DHSD / DHSE6800+
Dual HD / SD Serial Digital Video
Distribution Amplifiers
Installation and Operation Manual
Edition B
175-000267-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DHSD6800+ and is the answer not in the manual?

Questions and answers

Related Manuals for Harris DHSD6800+

Summary of Contents for Harris DHSD6800+

  • Page 1 DHSD / DHSE6800+ Dual HD / SD Serial Digital Video Distribution Amplifiers Installation and Operation Manual Edition B 175-000267-00...

  • Page 3: Installation And Operation

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. DHSD / DHSE6800+ Dual HD / SD Serial Digital Video Distribution Amplifiers Installation and Operation Manual Edition B March 2006...

  • Page 4: Warranty Information

    Inc. which may be registered in the United States, Canada, and / or other countries. All other trademarks are the property of their respective owners. Copyright 2006, Harris Corp. All rights reserved. This publication supersedes all previous releases. Printed in Canada. Warranty Information...

  • Page 5: Table Of Contents

    Contents Preface Manual Information ................vii Purpose ................... vii Audience ..................vii Revision History ................vii Writing Conventions ..............viii Obtaining Leitch Documents ............viii Unpacking / Shipping Information ............ix Safety Standards and Compliances ............x Safety Terms and Symbols ...............x Restriction on Hazardous Substances (RoHS) Directive ....
  • Page 6 Contents Preparing for Installation ............... 13 Checking the Packing List ............. 13 Setting Jumpers ..................14 Installing 6800+ Modules ..............17 Required Frames and Back Module Connector Types ....17 Installing DHSD / DHSE6800+ Modules ........17 Removing DHSD / DHSE6800+ Modules ........17 Making Connections ................

  • Page 7: Preface

    Preface Manual Information Purpose This manual details the features, installation procedures, operational procedures, and specifications of the DHSD / DHSE6800+ dual HD / SD serial digital video distribution amplifiers. Audience This manual is written for engineers, technicians and operators responsible for the installation, setup, and / or operation of the DHSD / DHSE6800+ dual HD / SD serial digital video distribution amplifiers.

  • Page 8: Writing Conventions

    Preface Writing Conventions To enhance your understanding, the authors of this manual have adhered to the following text conventions: Table P-2. Manual Style and Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus, windows, lists, and selection names.

  • Page 9: Unpacking / Shipping Information

    Preface Unpacking / Shipping Information Leitch has carefully inspected, tested, and calibrated this product before shipment to ensure years of stable and trouble free service. 1. Check equipment for any visible damage that may have occurred during transit. 2. Confirm that you have received all items listed on the packing list. 3.

  • Page 10: Safety Standards And Compliances

    Preface Safety Standards and Compliances See the 6800+ Safety Instructions and Standards Manual to find the safety standards and compliances for this 6800+ series product. A safety manual is shipped with every FR6802+ Frame Installation and Operation Manual and can be downloaded from the Leitch Web site at www.leitch.com.

  • Page 11: Restriction On Hazardous Substances (Rohs) Directive

    Preface Restriction on Hazardous Substances (RoHS) Directive Directive 2002 / 95 / EC—commonly known as the European Union (EU) Restriction on Hazardous Substances (RoHS)—sets limits on the use of certain substances found in electrical and electronic equipment. The intent of this legislation is to reduce the amount of hazardous chemicals that may leach out of landfill sites or otherwise contaminate the environment during end-of-life recycling.

  • Page 12: Waste From Electrical And Electronic Equipment (Weee) Directive

    Preface Waste from Electrical and Electronic Equipment (WEEE) Directive The European Union (EU) Directive 2002 / 96 / EC on Waste from Electrical and Electronic Equipment (WEEE) deals with the collection, treatment, recovery, and recycling of electrical and electronic waste products.

  • Page 13: Overview

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1 Introduction Overview The DHSD / DHSE6800+ are HD /SD dual serial digital video distribution amplifiers. The following topics are described in this chapter: • “Main Features” on page 2 •...

  • Page 14: Product Description

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Product Description The DHSD / DHSE6800+ HD / SD dual serial digital video distribution amplifiers provide two channels of HD / SD-SDI video distribution with cable equalizing (and reclocking on DHSE6800+ only). The DHSD / DHSE6800+ dual distribution amplifier provide 4 outputs for each input (two 1×4s), and provide a method that allows for a single channel distribution amplifier with 8 outputs (one 1×8).
  • Page 15 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction DHSE6800+ Features • Automatic / manual reclock rate setting at 143 Mb / s, 177 Mb / s (manual only), 270 Mb / s SDI and ASI, 360 Mb / s, 540 Mb / s; and 1.485 Gb / s •...

