Draytek VigorAP 710 User Manual page 56

Mode
Hide SSID
SSID
Isolate LAN
Isolate Member
VLAN ID
Mac Clone
Channel
VigorAP 710 User's Guide
At present, VigorAP 710 can connect to 11b only, 11g only, 11n
only, Mixed (11b+11g), Mixed (11g+11n) and Mixed
(11b+11g+11n) stations simultaneously. Simply choose Mixed
(11b+11g+11n) mode.
Check it to prevent from wireless sniffing and make it harder for
unauthorized clients or STAs to join your wireless LAN.
Depending on the wireless utility, the user may only see the
information except SSID or just cannot see any thing about
VigorAP 710 while site surveying. The system allows you to set
three sets of SSID for different usage.
Set a name for VigorAP 710 to be identified. Default settings is
DrayTek.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for wired PC in LAN.
Check this box to make the wireless clients (stations) with the
same SSID not accessing for each other.
Type the value for such SSID. Packets transferred from such
SSID to LAN will be tagged with the number.
If your network uses VLANs, you can assign the SSID to a
VLAN on your network. Client devices that associate using the
SSID are grouped into this VLAN. The VLAN ID range is from
3 to 4095. The VLAN ID is 0 by default, it means disabling the
VLAN function for the SSID.
Check this box and manually enter the MAC address of the
device with SSID 1. The MAC address of other SSIDs will
change based on this MAC address.
Means the channel of frequency of the wireless LAN. You may
switch channel if the selected channel is under serious
interference. If you have no idea of choosing the frequency,
please select AutoSelect to let system determine for you.
48
