3
.
1
O
p
e
r
a
t
i
o
n
3
.
1
O
p
e
r
a
t
i
o
n
This page provides several available modes for you to choose for different conditions. Click
any one of them and click OK. The system will configure the required settings
automatically.
Available settings are explained as follows:
Item
AP
AP Bridge-Point to
Point
AP Bridge-Point to
Multi-Point
AP Bridge-WDS
Universal Repeater
VigorAP 710 User's Guide
M
o
d
e
M
o
d
e
Description
This mode allows wireless clients to connect to access point and
exchange data with the devices connected to the wired network.
This mode can establish wireless connection with another
VigorAP 710 using the same mode, and link the wired network
which these two VigorAP 710s connected together. Only one
access point can be connected in this mode.
This mode can establish wireless connection with other VigorAP
710s using the same mode, and link the wired network which
these VigorAP 710s connected together. Up to 4 access points
can be connected in this mode.
This mode is similar to AP Bridge to Multi-Point, but access
point is not work in bridge-dedicated mode, and will be able to
accept wireless clients while the access point is working as a
wireless bridge.
This product can act as a wireless range extender that will help
you to extend the networking wirelessly. The access point can
act as Station and AP at the same time. It can use Station
function to connect to a Root AP and use AP function to service
all wireless clients within its coverage.
24
