Page 1 Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo with CD AM/FM stereo with in-dash six CD Climate Controls Manual heating and air conditioning Rear window defroster Lights Headlamps Turn signal control Bulb replacement Driver Controls Windshield wiper/washer control Steering wheel adjustment Power windows Mirrors...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Airbags Child restraints Tires, Wheels and Loading Tire Information Vehicle loading Trailer towing Recreational towing Driving Starting Brakes Traction control Transmission operation Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires...
Page 4: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle, the greater the safety and pleasure you will derive from driving it.
Page 5 SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury to yourself or others? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol. These comments should be read and observed.
Page 6 In order to properly diagnose and service your vehicle, Ford Motor Company, Ford of Canada, and service and repair facilities may access vehicle diagnostic information through a direct connection to your vehicle when diagnosing or servicing your vehicle.
Page 7 To access this information, special equipment must be directly connected to the recording modules. Ford Motor Company and Ford of Canada do not access event data recorder information without obtaining consent, unless pursuant to court order or where required by law enforcement, other government authorities or other third parties acting with lawful authority.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert Fasten Safety Belt Airbag - Side Child Seat Installation Warning Child Seat Tether Anchor Anti-Lock Brake System Powertrain Malfunction Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield...
Page 9 Vehicle Symbol Glossary Power Windows Front/Rear Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check Fuel Cap 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus) Introduction...
Page 10: Instrument Cluster
Instrument Cluster WARNING LIGHTS AND CHIMES Base instrument cluster Optional instrument cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause extensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulbs work.
Page 11 Service Engine Soon: The Service Engine Soon indicator light illuminates when the ignition is first turned to the ON position to check the bulb. Solid illumination after the engine is started indicates the On Board Diagnostics System (OBD-II) has detected a malfunction. Refer to On board diagnostics (OBD-II) in the Maintenance and Specifications chapter.
Page 12 Instrument Cluster Anti-lock brake system (if equipped): If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system serviced immediately by your authorized dealer. Normal braking is still functional unless the brake warning light also is illuminated. Airbag readiness: If this light fails to illuminate when ignition is turned to ON, continues to flash or remains...
Page 13 Instrument Cluster Traction Control active: Flashes when the Traction Control active. If the light remains on a malfunction has been detected; have the system serviced immediately, refer to the Driving chapter for more information. Overdrive off (automatic transmission): Illuminates when the overdrive function of the transmission has been turned off, refer to the Driving chapter.
Page 14 Instrument Cluster Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on. Daytime running lamps (DRL) (if equipped): Illuminates when the Daytime running lamps are on.
Page 15: Gauges
Instrument Cluster GAUGES Base instrument cluster gauges Optional instrument cluster gauges Refer to Message Center (if equipped) in the Driver Controls chapter to select one of six preset colors or one user definable color (MyColor) for the nighttime gauge backlighting. 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 16 Instrument Cluster Speedometer: Indicates the current vehicle speed. • Base instrument cluster • Optional instrument cluster Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating.
Page 17 Instrument Cluster Trip odometer: Registers the miles (kilometers) of individual journeys. • Base instrument cluster Press and release the RESET button on the cluster to toggle between odometer and trip odometer display. To reset, press and hold for less than 2 seconds. •...
Page 18 Instrument Cluster Battery voltage gauge (if equipped): Indicates the battery voltage when the ignition is in the ON position. If the pointer moves and stays outside the normal operating range, have the vehicle’s electrical system checked by your authorized dealer as soon as possible.
Page 19: Entertainment Systems
Entertainment Systems AUDIO SYSTEMS AM/FM stereo/ single CD sound system (if equipped) Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches and radio may be used for up to ten minutes after the ignition switch is turned to the OFF position or until any door or trunk is opened.
Page 20 Entertainment Systems Balance: Press to adjust the audio between the left and right speakers. SEEK Fade: Press to adjust the audio between the front and rear speakers. SEEK Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3.
Page 21 Entertainment Systems 8. Comp (Compression): In CD mode, brings soft and loud CD passages together for a more consistent listening level. 9. Repeat: Press to repeat the current CD track. 10. Fast forward: Press to manually advance in a CD track. 11.
Page 22 Entertainment Systems 18. CD eject: Press to eject a CD. 19. CD slot: Insert a CD label side SHAKER 500 — Audiophile In-Dash Six CD/MP3 Sound System (if equipped) 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 23 Entertainment Systems SHAKER 1000 — Audiophile In-dash Six CD/MP3 Sound System (if equipped) Accessory delay: Your vehicle is equipped with accessory delay. With this feature, the window switches and radio may be used for up to ten minutes after the ignition switch is turned to the OFF position or until any door or trunk is opened.
