Wireless Monitor

Operating Instructions

VL-W600BX
Model No.
Thank you for purchasing a Panasonic Wireless Monitor.
This unit is an accessory unit for Panasonic Wireless Video Intercom System.
You must register to the main monitor station before using.
Please read these Operating Instructions before using the unit and save for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic VL-W600BX

Summary of Contents for Panasonic VL-W600BX

  • Page 1: Operating Instructions

    Model No. Thank you for purchasing a Panasonic Wireless Monitor. This unit is an accessory unit for Panasonic Wireless Video Intercom System. You must register to the main monitor station before using. Please read these Operating Instructions before using the unit and save for future reference.

  • Page 2: Table Of Contents

    Table of Contents Important Information Important safety instructions ......................3 Additional safety information ......................4 For best performance .........................5 Product names used in these Operating Instructions ..............6 Preparation Accessory information ........................7 Location of controls ..........................7 Charging the sub monitor station ....................11 Registering the sub monitor station to the main monitor station (REGISTRATION) ......13 LCanceling the registration (CANCELLATION) ....................14 Doorphone...

  • Page 3: Important Information

    Important Information Important safety instructions 1) Read these instructions. All the safety and operating instructions should be read before the appliance is operated. 2) Keep these instructions. The safety and operating instructions should be retained for future reference. 3) Heed all warnings. All warnings on the appliance and in the operating instructions should be adhered to.

  • Page 4: Additional Safety Information

    Important Information Additional safety information 1. Use only the power source marked on the unit. If you are not sure of the type of power supplied to your home, consult your dealer or local power company. 2. Use only the specifi ed AC adaptor. 3.

  • Page 5: For Best Performance

    Important Information For best performance Before using LIt is prohibited to disassemble or modify this unit. Contact the dealer where you purchased this unit for repair. LWhen power fails, this unit cannot be used. LFor the recorded image: The recorded image may be lost when: –...

  • Page 6: Product Names Used In These Operating Instructions

    Important Information Using near medical equipment LConsult the manufacturer of any personal medical devices, such as pacemakers or hearing aids, to determine if they are adequately shielded from external RF (radio frequency) energy. (The unit operates in the frequency range of 2.4 GHz to 2.48 GHz, and the power output level can range from 0.03 to 0.175 watts.) Do not use the unit in health care facilities if any regulations posted in the area instruct you not to do so.

  • Page 7: Preparation

    Preparation Accessory information Included items Item Quantity Notes AC adaptor Cord length: Approx. 1.8 m Battery ------ Battery cover ------ Charger ------ Charger stand ------ Wood screws For the charger. (3.5 mm x 18 mm) Washers For the charger. Location of controls Rear view Charger LTo assemble the charger stand, see page 11.
  • Page 8 Preparation Front view A Monitor display (page 9) B {DOOR KEY} button LAllows you to open the door when the door opener is connected to the main monitor station (page 28). C {PAGE} button V L - W LPress to page the main monitor station or another sub 6 0 0 monitor station (page 17, 24).
  • Page 9 Preparation Monitor display The following display is example for description purposes, and it may differ from the actual display. LThe monitor display is turned off during standby. When you press {OFF}, the information display appears. D E F VL-GM002 DOOR KEY DOOR CAMERA PAGE...
  • Page 10 Preparation E Indicates that the door is opened when the door K Indicates the operation of the navigator key. opener is connected to the main monitor station (page (The display varies depending on the operation.) 28). F Indicates the level of the reception. Strong Use within this range.

  • Page 11: Charging The Sub Monitor Station

    Preparation Charging the sub monitor station Insert the battery. A Align the terminals and insert. Terminals B Close the battery cover. Assemble the charger stand, and plug the AC adaptor into the power outlet (100 – 240 V AC). To assemble the charger stand A Plug the connector of the AC adaptor into the jack on the charger.
  • Page 12 Preparation Place the sub monitor station on the charger and charge the battery. (At the fi rst time of charging, it takes about 7 hours to complete charging.) While charging: The CHARGE indicator lights up. When charging is complete: The CHARGE indicator turns off. LLocate the charger where “OUT OF RANGE”...

  • Page 13: Registering The Sub Monitor Station To The Main Monitor Station (Registration)

    Preparation Registering the sub monitor station to the main monitor station (REGISTRATION) Place the sub monitor station to be registered near the main monitor station and then operate the sub monitor station within 2 minutes in succession to the operations of the main monitor station. LCharge the sub monitor station to be registered for about 5 minutes before registration (page 11).

  • Page 14: Lcanceling The Registration (Cancellation)

    Preparation Canceling the registration (CANCELLATION) You can cancel the registration of a sub monitor station if you do not use it. LPlace the sub monitor station to be canceled near the main monitor station and then operate the sub monitor station.

