utility window, choose Enable for
TxBURST on the tab of Option).
49
VigorAP 710 User's Guide
