- Page 1 Got questions on how the GT707 series HMI can maximixe your process and improve quality? Contact Ramco Innovations today! Email us at nsales@ramcoi.com Ramco Innovations www.panasonicsensors.com (800) 280-6933...
- Page 2 Copyright / Trademarks - This manual and its contents are copyrighted. - You may not copy this manual in whole or part, without written consent of Panasonic Industrial Devices SUNX Co., Ltd. - Windows is a registered trademark of Microsoft Corporation in the United States and other countries.
- Page 3 Types of Manual There are different types of users manual for the GT707 series, as listed below. Please refer to a relevant manual for the unit and purpose of your use. The manuals can be downloaded on our website: http://industrial.panasonic.com/ac/e/dl_center/manual/...
-
Page 4: Table Of Contents
Table of Contents 1. System Configuration ............1-1 List of Models ..................1-2 1.1.1 GT Series Main Unit ................1-2 1.1.2 Options ....................1-2 Screen Creating Tool ................1-3 1.2.1 Tools Required for Screen Creation ............1-3 1.2.2 Software Usage Environment and Applicable Cables ......1-3 2. - Page 5 What to Do If an Error Occurs ............... 4-2 Error Codes and How to Handle Them ..........4-7 4.2.1 About Error Codes................... 4-7 4.2.2 GT707 Series Error Codes ..............4-7 4.2.3 When Connected to a FP Series PLC............. 4-9 4.2.4 When Performing General-purpose Serial Communication ....4-10 5.
- Page 6 Before You Start Usage conditions Ambient temperatures: 0 to +50 C Ambient humidity should be 20 to 85% RH (at 25 C) and non-condensing. Usable alltitude: 2000 m above sea level or lower For use in pollution degree 2 environment Do not use it in the following environments.
- Page 7 Touch switches Always operate the touch switches with fingers. As the touch switches may be damaged due to the excessive load or shock (caused when being operated with any tools), the touch switches should be operated within the specified control force. Also, if the touch switches are pressed like kneading, the electrode may be worn out exceptionally, and cause the malfunction.
- Page 8 Ramco Innovations www.panasonicsensors.com (800) 280-6933...
-
Page 9: System Configuration
System Configuration Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 10: List Of Models
1.1 List of Models 1.1.1 GT Series Main Unit Front Power Model Display Interface specifications Model No. panel supply color COM port for connecting an 65536-color TFT color LCD external device (800x480 dots) RS-232C (D-sub 9-pin) GT707 24V DC Black AIG707WCL1G2 LED backlight Port for connecting tool software... -
Page 11: Screen Creating Tool
1.2 Screen Creating Tool 1.2.1 Tools Required for Screen Creation 1. Screen creation tool software This software is used for creating screens and making various settings. 2. Screen transfer cable (Cable for connecting a PC) A commercial USB cable is necessary. 1.2.2 Software Usage Environment and Applicable Cables Screen creation tool software Terminal GTWIN Ver.3 Hard disk... - Page 12 Ramco Innovations www.panasonicsensors.com (800) 280-6933...
-
Page 13: Names And Functions Of Parts
Names and Functions of Parts Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 14: Names And Functions Of Parts
2.1 Names and Functions of Parts 2.1.1 GT707 Names and functions of parts Name Function Various screens are displayed here. Switches can be operated and data entered Touch screen simply by touching the touch screen. A sheet is affixed to the touch panel to protect it from scrathes when shipping. -
Page 15: Operation Mode Setting Switches
2.1.2 Operation Mode Setting Switches Reserved for Normal use Inhibit system Memory clear Mode system (Factory default) menu shift menu display (Usage prohibited) Switch setting Operation when selecting the memory clear menu display [Clear Memory] menu is displayed by selecting the memory clear menu display and turning the power supply on. - Page 16 Ramco Innovations www.panasonicsensors.com (800) 280-6933...
