PACKAGE CONTENTS

• [1] Primal Charger
• [1] HCT-Plug to Mini/Micro plug adapter
• [1] Documentation package

COMPATIBLE BATTERY TYPES FOR USE WITH YOUR CHARGER

• Nickle Cadmium (NiCd)
› 1 (1.2V) - 8 (9.6V) cells
• Nickle Metal-Hydride (NiMH)
› 1 (1.2V) - 8 (9.6V) cells

UNBOXING

1. Remove the charger from the box.
a. Ensure the plug is compatible with your battery.
i. NOTE: There are many different types of battery plugs on the market. If yours does not fit the standard supplied plugs, please
visit your local hobby dealer to purchase the correct adapter.
2. Read charging instructions and understand all warnings and cautions before proceeding.
a. This product is not a toy and should not be charged, operated, or maintained without supervision of an adult.
b. It is necessary to follow all manufacturer's charging instructions per each battery type.

INTRODUCING THE PRIMAL CHARGER

1
CHARGE STATUS LED (RED/GREEN)
AIR VENT
11
(KEEP CLEAR)
LiPo JST-XH 2s Balance Port
7
LiPo JST-XH 3s Balance Port
9
THE CONTROL PANEL
BUTTON TO HOLD WITH SAFE START BUTTON
TO BEGIN LIPO CHARGE
3
LiPo CHEMISTRY BUTTON
2
MULTI-CHEMISTRY AC PEAK DETECTION BALANCE CHARGER
MAIN CHARGE LEADS
5
CHARGE CURRENT SELECT
• Lithium Polymer (LiPo)
› 2s (7.4V) - 3s (11.1V) cells (series configuration)
2
CHARGE CURRENT LEDs (RED, 0.5-4A)
8
4
SAFE START
3
10
11
COOLING FAN
(KEEP CLEAR)
BUTTON TO HOLD WITH SAFE START
3
BUTTON TO BEGIN NIXX CHARGE
3
NiCd or NiMH (NiXX) CHEMISTRY BUTTON