Page 24 Entertainment Systems 3. Menu: Press to toggle through the following modes: Setting the clock: Press until SELECT HOUR or SELECT MINS is displayed. Press SEEK SHAKER (Available with the SHAKER 1000 only): Select to engage SHAKER 1000 mode. SHAKER 1000 mode enhances acoustic sound for all seating locations and increases the signal to the trunk mounted speakers and amplifiers for enhanced bass performance.
Page 25 Entertainment Systems Occupancy mode: Use SEEK select and optimize sound for ALL SEATS, DRIVERS SEAT or REAR SEATS. Speed sensitive volume: Radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise. Recommended level is 1–3. Level 0 turns the feature off and level 7 is the maximum setting.
Page 26 Entertainment Systems 8. FOLDER: Press to access next folder on MP3 discs, if folders are available. 9. FOLDER: press to access the previous folder on MP3 discs, if folders are available. 10. Fast forward: Press to manually advance in a CD track. 11.
Page 27 18. LOAD: Press to begin the CD load sequence. When the radio prompts to select a slot, use the presets to select the desired slot to load the CD. If the selected slot already contains a CD, the display will read SLOT FULL. Press and hold to autoload up to 6 CDs.
Page 28 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 29: Climate Controls
Climate Controls MANUAL HEATING AND AIR CONDITIONING SYSTEM 1. Temperature selection: Controls the temperature of the airflow in the vehicle. 2. Mode selections: Controls the location of the airflow in the vehicle. See the following for a brief description of each selection. MAX A/C: Distributes recirculated air through the instrument panel vents to cool the vehicle.
Page 30 Climate Controls 6. Fan speed adjustment: Controls the volume of air circulated in the vehicle. Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the • To reduce humidity build up inside the vehicle, do not drive with the airflow selector in the O (OFF) position or with recirculated air engaged.
Page 31: Rear Window Defroster
Climate Controls REAR WINDOW DEFROSTER (R Ensure that the ignition is in the 3 (ON) position. Press the control to clear the rear window of thin ice and fog. The LED will illuminate. The rear window defroster turns off automatically after 10 minutes, or when the ignition is turned to the 1 (OFF/LOCK) position.
Page 32: Lights
Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Foglamp control (if equipped) The foglamps can be turned on when the ignition is in the ON position, the headlamp control is in position and the high beams are not on.
Page 33 Flash to pass Pull toward you, to the first detent, to activate and release to deactivate. Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. When activated, the DRL telltale is illuminated. To activate: • the ignition must be in the ON position, •...
Page 34 Lights If your vehicle has been in an accident the alignment of your headlamps should be checked by your authorized dealer. Headlamp vertical aim adjustment 1. Park the vehicle directly in front of a wall or screen on a level surface, approximately 25 feet (7.6 meters) away.
Page 35: Turn Signal Control
TURN SIGNAL CONTROL • Push down to activate the left turn signal. • Push up to activate the right turn signal. The flash rate of the turn signal will speed up considerably if the Lighting Control Module detects a left or right turn lamp bulb (front or rear) is burned out.
Page 36 Lights “E” for Europe to ensure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time. Function Headlamp Park lamp, turn lamp, side marker (front) Sidemarker (front) Fog lamp Tail lamp, brakelamp, turn lamp...
Page 37 Handle a halogen headlamp bulb carefully and keep out of children’s reach. Grasp the bulb only by its plastic base and do not touch the glass. The oil from your hand could cause the bulb to break the next time the headlamps are operated.
Page 38 Lights 2. Remove the sight shield by loosening the six fasteners with a flat head screwdriver. 3. Remove the two underhood bolts attaching the bumper cover next to the grill and then pull the cover/grille/foglamp assembly forward to access the foglamp bulbs. 4.
Page 39 Lights Replacing backup bulbs The backup lamp is located in the tail lamp assembly. Follow the same steps to replace either bulb. 1. Make sure headlamp switch is in OFF position, then open the trunk. 2. Carefully remove fasteners around the lamp area, then remove the interior trunk trim.
Page 40 Lights Replacing high-mount brake lamp bulbs 1. Make sure the headlamp switch is in the OFF position and then open the trunk. 2. Inside trunk, pull the trim panel straight off of the underside of the trunk lid. 3. Locate the lighting assembly and push the release tab to access the bulb socket.