-
Page 17: Installation And Wiring
Installation and Wiring Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 18: Installation
3.1 Installation 3.1.1 Installation Environment When installing and using the GT series, always make sure the following conditions are observed. Usage conditions Ambient temperatures: 0 to +50 C Ambient humidity should be 20 to 85% RH (at 25 C) and non-condensing. Usable alltitude: 2000 m above sea level or lower For use in pollution degree 2 environment Do not use it in the following environments. -
Page 19: Restriction According To Mounting Directions
3.1.2 Restriction According to Mounting Directions If the unit is used in a vertical orientation or installed in a horizontal orientation, note that the ambient usage temperature should be as below. Ambient Model name Condition temperature Horizontally installed GT707 0 to 50 C Vertically used Horizontally installed Vertically used... -
Page 20: Gt707 Installation Method
3.1.5 GT707 Installation Method Secure the GT to the installation panel using the fittings and screws (4 sets/per unit) provided with the unit. PROCEDURE 1. Place the GT unit in the installation panel. 2. Insert the fittings into the grooves of the GT unit, and slide them to be fixed. 3. -
Page 21: Installing In Vertical Orientation
3.1.6 Installing in Vertical Orientation The GT series can be installed upright. The power supply connector is placed on the top side as illustrated below. Select the vertical type when selecting a GT model in GTWIN. Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 22: Wiring The Power Supply
3.2 Wiring the Power Supply 3.2.1 Precautions on Wiring Perform wiring and placement of the cable so that there is no impression of external noise on the cable and no induction. This product conforms to EN61131-2 for the European EMC Directive (EMC Directive 2004/108/EC). -
Page 23: Wiring Of Terminal Block
3.2.3 Wiring of Terminal Block Layout of terminal block for power supply Pin No. Function +24 V Functional ground Suitable wires (strand wire) Nominal cross- Size Rated temperature Tightening torque sectional area AWG24 to 16 0.2 to 1.25 mm 0.5 to 0.55 N m 75 C or more Wiring method When removing the wire's insulation, be careful not to scratch the core wire. -
Page 24: Grounding
3.2.4 Grounding Be sure to ground when the influence of noise is great The unit is tolerant against noise in normal environments, but if the environment is particularly susceptible to noise, please ground. Use dedicated grounding Make the grounding point as close as possible to the GT and keep the distance of the grounding wire short. -
Page 25: Wiring Of Com Port
3.3 Wiring of COM Port 3.3.1 Specifications of COM Port Specifications of GT707 COM port Pin No. Name Abbr. Signal direction N.C. RS-232C Receive Data External devices to GT RS-232C Send Data GT to External devices N.C. Signal Ground N.C. RS-232C Request to Send GT to External devices RS-232C Clear to Send... -
Page 26: Wiring Example Of Com Port
AFPG801 / AFPG802 / AFPG806 Usable in combination with each FP7 CPU unit or FP7 serial communication unit and the following FP7 communication cassettes. AFP7CCS1 / AFP7CCS2 / AFP7CCS1M1 FP series GT707 series COM port terminal Signal Signal Function Pin No. - Page 27 Use the mini-DIN 5-pin round connector for the connection on the FP-series PLC TOOL port side. The following figure shows the connection with the cable AFC8503/AFC8503S. The FG terminals of PLC and GT707 are connected. FP series GT707 series TOOL port terminal Signal Signal Function Pin No.
-
Page 28: Communication With Plc
3.4 Communication with PLC 3.4.1 Automatic Communication Settings Function Overview of Automatic Communication Settings Function After turning on the power supply, if there is not response from the PLC connected to the GT, the GT switches to the automatic setting mode for the communication conditions. In the automatic setting mode, commands are sent to the PLC while changing the communication conditions in the sequence shown below. -
Page 29: Through Function
PLC programs can be edited or monitored through the GT series. The through function is always enabled when the PLC type for GT is set to Panasonic PLC. It can be used in combination with Panasonic PLC equipped with an interface. -
Page 30: Battery For Clock
3.5 Battery for Clock 3.5.1 Battery for Clock For using the clock function built-in the GT, a battery for the clock should be mounted. Even when the power supply is off, the clock works. Battery for clock Item name Appearance Specifications Model No. -
Page 31: Lifetime And Time For Replacement Of Battery For Clock
3.5.3 Lifetime and Time for Replacement of Battery for Clock Lifetime of battery for clock Battery life, when operating at a normal temperature (25 C), a normal humidity (65% RH), is as follows. GT model Life GT707 Approx. 5 years Detection of battery error (1) Battery mark Battery life is detected when the power of the GT turns OFF and ON. - Page 32 Ramco Innovations www.panasonicsensors.com (800) 280-6933...