  • Page 15: Doorphone

    Doorphone Answering a call When you receive a call from a door station, the sub monitor station rings and the TALK indicator fl ashes. You can monitor the visitor on the monitor display before answering a call. When a ringer tone is heard, press {TALK}. Speak to the visitor.
  • Page 16 Doorphone If it is diffi cult to hear the visitor’s voice due to noise (Press-to-talk mode) You can speak with the visitor alternately by pressing {TALK} to switch between the talking mode and the receiving mode. Press and hold {TALK} for about 2 seconds during a call. LA beep sounds, and “...

  • Page 17: Transferring A Call

    Doorphone Transferring a call To transfer a call using the sub monitor To receive a transferred call using the station: sub monitor station: During a door call, press {PAGE} and talk to the When the paging call is heard, press {TALK} paged party.

  • Page 18: Answering Another Call During A Call Or While Monitoring

    Doorphone Answering another call during a call or while monitoring When receiving another call during a call or while monitoring, the ringer tone is heard while fl ashing button and display indication notify you which device is calling. Camera 1 – 4* Door station 2* Door station 1 During a call or while monitoring...

  • Page 19: Camera

    Camera Monitoring the view from the camera (Camera monitor) You can monitor the sound and camera of the place where the camera is located. {CAMERA} {BRIGHT} { } {▲} {OFF} {TALK} Press {CAMERA}. LThe image taken by the camera will be shown on the display, and you will hear the sound from the camera. (The sound from your end will not be heard at the camera.) LWhen 2 or more cameras are registered, press {CAMERA} repeatedly to select the desired camera.

  • Page 20: Answering A Call From The Camera

    Camera Answering a call from the camera When the sensor detects motion, the sub monitor station rings and the {CAMERA} button fl ashes. The image taken by the camera appears on the display. When a ringer tone is heared, press {CAMERA}. LYou will hear the sound from the camera.

  • Page 21: Recording

    Recording Recording an image The main monitor station can automatically or manually record (save) up to 100 images from the door station or the camera in total. For more detailed functions, refer to the Operating Instructions included with the main monitor station. Auto recording When you receive a call in standby mode, images are automatically recorded.

  • Page 22: Viewing Recorded Images

    Recording Viewing recorded images You can view or delete recorded images, or protect up to 20 images. During standby, press {D} and select the desired item to view by using { } or {▲}. “DOOR NEW PICS”: Recorded images taken by the door station when you did not answer calls “DOOR PICS”: All recorded images taken by the door station { } { }...
  • Page 23 Recording Recorded images taken by the door station When “DOOR STATION PICTURE REC When “DOOR STATION PICTURE REC NUMBER” is set NUMBER” is set to “1 PICTURE” (Refer to to “4 PICTURES” (Refer to the Operating Instructions the Operating Instructions included with included with the main monitor station): the main monitor station) (default setting): 1st image*...

  • Page 24: Intercom

    Intercom Making an intercom call from the sub monitor station To call from the sub monitor station: To answer an intercom call: Press {PAGE} and talk to the paged party. When the paging call is heard, press {TALK}. LThe TALK indicator lights up. When the paged party answers the call, talk with Talk with the other party.

  • Page 25: Programming

    Programming Changing the function settings (Function list) Changing the settings You can change and set the functions of “SUB” and “CAM”. LWhen receiving a call while setting or no operation is done for about 90 seconds, the setting function screen automatically quits.
  • Page 26 Programming Functions of the sub monitor station The functions listed below can be set when selecting “SUB” in step 2 on page 25. The default setting is indicated in bolds. Functions Contents VOICE ANSWER You can answer a call from the door station, the main monitor station or the sub monitor station by answering with a clear voice such as “Yes”...
  • Page 27 Programming Functions of the camera The functions listed below can be set when selecting “CAM” in step 2 on page 25. You can set the functions of the camera 1 – 4 separately. The default setting is indicated in bolds. Functions Contents CAM RINGER...

  • Page 28: Adjusting The Volume

    Programming Adjusting the volume Ringer volume You can change the volume of the ringer heard when receiving calls from the door station or the camera. To adjust the ringer volume of the door station: During standby, press {▼} or {▲}. Each time you press {▼}, the volume level decreases.

  • Page 29: Help

    Remove the old battery. Insert the new battery and charge it (step 1 and 3 on page 11-12). Important: LUse only the rechargeable Panasonic battery HHR-P103. – Battery specifi cations: Rechargeable nickel metal hydride (Ni-MH) battery (3.6 V DC, 650 mAh)

  • Page 30: General Information

    General Information Technical data about this product Sub monitor station (VL-W600BX) Power supply: Ni-MH battery (3.6 V DC / 650 mAh) Dimensions: Approx. height 157 mm x width 52 mm x depth 35 mm Mass (Weight): Approx. 175 g Operating environment: 0 °C to 40 °C, Up to 90% RH (Relative Humidity) non condensing...
  • Page 31 Notes...
  • Page 32 Copyright: ● This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd. ● Portions of this software are based in part on the work of the Independent JPEG Group.
