- Page 1 HSD/HSE6800+ SD/HD Serial Digital Video Distribution Amplifiers Installation and Operation Manual Edition F 175-000191-00...
-
Page 3: Installation And Operation Manual
Preliminary—Contents are proprietary and confidential. Do not photocopy or distribute. HSD/HSE6800+ SD/HD Serial Digital Video Distribution Amplifiers Installation and Operation Manual Edition F January 2010... - Page 4 No part of this product or related documentation may be reproduced in any form by any means without prior written authorization of Harris Corporation and its licensors, if any. This publication could include technical inaccuracies or typographical errors.
-
Page 5: Table Of Contents
Checking the Packing List ................11 Setting HSD6800+ Jumpers ................12 Setting HSE6800+ Jumpers ................13 Installing 6800+ Modules ................. 14 Installing HSD/HSE6800+ Modules ............. 14 Removing HSD/HSE6800+ Modules ............14 Making Connections..................14 Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 6 Module Status LED ..................23 Other LED Descriptions ................23 Specifications Inputs ......................26 Outputs ......................26 Power Consumption ..................27 Propagation Delay..................... 27 Temperature ....................27 Start-Up Time ....................27 Index Keywords ......................29 Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 7: Preface
Updated FR6802+ back connector January 2006 illustrations Moved “Troubleshooting” section to FR6802+ Frame Installation and Operation Manual Updated information concerning September 2006 jumper settings Removed reference to input January 2010 termination jumper Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 8: Writing Conventions
NOTE: Indicates important information that helps to avoid and troubleshoot problems. Obtaining Technical documents can be viewed or downloaded from our website. Alternatively, contact your Customer Service representative to request a document. Documents Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 9: Unpacking/Shipping Information
Ship products back to us for servicing prepaid and, if possible, in the original packaging material. If the product is still within the warranty period, we will return the product prepaid after servicing. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 10: Safety Standards And Compliances
RoHS-compliant and “lead-free.” Spare parts supplied for the repair and upgrade of equipment sold before July 1, 2006 are exempt from the legislation. Equipment that complies with the EU directive will be marked with a RoHS-compliant symbol, as shown in Figure P-1. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 11: Waste From Electrical And Electronic Equipment
Contact your local Sales representative for information on returning these products for recycling. Equipment that complies with the EU directive will be marked with a WEEE-compliant symbol, as shown in Figure P-2. Figure P-2 WEEE Compliance Symbol Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 12 Preface Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 13: Introduction
The HSD/HSE6800+ are SD/HD serial digital video distribution amplifiers. The following topics are described in this chapter: Main Features on page 2 Module Descriptions on page 3 Product Description on page 2 Signal Flow on page 7 Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 14: Product Description
Automatic/manual reclock rate setting at 143 Mb/s, 177 Mb/s (manual only), 270 Mb/s SDI and ASI, 360 Mb/s, 540 Mb/s; and 1.485 Gb/s (HSE6800+ only) Reclocking status report (HSE6800+ only) Automatic/enforced bypass (HSE6800+ only) Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 15: Module Descriptions
Figure 1-1. Typical HSD6800+ Front Module Figure 1-2 is a generic top-front view of a typical HSE6800+ front module. See Figure 2-3 on page 13 for jumper locations. Figure 1-2. Typical HSE6800+ Front Module Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 16 Local: Locks out external control panels and allows Local/remote card-edge control only; limits the functionality of remote control jumper software applications to monitoring Remote: Allows remote or local (card-edge) configuration, operation, and monitoring of the HSD/HSE6800+ Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 17: Back Module
Figure 1-4 shows the double-slot back connector used by the HSD/HSE6800+ when installed in an FR6802+ frame. Figure 1-3 Single-Width Back Connectors for FR6802+ Frame Figure 1-4 Double-Width Back Connectors for FR6802+ Frame Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 18 Chapter 1 Introduction Signal Input/Output Connections for FR6802+DM Frames Figure 1-5 shows the signal input/output connections used by the HSD/HSE6800+ when installed in an FR6802+DM frame. Figure 1-5 Double-Slot Back Module for FR6802+DM Frames Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 19: Signal Flow
HSD/HSE6800+ Installation and Operation Manual Signal Flow Figure 1-6. HSD/HSE6800+ Signal Flow Diagram Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 20 Chapter 1 Introduction Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 21: Installation
11 See the FR6802+ Frame Installation and Operation Manual for information about installing and operating an FR6802+ frame and its components. The HSD/HSE6800+ cannot be installed in a 6800/7000 series frame. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 22: Maximum 6800+ Frame Power Ratings