Page 41: Driver Controls
MULTI-FUNCTION LEVER Windshield wiper: For intermittent operation, move control up one position. Adjust the rotary control to the desired speed setting. For normal or low speed wiper operation, move control up two positions from OFF. For high speed wiper operation, move control up three positions from OFF.
Page 42 Driver Controls TILT STEERING WHEEL (IF EQUIPPED) To adjust the steering wheel: 1. Push the lever down to unlock the steering column. While the lever is in the down position, tilt the steering column to its desired orientation. 2. While holding the steering column, pull the lever up to its original position to lock the steering column.
Page 43: Power Windows
Cigarette/Cigar lighter (if equipped) Do not plug optional electrical accessories into the cigarette lighter socket. Do not hold the lighter in with your hand while it is heating, this will damage the lighter element and socket. The lighter will be released from its heating position when it is ready to be used.
Page 44 Driver Controls Express down (One Touch Down, Front windows only) Allows the driver and passenger’s window to open fully without holding the control down. Push the switch completely down to the second detent and release quickly. The window will open fully. Momentarily press the switch to any position to stop the window operation.
Page 45 Driver Controls Bounce Back Override (Front windows only) To override Bounce Back, within 2 seconds after reaching Bounce Back position, if the switch is moved from the Neutral to the Express Up position the window will travel up with no bounce back protection. If the switch is released before the window reaches fully closed position, the window will stop.
Page 46: Mirrors
Driver Controls EXTERIOR MIRRORS Power side view mirrors To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror. 2. Move the control in the direction you wish to tilt the mirror. 3.
Page 47 • If the vehicle speed decreases more than 10 mph (16 km/h) below your set speed on an uphill, your speed control will disengage. • If the vehicle speed decreases to 30 mph (48 km/h) or less, your speed control will disengage Disengaging speed control To disengage the speed control: •...
Page 48 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET + control. Turning off speed control There are two ways to turn off the speed control: • Press the speed control OFF control. •...
Page 49 Driver Controls The latch handles must be pulled downwards fully to allow the latch to fully rotate into the open position 3. Unclamp the top from the windshield header by pulling each latch handle down and then rotating the latch to the rear until it clears the header.
Page 50 Driver Controls Installation of the boot (if equipped) Be sure the boot is secure on the vehicle before driving. 1. Install the boot on the vehicle by hooking the boot retaining clips on the back panel. 2. Install the boot on the right side tucking in the front part of the boot in the quarter panel and hooking the retaining clip on the side.
Page 51 Driver Controls Storing the boot 1. Position the boot right-side up and fold each side of the boot inward. 2. Turn the boot upside down and fold the left side of the boot inward. 3. Fold the right side inward and secure the boot with the strap. Stow the boot in the trunk.
Page 52 Driver Controls To raise the convertible top: 1. Bring the vehicle to a complete stop. Key must be in the ON position. It is recommended that the vehicle’s engine is running when raising the top to prevent draining the battery. 2.
Page 53: Message Center
Driver Controls MESSAGE CENTER (IF EQUIPPED) With the ignition in the ON position, the message center, located on your instrument cluster, displays important vehicle information through a constant monitor of vehicle systems. You may select display features on the message center for a display of status. The system will also notify you of potential vehicle problems with a display of system warnings followed by a long indicator chime.
Page 54 Driver Controls of the monitored systems, the message center will indicate either an OK message or a warning message for two seconds. Pressing the RESET control cycles the message center through each of the systems being monitored. The sequence of the system check report and how it appears in the message center is as follows: 1.
Page 55 Driver Controls Red, Green, and Blue LEDs. Apart from the 6 preset colors, drivers can create their own color by adjusting the levels of the three primary colors through the MyColor feature to achieve any of 125 different combinations. The vehicle must be stationary to enter the MyColor adjust mode.
Page 56 Driver Controls 3. Press and hold the RESET control to set the language choice. Info menu This control displays the following control displays: • Odometer • Trip odometer • Distance to Empty • Average Fuel Economy • Instantaneous Fuel Economy •...
Page 57 Driver Controls The DTE function will display LOW FUEL LEVEL and sound a tone for one second when you have approximately 50 miles (80 km) to empty. If you RESET this warning message, this display and tone will return within 10 minutes. DTE is calculated using a running average fuel economy, which is based on your recent driving history of 500 miles (800 km).
Page 58 Driver Controls Fuel Used Select this function from the INFO menu to display the fuel used since last reset. The information displayed will be in gallons or liters, depending on English/metric mode state. Trip elapsed drive time Select this function from the INFO menu to display a timer.
