- Page 1 Instruction Manual 880 Series Audio Distribution Amplifiers Edition I 880 ADA MAN Delivering the Moment...
-
Page 2: Contact Information
Publication Information © 2014 Imagine Communications Corp. Proprietary and Confidential. Imagine Communications considers this document and its contents to be proprietary and confidential. Except for making a reasonable number of copies for your own internal use, you may not reproduce this publication, or any part thereof, in any form, by any method, for any purpose, or in any language other than English without the written consent of Imagine Communications. - Page 3 880 Series Audio Distribution Amplifiers Instruction Manual Edition I April 2006...
-
Page 5: Table Of Contents
Amplifier Module Overview ......................11 Configuring an APD-880-0 ................. 12 Chapter 4: ARG-880 Audio Remote Gain Distribution Amplifier Module Overview ......................13 Remote Control Information ................14 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 6 ARG-880 Audio Remote Gain Distribution Amplifier Module ......29 Input ......................29 Output ......................29 Performance ....................29 ASD-880 Stereo Audio Distribution Amplifier Module ........30 Input ......................30 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
- Page 7 Preventing Electrostatic Discharge ..............35 EMC and Safety Standards .................. 38 EMC Standards .................... 38 Additional EMC Information ............... 39 Safety Standards ................... 40 Index Keywords ......................41 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
- Page 8 Contents viii 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 9: Preface
Manual Information Purpose This manual details the features, installation, operation, maintenance, and specifications for the 880 series audio distribution amplifers. Audience This manual is written for technicians and operators responsible for installation, setup, maintenance, and/or operation of the product, and is useful to operations personnel for purposes of daily operation and reference. - Page 10 • APD-880-3, -4, -5 programmable audio distribution amplifiers Applications The 880 series platform is ideal for space-constrained operations demanding full local and remote control capabilities in a routing solution. 880 series products are perfect for • Television production facilities •...
- Page 11 Indicates important information that helps to avoid and Note troubleshoot problems Obtaining Documents Technical documents can be viewed or downloaded from our website. Alternatively, contact your Customer Service representative to request a document. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 12: Unpacking/Shipping Information
Ship products back to us for servicing prepaid and, if possible, in the original packaging material. If the product is still within the warranty period, we will return the product prepaid after servicing. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 13: Standards
(Some EU member states may have different deadlines.) 880 Series Audio Distribution Amplifiers Instruction Manual xiii Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 14 Equipment that complies with the EU directive will be marked with a WEEE-compliant emblem, as shown in Figure P-2. Figure P-2. WEEE Compliance Emblem 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
- Page 15 High voltage is present. CAUTION Statements identifying conditions or practices that can result in damage to the equipment or other property. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
- Page 16 Preface 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 17: Overview
The modular concept with two fully wired mounting frame options facilitates system design. The options are as follows: • The FR-883 and FR-884 mounting frames accept up to twelve 880 series audio distribution amplifier modules. • The FR-883 frame accepts one 884PS power supply, while the FR-884 frame accepts two 884PS power supplies. -
Page 18: Chapter 1: 880 Series Mounting Frames
• Make sure that all modules are properly seated in the mounting frame. The mounting requirements of the 880 series frame options are as follows. FR-883 The FR-883 mounting frame requires 1 unit of rack space: 1¾ in. (44 mm) high ×... -
Page 19: Fr-884
× 19 in. (483 mm) wide × 11 in. (280 mm) deep. This frame can house 12 modules. Figure 1-3. FR-884 Figure 1-4. FR-884 Back Panel 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 20: Frame Cooling