Max. Frame Max. Power Number of 6800+ Frame Type Power Dissipation Per Usable Slots Dissipation Slot FR6802+XF 120 W (frame with AC power supply) FR6802+X48 50 W 2.5 W (frame with DC power supply) Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 23: Unpacking The Module
One HSD/HSE6800+ front module HSD/HSE6800+D One standard double-slot back connector One HSD/HSE6800+ Installation and Operation Manual One standard single-slot back connector HSD/HSE6800+SR One standard double-slot back connector HSD/HSE6800+DR Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 24: Setting Hsd6800+ Jumpers
2-2. Figure 2-2 HSD6800+ Jumper Set Settings For SD slew rates, set the jumper to pins 1 and 2. For HD slew rates, set the jumper to pins 2 and 3. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 25: Setting Hse6800+ Jumpers
Figure 2-3 Location of the HSE6800+ Jumper Set and LEDs Place a jumper on the pin that corresponds to the reclocking mode that you want. See Figure 2-4. Figure 2-4 HSE6800+ Jumper Set Settings Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 26: Installing 6800+ Modules
Frame Installation and Operation Manual for information about removing HSE6800+ components in an FR6802+ frame. Modules Making Once you have installed the HSD/HSE6800+ module, you can connect it to the appropriate input and outputs. Connections Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 27 19 Setting Locally Accessible Parameters on page 20 Setting Remotely Controlled Parameters on page 21 Understanding Jumper Controls on page 16‘ Understanding Parameter Types on page 19 Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 28: Understanding Jumper Controls
The bypass mode allows you to force the input data to take the bypass path, whether it is lockable or not. Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 29 HD LED will be yellow If the reclocking is not successful, the RCLK LED will be red, the HD LED will be off, and un-reclocked data will be present at output Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 30: Remote Control
When the jumper is set to the “remote” position, the reclocker setting is handled by +Pilot Lite only. You may select the three setting modes (automatic, manual, and bypass) remotely via +Pilot Lite. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 31: Understanding Parameter Types
When you change a parameter, the effect is immediate. However, the module requires up to 20 seconds to save the latest change. After 20 seconds, the new settings are saved and will be restored if the module loses power and must be restarted. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 32: Setting Locally Accessible Parameters
Only 540 Mb/s can be locked Only ASI can be locked Only 1.485 Gb/s can be locked Bypass Allow data to bypass reclocker Remote Let CCS select the control mode Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 33: Setting Remotely Controlled Parameters
[RO] the input signal Auto Reclocking Mode Sets the module working mode 143 Mb/s 177 Mb/s 270 Mb/s 360 Mb/s 540 Mb/s Bypass Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 34: Changing Parameter Settings
CCS-enabled control panel or a CCS software application. See the appropriate Software and control panel installation and operation manual, CCS software application user Hardware manual, or CCS software application online help for information on viewing Versions software and hardware version numbers. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 35: Leds And Alarms
Input signal is reclocked at 270 Mb/s Amber Input signal is reclocked at 360 Mb/s Amber Input signal is reclocked at 540 Mb/s Amber Input signal is reclocked at 1.485 Gb/s HSE6800+ modules only; not available on HSD6800+ modules Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 36 Working status information is usually monitored within the available 6800+ software control applications (for example, +Pilot Lite or Pilot); alarms are usually logged and monitored. See the appropriate software control user manual or online help for more information. Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 37: Specifications
Power Consumption on page 27 Propagation Delay on page 27 Start-Up Time on page 27 Temperature on page 27 Specifications and designs are subject to change without notice. Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 38: Inputs
Better than 15 dB 5 MHz to 1.485 GHz worst case Signal amplitude 800 mV ± 10% DC offset 0.0 V ± 0.5 V Rise and fall time 400 to 700 pS SD/ASI < 270 pS Overshoot <10% Jitter < 0.2 UI Copyright © 2003, 2005-2006, 2010, Harris Corporation... -
Page 39: Power Consumption
3.0 ns typical Temperature Table 4-5 Temperature Specifications Item Specification Operating 41°F to 113°F (5°C to 45°C) Performance 32°F to 122°F (0°C to 50°C) Start-Up Time Start-up time for HSD/HSE6800+ modules is approximately 10 seconds. Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 40 Chapter 4 Specifications Copyright © 2003, 2005-2006, 2010, Harris Corporation...
-
Page 41: Keywords
Features 2 module status 23 Front modules 3 Local control jumpers 16 jumpers 4 LEDs 4 switches 4 Manual information vii Modules back modules 5–6 Hardware versions, reading 22 descriptions 3–6 front modules 3 Copyright © 2003, 2005-2006, 2010, Harris Corporation... - Page 42 Versions, reading hardware and soft- Performance temperature 27 ware 22 Power consumption specifications 27 Power ratings 10 Power up time 27 Product description 2 Propagation delay 27 Waste from Electrical and Electronic Equipment (WEEE) directive xi Copyright © 2003, 2005-2006, 2010, Harris Corporation...
