Standard fuse amperage rating and color
Fuse Mini
rating fuses
2A Grey
3A Violet
4A Pink
5A Tan
7.5A Brown
10A Red
15A Blue
20A Yellow
25A Natural
30A Green
40A —
50A —
60A —
70A —
80A —

Passenger compartment fuse panel

The fuse panel is located below and to the left of the steering wheel by
the brake pedal. Remove the panel cover to access the fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
178
2006 Zephyr (378)
Owners Guide (post-2002-fmt)
USA (fus)
COLOR
Standard Maxi
fuses fuses
Grey —
Violet —
Pink —
Tan —
Brown —
Red —
Blue —
Yellow Yellow
Natural —
Green Green
— Orange
— Red
— Blue
— Tan
— Natural
Cartridge
Fuse link
maxi
cartridge
fuses
— —
— —
— —
— —
— —
— —
— —
Blue Blue
— —
Pink Pink
Green Green
Red Red
— Yellow
— Brown
— Black