  • Page 16: Module Descriptions

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Module Descriptions Front Module Figure 1-1 is a generic top-front view of a typical DHSD6800+ front module.Figure 1-2 on page 5 is a generic top-front view of a typical DHSE6800+ front module.
  • Page 17 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Figure 1-2. Typical DHSE6800+ Front Module DHSD / DHSE6800+ Installation and Operation Manual...

  • Page 18: Back Modules

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Back Modules DHSD / DHSE6800+ modules can be installed with double-width back connectors in FR6802+ and FR6802+DM frames. FR6802+ Frame Back Module Figure 1-3 shows the double-width back connector module used by the Note DHSD / DHSE6800+ when installed in an FR6802+ frame.
  • Page 19 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Signal Input / Output Connections for FR6802+DM Frames Figure 1-4 shows the signal input / output connections used by the Note DHSD / DHSE6800+ when installed in an FR6802+DM frame. Distribution amplifiers with unused inputs should have the input terminated.

  • Page 20: Signal Flow

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Signal Flow Figure 1-5. Signal Flow Diagram for 1×8 Mode of Operation DHSD / DHSE6800+ Installation and Operation Manual...
  • Page 21 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction Figure 1-6. Signal Flow Diagram for 2×4 Modes of Operation DHSD / DHSE6800+ Installation and Operation Manual...
  • Page 22 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 1: Introduction DHSD / DHSE6800+ Installation and Operation Manual...

  • Page 23: Overview

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2 Installation Overview This chapter describes the DHSD / DHSE6800+ installation process, Caution including the following topics: • “Installing DHSD / DHSE6800+ Modules” on page 17 Before installing this product, read the 6800+ Series Safety •...

  • Page 24: Maximum 6800+ Frame Power Ratings

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation Maximum 6800+ Frame Power Ratings Power consumption information is listed in Chapter 4: “Specifications” on page Table 2-1 describes the maximum allowable power ratings for 6800+ frames. Note the given maximums before installing any 6800+ modules in your frame.

  • Page 25: Unpacking The Module

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation Unpacking the Module Preparing for Installation Before you install the DHSD / DHSE6800+, perform the following: • Check the equipment for any visible damage that may have Note occurred during transit.

  • Page 26: Setting Jumpers

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation Setting Jumpers The DHSD / DHSE6800+ module has two standard jumpers. Follow Note this procedure to set the jumper for the proper serial digital video signal: 1. Locate jumper set P1 on the module. Figure 2-1 shows the standard You need to configure modules...
  • Page 27 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation 2. Place a jumper on the pin that corresponds to the setting that you want. See Figure 2-2. (See page 20 for a description of the P1 settings.) Figure 2-2.
  • Page 28 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation 3. Locate Jumper set P2 / P3 on the module. Figure 2-1 on page 14 Note shows the standard location of the jumper set. 4. Place a jumper on the pin that corresponds to the mode that you Set the P2 jumper for input 1 rate control.

  • Page 29: Installing 6800+ Modules

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation Installing 6800+ Modules Required Frames and Back Module Connector Types The DHSD / DHSE6800+ modules have double-width back connectors that can be installed in an FR6802+X(F) series frame. See the FR6802+ Frame Installation and Operation Manual for details on installing back connectors in an FR6802+ frame.
  • Page 30 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: Installation DHSD / DHSE6800+ Installation and Operation Manual...

  • Page 31: Overview

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3 Operation Overview This chapter describes how to operate the DHSD / DHSE6800+ using local controls only. See the following Leitch documents for information on how to operate this product remotely: + Pilot Lite™...

  • Page 32: Understanding Jumper Controls

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Understanding Jumper Controls Introducing Jumper Control Types P2/P3 jumpers (used by DHSE6800 only) Status indicator Reclock status LEDs P1 jumper Figure 3-1. Location of the Jumper Sets and Status Indicators P1 Jumpers You can use the P1 jumper set to select the following items: Note...

