OWNER'S MANUAL
LP Gas Grill
A propane gas cylinder is required for
operation. This gas grill is not intended
for commercial use.
SAVE THESE INSTRUCTIONS FOR FU-
TURE REFERENCE. IF YOU ARE ASSEM-
BLING THIS UNIT FOR SOMEONE ELSE,
GIVE THIS MANUAL TO HIM OR HER TO
SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, CALL 912-
638-4724
WARNING:
Improper installation, adjustment, al-
teration, service or maintenance could
cause injury or property damage. Read
the installation, operation and mainte-
nance instructions thoroughly before
assembling or servicing this equip-
ment.
OM3001D.3
Keep your receipt with this manual
for Warranty.
(outside any enclosure)
DANGER:
DO NOT use gas grill for indoor cook-
ing or heating. TOXIC fumes can accu-
mulate and cause asphyxiation. Do
not use in or on boats or recreational
vehicles.
PROP 65 WARNING:
Chemicals known to the state of Cali-
fornia to cause cancer, birth defects
or other reproductive harm are creat-
ed by the combustion of propane.
™ & © Char-Griller / A&J Mfg.
Grillin' Pro
Model # 3001
WARNING
!
For Outdoor Use Only

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Grillin’ Pro 3001 and is the answer not in the manual?

Questions and answers

Summary of Contents for Char-Griller Grillin’ Pro 3001

  • Page 1 OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 2: If You Smell Gas

    1-912-638-4724 (USA), Mon- day-Friday 8:30am-5pm (EST). Have your grills serial number (located on the back of the grill body or on the leg) when calling. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 3: Table Of Contents

    Assembly Instructions ……………………………..page 9 – 17 Operating Grill Connecting Gas Cylinder…………………………..page 18 Cleaning and Care……………………………………page 19-20 Checking for Leaks………………………………..…page 21 Lighting Grill…...……………………………………..page 22-24 Trouble Shooting……………………………………..page 25-26 Grill Preparation………………………………………..page 27 Recipes……………………………………………..…...…page 28 - 29 Accessories……………………………………………….page 30 - 31 OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 4: Important Safety Information

    8. DO NOT use this grill or any gas product near unprotected combustible constructions. 9. Do not use in an explosive atmosphere. Keep grill area clear and free from combus- tible materials, gasoline and other flammable vapors and liquids. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 5 This grill is shipped from the factory for propane gas use only. Never use a propane cylinder with a damaged body, valve, collar or footing. Dented or rusted propane cylinders may be hazardous and should be checked by your propane gas supplier. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 6: Illustrated Parts List

    OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 7 50-0002 GREASE TRAY 10-0028 CATCH PAN, REMOVABLE 20-1025 SIDE SHELF 20-0033 POT STAND 20-0005 STACK 20-0034 HUB CAP 55-0007 STOPPER BRACKET 10-0360 SLIDER BRACKET 10-0359 TANK BLOCK BAR 10-0283 GRATE LIFTER 10-0045 OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 8: Tools, Assembly Tips And Hardware List

    ¼-20 HEX NUT…………..10 PCS ¼” LOCK WASHER……..……..33 PCS HINGE PINS………………..2 PCS LARGE HAIR COTTER PIN…….2 PCS SMALL HAIR COTTER PIN…….2 PCS SCREW…………………..………….3 PCS #10-24 x 0.40” BOLT……….6 PCS 1/4-20 x 31/4” Wing Bolt….…1 PC OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 9: Assembly Instructions

    ER, COTTER PIN and HUB CAP onto the AXLE then slide the AXLE through WHEELS and legs as shown. Finish by attaching 2nd WASHER, COTTER PIN and HUB CAP. Wheel Axle Cotter Pin Hub Cap Washer OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 10 You may need to loos- en other bolts and move the GRILL BODY slightly to get the holes in the GRILL BODY to line up with the holes in the LEGS. Lock Washer Bolt OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 11 (2) Slider Bracket (1) Stopper Bracket Slider Bracket Figure 3 Figure 2 Figure 1 Slider Bracket Stopper Bracket GRILL BODY CATCH PAN CATCH PAN Support Bracket Side Bracket CATCH PAN Figure 4 Stopper Bracket Slider Bracket OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 12 BOLTS will first go through the GRILL BODY and then screw into the SIDE BURNER and CONTROL PANEL. See Figures below. Then remove and re-install bolt in LEG BRACE to hold HOSE GUIDE in place as shown. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 13 Insert the IGNITER WIRES, which are attached to the underside of each BURNER, through the small hole in the GRILL BODY that the BURNER goes through then at- tach the wire to the back side of the ELECTRONIC IGNITER, which is attached to the OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 14 HOOD onto the GRILL BODY then screw the HINGE PINS into place and then insert COTTER PINS through the holes in the HINGE PINS on the inside of the GRILL BODY. Hinge Pin Hinge Pin OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 15 Set the POT STAND in place over the SIDE BURNER. Next install the FLARE-UP SHIELD over the BURNER TUBES. Then set the COOKING GRATES in place and in- sert UTENSILS HOOKS into the SIDE SHELF. POTS STAND OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 16: Operating Grill