To prevent electric shock, do not use the (polarized) plug with an extension cord, receptacle, or other outlet unless the blades can be fully inserted to prevent blade exposure. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 21: 884 Ps Power Supply
170 – 270VAC. Output voltage is adjustable by ±10%. Other output voltages can be achieved by changing power transformer TR1 without any additional circuit changes. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 22: Cable Harness Support Bracket
Mount the cable support bar with a 6-32 x 3/8-inch binder head screw to each bracket. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 23: Back Panel Pinout Assignments
Chapter 1: 880 Series Mounting Frames Back Panel Pinout Assignments Figure 1-5. FR-883 Back Panel Pinout Assignments Figure 1-6. FR-884 and FR-684-AV Balanced Audio Back Panel Pinout Assignments 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 24: Back Panel Connections
FR-884 Mounting Frames AMD-880 APD-880-1 APD-880-2 ARG-880 ASD-880 ATG-880 (dBm) Mono/ Remote Mono Stereo Mono Stereo Test Gain A IN A IN B IN –10 Remote Ctrl –10 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 25: Chapter 2: Amd-880 Mono Audio Distribution Amplifier Module
The extended shaft option allows for front panel gain control in the FR-883 and FR-884 mounting frames. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 26 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 2: AMD-880 Mono Audio Distribution Amplifier Module 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 27: Overview
Leitch audio amplifier to date. • APD-880-1 — Stereo in, 4 stereo out (Figure 3-2 on page • APD-880-2 — Mono in, 8 mono out (Figure 3-3 on page 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 28: Configuring An Apd-880-0
Figure 3-1. ADP-880-0 Module Figure 3-2. APD-880-1 — Stereo in, 4 stereo out Figure 3-3. APD-880-2 — Mono in, 8 mono out 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 29: Chapter 4: Arg-880 Audio Remote Gain Distribution
Unbalanced input is converted to balanced output. Isolation between modules in the mounting frame is better than 90dB over the entire audio frequency band. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 30: Remote Control Information
Ground reference and +5VDC source are located at connection 5B on the FR-883 and FR-884 frames. The actual remote connection is as follows: Figure 4-1. Remote Connections 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 31: Chapter 5: Asd-880 Stereo Audio Distribution Amplifier Module
The extended shaft option allows for front panel gain control in the FR-883 and FR-884 mounting frames. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 32 Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. Chapter 5: ASD-880 Stereo Audio Distribution Amplifier Module 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 33: Generator Module
IC4A. Its output at pin 1 is AC coupled through a 68 μF capacitor and diverted to two places, that is, the control loop and the output stage later described. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 34: Control Loop
Closing the IDENT switch will enable multivibrator IC2 and thus cause the left channel of each pair to be pulsed off and on at about once per second. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 35: Chapter 7: 884Ps Power Supply Module
170-270 VAC. Output voltage is adjustable by ±10%. Other output voltages can be achieved by changing power transformer TR1 without any additional circuit changes. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 36: Installing The 884Ps-48
• Install the 884PS-48 power supply in accordance with the schematic diagram shown in Figure 7-1. Power can only be disconnected completely from the 880 series frame through a studio installed breaker or fuse. 880 Series Audio Distribution Amplifiers Instruction Manual... -
Page 37: Branch Circuit Schematic
* “Heinemann” is a registered trademark of Eaton Corporation, Cleveland, Ohio. The AM/S series are products of Eaton Corporation. † “Buss” is a registered trademark of Cooper Bussman, St. Louis, Missouri. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 38: Maintaining The 884Ps-48
884PS-48 is installed in a frame) to make the following pin connections for the 884PS-48. Figure 7-2. XLR Connector Pin Number Connection –48 V Chassis Specifications Specifications: 884PS-48 Input 42–60 VDC 1.5A 50 VA maximum 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 39: Chapter 8: Specifications
Specifications and designs are subject to change without notice. The following specification tables appear in this chapter: • Electrical • Mechanical • Input • Output • Performance 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 40: Fr-883 / Fr-884 Mounting Frames
