When you choose AP Bridge-WDS, you will need to configure the following page.
Available settings are explained as follows:
Item
Phy Mode
Subnet
Security
Peer MAC Address
VigorAP 710 User's Guide
c e d S e t t i n g s f o r A
c e d S e t t i n g s f o r A
Description
Data will be transmitted via HTMIX communication channel.
Each access point should be setup to the same Phy mode for
connecting with each other.
LAN-A is specified for connection.
Select WEP, TKIP or AES as the encryption algorithm. Type the
key number if required.
Type the peer MAC address for the access point that VigorAP
710 connects to.