  • Page 33: P2 / P3 Jumpers

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Remote Control When the jumper is set to the “remote” position, the reclocker setting is handled by +Pilot Lite only. You may select the three setting modes (automatic, manual, and bypass) remotely via +Pilot Lite.
  • Page 34 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Local Control Local Control Reclocking Mode Note In the local control reclock setting operation mode, all of the settings’ data status information appears on the Leitch +Pilot Lite control screen; Leitch recommends that you use however, you cannot change any setting in this mode via +Pilot Lite.

  • Page 35: Understanding Parameter Types

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Table 3-1. P2 / P3 Local Control Reclock Modes (Continued) Reclock Mode Description Forces channel to lock to a 540 Mb / s signal Set the jumper on the pin that allows the reclocker to handle 540 Mb / s data only •...

  • Page 36: Read-Only Parameters

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation • Numerical parameters—which require you to select a value within a numerical range • Selectable parameters—which require you to select a specific option Both numerical and selectable parameter changes are immediate. Use the available 6800+ software controls (serial / local or Ethernet remote network) to view and monitor parameter selections.

  • Page 37: Setting Remotely Controlled Parameters

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Setting Remotely Controlled Parameters Table 3-2 describes DHSD6800+ parameters that are accessible remotely; Table 3-3 on page 25 describes DHSE6800+ parameters that are accessible remotely. See your CCS control software application manual or online help for more information on setting and monitoring these parameters remotely.
  • Page 38 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Table 3-3. DHSE6800+ Remotely Controlled Parameters (Continued) Name Range Description • 0=1×8* Output configuration Allows you to select if the card is • 1=1×4 in dual 1×4 or 1×8 Input 1 routed to all outputs •...

  • Page 39: Changing Parameter Settings

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Changing Parameter Settings You can change DHSD / DHSE6800+ parameter settings locally with the card-edge jumper or remotely by selecting the Reclocking Mode parameter setting. Recalling Default Parameter Settings You cannot recall default parameter settings for DHSD / DHSE6800+ modules.

  • Page 40: Leds And Alarms

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation LEDs and Alarms Module Status Indicator LED Figure 3-2. Module Status Indicator LED The DHSD / DHSE6800+ module has a module status LED that reports the state of the module. See Figure 3-1 on page 20 for the location of this LED, and...

  • Page 41: Alarms

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Alarms Alarms are usually logged and monitored within the available 6800+ software control applications (for example, + Pilot Lite or Pilot). See the appropriate software control user manual or online help for more information.
  • Page 42 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 3: Operation Table 3-5. Module-Specific Status LEDs (Continued) Name Color Function Green Input signal is reclocked at 270 Mb / s Green Input signal is reclocked at 360 Mb / s Green Input signal is reclocked at 540 Mb / s Green...

  • Page 43: Overview

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 4 Specifications Overview The following specification tables appear in this chapter: • “Inputs” on page 32 • “Outputs” on page 32 • “Power Consumption” on page 33 • “Propagation Delay” on page 33 •...

  • Page 44: Inputs

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 4: Specifications Inputs Table 4-1. DHSD / DHSE6800+ Input Specifications Item Specification Signal type HD, SD, ASI Connector BNC (IEC169-8) Impedance 75Ω Return loss 18 dB to 1485 MHz CMRR >20 V (peak-to -peak, up to 60 Hz) Cable equalization...

  • Page 45: Power Consumption

    Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 4: Specifications Table 4-2. DHSD / DHSE6800+ Output Specifications (Continued) Item Specification Overshoot <10% of amplitude Jitter < 0.2 UI peak-to-peak Power Consumption Table 4-3. Power Consumption Specifications Item Specification DHSD6800+ 514 mA @ 3.3 Vdc;...
  • Page 46 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 4: Specifications DHSD / DHSE6800+ Installation and Operation Manual...

  • Page 47: Index

    Index Keywords Installation back modules Adjustable parameters installing modules Alarms jumpers Applications power ratings Back connectors see Back modules preparing modules Back modules 6–7, 17 removing modules Changing parameter settings required frames Controls unpacking modules control types Introduction understanding controls 20–23 applications Descriptions...
  • Page 48 Index setting parameters 25–26 Performance temperature LEDs Power consumption specifications descriptions 28–30 Power ratings module specific 29–30 Power up time module status Preparing for installation Local control jumpers Product description Manual information vii–viii Propagation delay Module specific LEDs 29–30 Module status LEDs Modules Read-only parameters back modules...