Height 3½ in. (88 mm) Width 19 in. (483 mm) Depth from mounting surface 11 in. (280 mm) Nominal weight (with modules) 19.6 lb (8.9 kg) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 41: Amd-880 Mono Audio Distribution Amplifier Module
< 0.01% SMPTE @ +18 dBu < 0.02% SMPTE @ +24 dBu Isolation between modules > 100 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 42: Amd-880 Mono Audio Distribution Amplifier Module (600Ω Impedance)
< 0.05%, 20 Hz – 20 kHz @ +24 dBm Intermodulation distortion < 0.02% SMPTE @ +18 dBm Isolation between modules > 100 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 43: Apd-880 Programmable Audio Distribution Amplifier Module
Isolation between modules > 100 dB, 20 Hz – 20 kHz Interchannel crosstalk > 95 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 44: Input
Isolation between modules > 100 dB, 20 Hz – 20 kHz Interchannel crosstalk > 95 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 45: Arg-880 Audio Remote Gain Distribution Amplifier Module
Isolation between modules > 100 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) Control input 0 to 5V DC +5V DC provided as output 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 46: Asd-880 Stereo Audio Distribution Amplifier Module
Isolation between modules > 100 dB, 20 Hz – 20 kHz Interchannel crosstalk > 95 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 47: Asd-880 Stereo Audio Distribution Amplifier Module (600Ω Impedance)
Isolation between modules > 100 dB, 20 Hz – 20 kHz Interchannel crosstalk > 95 dB, 20 Hz – 20 kHz Temperature range 41°– 104°F (5°– 40°C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 48: Atg-880 Audio Tone Generator Module
Output level stability < 0.1 dB Total harmonic distortion <0.1%, all outputs Output impedance 600Ω, balanced Temperature range 32°– 122°F (0° – 50° C) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 49: Appendix A: Safety Precautions, Certifications, And Compliances
Any user-serviceable components (such as fuses or batteries) are only replaceable by those components listed in the manual. IMPORTANT! Only qualified personnel should perform service procedures. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 50: Safety Terms And Symbols In This Manual
Fuse. Replace with same type and rating of fuse. Zur Vermeidung von Feuer verwenden Sie nur Sicherungen mit der für dieses Produkt geforderten Typ und Stromstärke. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 51: Preventing Electrostatic Discharge
MOUNT IN RACK ONLY INSTALLER SUR SUPPORT DE MONTAGE SEULEMENT. USE PROPER POWER CORD To avoid fire hazard, use only the power cord specified for this product. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 52 USE PROPER POWER SOURCE Do not operate this product from a power source that supplies more than the specified voltage. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
-
Page 53: Compliances
USE PROPER POWER SOURCE Do not operate this product from a power source that supplies more than the specified voltage. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 54: Emc And Safety Standards
0.15-80 MHz Sig. & Ctrl. Lines, 3 V rms 0.15-80 MHz d.c. Power Line, 1 V rms 0.15-80 MHz a.c. Power Line, 1 V rms 0.15-80 MHz Functional Earth EN61000-4-11 Voltage Dips, Short Interruptions, and Voltage Variations- Immunity Tests 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 55: Additional Emc Information
(screen) of the cable mechanically bonded to the metal shell. It is further recommended that the D-type cable connectors be of the “dimple” variety. These connectors make a better contact and consequently improve EMC performance. 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 56: Safety Standards
6th Edition, with Canadian Deviations) CAN/CSA-C22.2 Audio, Video, and Similar Electronic Equipment No. 1-98 CSA C22.2 Audio, Video, and Similar Electronic Equipment No. 1-98 including Am1 (June, 2003) 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... -
Page 57: Keywords
FR-883 output stage FR-884 specifications power consumption Audio remote gain distribution amplifier. See ARG-880 power supply 5, 19–22 Audio tone generator. See ATG-880 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation... - Page 58 33–37 Preventing electrostatic discharge Stereo audio distribution amplifier. See ASD-880 Product damage precautions Unpacking a Leitch product Programmable audio distribution amplifier. See APD-880 880 Series Audio Distribution Amplifiers Instruction Manual Copyright © 2001-2004, 2006, 2008, Harris Corporation...