Page 59 Warning messages that have been reset are divided into three categories: • They will not disappear until a condition is changed. • They will reappear on the display ten minutes from the reset. • They will not reappear until an ignition OFF-ON cycle has been completed.
Page 60 Driver Controls LOW BRAKE FLUID LEVEL. Indicates the brake fluid level is low and the brake system should be inspected immediately. Refer to Brake fluid reservoir in the Maintenance and Specifications chapter. LOW OIL PRESSURE. Displayed when the engine oil pressure is low. If this warning message is displayed, check the level of the engine oil.
Page 61: Locks And Security
Locks and Security KEYS One key operates all the locks and starts the vehicle. Always carry a spare key with you in case of an emergency. Your keys are programmed to your vehicle; using a non-programmed key will not permit your vehicle to start. If you lose your authorized dealer supplied keys, replacement keys are available through your authorized dealer.
Page 62 Locks and Security Autolock (if equipped) On vehicles equipped with an automatic transmission, this feature automatically locks all vehicle doors when: • all doors are closed, • the ignition is in the 3 (ON) position, • the brake is pressed before reaching 5 mph (8 km/h), and •...
Page 63 • The driver’s door is unlocked when the key is inserted in the driver door key cylinder and turned to the unlock position. The driver’s door is locked when the key is inserted in the driver door key cylinder and turned to the lock position.
Page 64 Locks and Security To open the luggage compartment door (lid) from within the luggage compartment, pull the illuminated “T” shaped handle and push up on the trunk lid. The handle is composed of a material that will glow for hours in darkness following brief exposure to ambient light.
Page 65 REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RSS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 66 Locks and Security Locking the doors 1. Press and release to lock all the doors. Note: The interior lamps will turn off (unless the dome lamp control is in the full-up position), and the turn signal lamps will flash if all doors, trunk and hood (if equipped with active anti-theft system) are closed and locked.
Page 67 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE RUBBER COVER AND CIRCUIT BOARD OFF THE FRONT HOUSING OF THE REMOTE ENTRY TRANSMITTER.
Page 68 Locks and Security To reprogram the remote entry transmitters: 1. Ensure the vehicle is electronically unlocked. 2. Put the key in the ignition. 3. Cycle eight times rapidly (within 10 seconds) between the 1 (OFF/LOCK) position and 3 (ON). Note: The eighth turn must end in the 3 (ON) position.
Page 69: Anti-Theft System
Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 70 Locks and Security Automatic arming The vehicle is armed immediately after switching the ignition to the 1 (OFF/LOCK) position. The theft indicator will flash every two seconds when the vehicle is armed. Automatic disarming Switching the ignition to the 3 (ON) position with a coded key disarms the vehicle.
Page 71 Tips: • A maximum of eight keys can be coded to your vehicle. • Only use Securilock keys. • You must have two previously programmed coded keys (keys that already operate your vehicle’s engine) and the new unprogrammed key(s) readily accessible. •...
Page 72 Locks and Security To program additional new unprogrammed key(s), repeat this procedure from Step 1 for each additional key. ACTIVE ANTI-THEFT SYSTEM (IF EQUIPPED) The active anti-theft system is designed to warn you in the event of an unauthorized entry to your vehicle and is also designed to help prevent the unwanted towing of the vehicle.
Page 73 Arming the system When armed, the active anti-theft system is designed to notify you of an unauthorized entry. When unauthorized entry or towing occurs, the system will flash the turn signal lamps and interior lamps and sounds the security horn. The system is ready to arm whenever the key is out of the ignition.
Page 74: Seating And Safety Restraints
Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 75 Seating and Safety Restraints Lift the head restraint to raise the height. To lower the head restraint, press the button located on the driver’s side post. Adjusting the front manual seat (if equipped) Never adjust the driver’s seat or seatback when the vehicle is moving.
Page 76 Seating and Safety Restraints Pull lever up to adjust the angle of the seatback. Four-way seat adjust (driver side only) Pump the handle upwards to raise the cushion and pump downward to lower the cushion to the desired location. Using the power lumbar support (if equipped) The power lumbar control is located on the top of the seat side shield.
Page 77 Seating and Safety Restraints Do not pile cargo higher than the seatbacks to avoid injuring people in a collision or sudden stop. Always drive and ride with your seatback upright and the lap belt snug and low across the hips. Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision.
Page 78 Seating and Safety Restraints Move the switch in the direction of the arrows to raise or lower the front portion of the seat cushion. Move the switch in the direction of the arrows to raise or lower the rear portion of the seat cushion. Press the switch in the direction of the arrows to move the seat forward, backward, up or down.