    Install Igniter battery by turning the Igniter push button cap counter-clockwise until the igniter button detaches, then install a AA battery making sure the positive(+) end is toward the push button. Then re-attach the igniter button by turning it clock- wise. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 17 Any remaining glue residue can be cleaned off with a spray lubri- cant like WD-40 . Do NOT use any other type of solvent or cleaner because this will damage the finish/paint/coating on the grill. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 18: Connecting Gas Cylinder

    (refer to illustration under step 22 of page 17). DANGER: Never store a spare propane cylinder near this grill. A fire causing death or serious injury may occur if the above is not followed exactly. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 19: Cleaning And Care

    Non abrasive scour- ing powder can be used on stubborn stains, then rinse with water. Heat Shield – Clean residue with wire brush and wash with soapy water. Then rinse with water. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 20 Inspect burner for any damage (cracks or holes). If damage is found, replace with new burner. Reinstall burner; check to insure that gas valve orifices are cor- rectly positioned inside burner inlet (venturi). Also check position of spark elec- trode. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 21: Checking For Leaks

    If bubbles appear, you have a leak. Check the regulator connection as follows: Disconnect regulator from the tank and recon- nect, making sure the connection is secure. Retest with solution. If you contin- ue to see bubbles, replace the cylinder. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 22: Lighting Grill

    5 minutes before re-lighting. Clean your grill after each use, DO NOT use abrasive or flammable cleaners, as it will damage the parts of this product and may start a fire. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 23: Side Burner

    Flame should be a Blue / Yellow color. To visually check that the burner is operating, look at the burner flame through the flame viewing hole. The flame should be approximately 1/2-3/4 inch long with the high setting. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 24: Cooking Grate

    2. Press in knob and rotate counter-clockwise to the High setting and burner should light immediately. 3. Adjust burners to desired cooking settings Cooking Grate Match Holder Chain Burner Ports OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 25: Trouble Shooting

    30 seconds and then light the grill. Irregular flame pattern, Burner ports are clogged Clean Burner ports flame does not run the or blocked. full length of burner. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 26 Baked on grease buildup has Clean inside of lid thorough- be peeling turned to carbon and is flak- ly. The lid is not painted on - like paint peeling ing off. the inside OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 27: Grill Preparation

    PROPERLY CARED FOR. 3. You may fill unwanted holes with Nuts & Bolts (Not Provided). NOTE: Smoke will escape from areas other than the smokestacks. This will not affect your cooking . OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 28: Recipes

    (hot) position for 1 min each side before lowering grate and closing lid. *OR SMOKE by placing birds in center of GRID with fire in both ends of FIRE BOX. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 29 50 minutes. Turn after 25 minutes (no need to turn if smoked). Squeeze to check for doneness. SWEET CORN IN HUSKS: Trim excess silk from end and soak in cold salted water 1 hour before grilling. Grill 25 minutes – turning several times. OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 30: Accessories

    Fits standard 20lb LP tank Velcro Close Elastic at Top and Bottom Cover Only Tank Not Included…...$9.99 Visit our online store at: www.chargriller.com for more Char-Griller ® (continued on next page) Professional Accessories ™ OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 31 Price Qty. Prodcut Price Tank Cover $9.99 Rotisserie $35.99 Adjustable Fit Apron $14.99 Side Fire Box #2-2424 $59.99 Cover For Grill $24.99 Raw Cast Iron Grate $8.99 Shipping Charge ORDER NOW! Total OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 32 Page intentionally left blank for notes OM3001D.3 ™ & © Char-Griller / A&J Mfg.
  • Page 33 Char-Griller will repair or re- place any defective part of its side fire boxes for a period up to one year from the date of purchase.