-
Page 33: Troubleshooting
Troubleshooting Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 34: What To Do If An Error Occurs
4.1 What to Do If an Error Occurs Problem Cause Solution Check the power within the specifications is Power is not on. supplied. Check the capacity of the power supply unit if it is The power voltage may be low. enough for the GT's power consumption. - Page 35 Problem Cause Solution No screen number has been written to the screen setting area (the first word in the basic Specify a correct screen number. communication area word device) from the PLC. Screen doesn't The screen number to which you switch.
- Page 36 Problem Cause Solution Bit F of the first word in the Buzzer sounds basic communication area bit continuously. device is set to ON. Refer to the baxic communication area map and The backlight flashing flag or check the operation of the bit allocated to PLC. Backlight color the backlight enable flag of the changes/flashes.
- Page 37 Operation security function Problem Cause Solution “Incorrect password.” Is displayed An unregistered Enter the registered password. on the login screen. password was entered. An incorrect password “Incorrect password.” Is displayed was entered in the Enter the registered password correctly. on the password change screen. Current password field.
- Page 38 When using an SD memory card Data may be erased or the SD memory card may be damaged during the operation. Take measures for the situations as below. Problem Measures Transmitting GT configuration setting file using the logging function clears the information on the RAM.
-
Page 39: Error Codes And How To Handle Them
4.2.1 About Error Codes When an error occurs in the GT series, an error code displays at the top right of the screen. There are two types of error codes, GT707 series error codes and PLC error codes. 4.2.2 GT707 Series Error Codes List of error codes Code No. - Page 40 Code No. Content Cause and solution SD memory card The SD memory card cannot be recognized. Check the SD memory **1006 recognition error card used. PLC model unmatch **1020 Check if the PLC program for transfer matches the destination PLC. error PLC model **1021...
-
Page 41: When Connected To A Fp Series Plc
4.2.3 When Connected to a FP Series PLC Error codes which are sent from the PLC are listed in the table below. For details, refer to the table of MEWTOCOL-COM communication errors in PLC user's manuals. List of error codes Code No. -
Page 42: When Performing General-Purpose Serial Communication
4.2.4 When Performing General-purpose Serial Communication List of error codes Error code Error name Measures The value of BCC may be incorrect. Check if there is no calculation **0000 BCC error mistake. **0001 Format error A command format may be incorrect. Check if it is correct. A command used is not supported with the version of the GT. -
Page 43: Specifications
Specifications Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 44: Gt707 Specifications
5.1 GT707 Specifications 5.1.1 General Specifications Item Specifications Rated voltage 24V DC Operating voltage 21.6 to 26.4V DC range Power consumption 6 W or less (250 mA or less) Operating ambient 0 to +50 C temperature Operating ambient 20 to 85% RH (at 25 C), non-condensing humidity Storage ambient -20 to +60 C... -
Page 45: Performance Specifications
5.1.2 Performance Specifications Item Specifications Display device TFT color LCD Number of dots 800 (W) x 480 (H) dots Displayable area 153.8 (W) x 85.6 (H) mm Display (Note 1) Backlight LED backlight Can be adjusted on the menu screen, GTWIN configuration settings Backlight or PLC. -
Page 46: Function Specifications
Programs of Panasonic FP series PLCs can be uploaded/downloaded via SD memory cards. PLC backup/restore Programs and registers of a Panasonic FP series PLC connected to the COM port can function (Note 5) be backed up in the GT internal memory. -
Page 47: Interface Specifications
Item Specifications SD memory card, SDHC memory card Support media (Note 1) (The manufacturer name that the operation check has done: Panasonic Corporation) Conforms to SD standard. Supported format standard (Please format with a format software for SD memory cards.) (Note 1): Check the usable temperature range of a SD memory card to be used before use. -
Page 48: Dimensions
5.2 Dimensions 5.2.1 GT707 Main Unit Dimensions (Unit: mm) Panel cutout dimensions (Unit: mm) Ramco Innovations www.panasonicsensors.com (800) 280-6933... -
Page 49: For Connecting Plc (Afc8503/Afc8503S)
5.2.2 For Connecting PLC (AFC8503/AFC8503S) This is the cable used for connecting the GT707 to the tool port of Panasonic PLC, FP0R/FP- Ramco Innovations www.panasonicsensors.com (800) 280-6933... - Page 50 Ramco Innovations www.panasonicsensors.com (800) 280-6933...
- Page 51 Record of changes Manual No. Date Record of Changes WUME-GT707H-01 Aug.2015 1st Edition Ramco Innovations www.panasonicsensors.com (800) 280-6933...
