Hdav HD4?C6E Setup Manual

T S :
ECHNICAL PECIFICATIONS
- Max. Resolutions
- HDMI Audio Support
- HDMI Video Bandwidth 340MHz (10.2Gbps)
- HDCP/DDC/CEC
- TMDS Input Voltage
DDC Input Voltage
- IR Frequency
- IR Cable Max Distance
- Serial Protocol
- Serial Bandwidth
- LAN Protocol
- LAN Bandwidth
- LAN Protocol
- LAN Cable Termination
- Connectors
- Power Supply
- Operating Temperature
- Enclosure / Net Weight
- Standard s
- Warranty
- Country of Origin
- SKU / UPC
Do not attempt to service this unit yourself. Provide proper ventilation and air circulation.
All names and trademarks are property of their respective companies.
All information is subject to change without notice.
HDTV: 480p, 720p, 1080i/p
PC: 1920x1200 @ 60Hz
Stereo, DTS-HD, Dolby TrueHD
Supported
1.2v (peak-to-peak)
5v (peak-to-peak)
20-80KHz
15-Meters
RS-232C
Up to 57600bps / Full Duplex
Ethernet 10/100BaseT
Up to 100MHz
IEEE802.1q, 2.3, 2.3u, 2.3x
T568B Pin-out / Straight Thru
RJ45 LAN, HDMI, 3.5mm IR, DB9
Only TX Module required External Power
24v 1A DC / 100v-240vAC
0 0
32 F to 158 F
Metal / 1.09 Lb per Module
HDMI v1.4a, DVI 1.0, HDCP v1.1
FCC, CE, RoHS
One Year
Taiwan
HD4-C6E / 0 37229 00799 2
v1.1
HDMI v1.4 3D/CEC
4‐in‐1 100‐Meter 1xCAT6 Ext. Kit
with Built‐in RS‐232 & IR Control
and 6‐Ports Fast Ethernet Hub
Setup Guide
(HD4‐C6E)
[Must be used with Solid CAT6 Cables]
Note: HD4‐C6E does not support HDMI v1.4 Ethernet Channel and ARC.