Page 79 Seating and Safety Restraints Use the recliner handle to return the seatback to the desired position. REAR SEATS 2nd seat/split-folding rear seat One or both rear seatbacks (coupe only) can be folded down to provide additional cargo space. To lower the seatback(s) from inside the vehicle, pull strap to release seat back and then fold seatback down.
Page 80: Safety Restraints
Seating and Safety Restraints SAFETY RESTRAINTS Personal Safety System The Personal Safety System provides an improved overall level of frontal crash protection to front seat occupants and is designed to help further reduce the risk of airbag-related injuries. The system is able to analyze different occupant conditions and crash severity before activating the appropriate safety devices to help better protect a range of occupants in a variety of frontal crash situations.
Page 81 Seating and Safety Restraints Driver and passenger dual-stage airbag supplemental restraints The dual-stage airbags offer the capability to tailor the level of airbag inflation energy. A lower, less forceful energy level is provided for more common, moderate-severity impacts. A higher energy level is used for the most severe impacts.
Page 82 Seating and Safety Restraints The front passenger sensing system can automatically turn off the passenger front airbag. The system is designed to help protect small (child size) occupants from airbag deployments when they are improperly seated or restrained in the front passenger seat contrary to proper child-seating or restraint usage recommendations.
Page 83 Seating and Safety Restraints The Restraints Control Module (RCM) monitors its own internal circuits and the circuits for the airbag supplemental restraints, crash sensor(s), safety belt pretensioners, front safety belt buckle sensors, and the driver seat position sensor. In addition, the RCM also monitors the restraints warning light in the instrument cluster.
Page 84 Seating and Safety Restraints In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a safety belt. Each seating position in your vehicle has a specific safety belt assembly which is made up of one buckle and one tongue that are designed to be used as a pair.
Page 85 Seating and Safety Restraints The belt guide is secured to the side shield by fastening the snap on the guide strap to the snap on the side shield. 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
Page 86 Seating and Safety Restraints Energy Management Feature • This vehicle has a safety belt system with an energy management feature at the front seating positions to help further reduce the risk of injury in the event of a head-on collision. •...
Page 87 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by an authorized dealer after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 88 Seating and Safety Restraints After any vehicle collision, the front passenger and rear outboard safety belt systems must be checked by an authorized dealer to verify that the “automatic locking retractor” feature for child seats is still functioning properly. In addition, all safety belts should be checked for proper function.
Page 89 (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies in use in vehicles involved in a collision be replaced.
Page 90 Seating and Safety Restraints Conditions of operation If... The driver’s or front passenger’s safety belt is not buckled before the ignition switch is turned to the ON position... The driver’s or front passenger’s safety belt is buckled while the indicator light is illuminated and the warning chime is sounding...
Page 91 Seating and Safety Restraints If... The driver’s and front passenger’s safety belts are buckled before the ignition switch is turned to the ON position or less than 1-2 minutes have elapsed since the ignition switch has been turned ON... The driver’s or front passenger’s safety belt is not buckled when the vehicle has reached at least 3 mph (5 km/h)
Page 92 Seating and Safety Restraints Reasons given... “Belts are uncomfortable” “I was in a hurry” “Safety belts don’t work” “Traffic is light” “Belts wrinkle my clothes” “The people I’m with don’t wear belts” “I have an airbag” “I’d rather be thrown clear” 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 93 Seating and Safety Restraints Do not sit on top of a buckled safety belt to avoid the BeltMinder chime. Sitting on the safety belt will increase the risk of injury in an accident. To disable (one-time) or deactivate the BeltMinder feature please follow the directions stated below. One time disable If at any time the driver/front passenger quickly buckles then unbuckles the safety belt for that seating position, the BeltMinder is disabled for...
Page 94: Airbags
Seating and Safety Restraints • Step 3 must be completed within 50 seconds after the safety belt warning light turns off. 3. For the seating position being disabled, at a moderate speed, buckle then unbuckle the safety belt 9 times, ending in the unbuckled state. (Step 3 must be completed within 50 seconds after the safety belt warning light turns off.) •...
Page 95 Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Airbags DO NOT inflate slowly; there is a risk of injury from a deploying airbag.
Page 96 Seating and Safety Restraints Do not attempt to service, repair, or modify the airbag supplemental restraint systems or its fuses. See your authorized dealer. Modifying or adding equipment to the front end of the vehicle (including frame, bumper, front end body structure and tow hooks) may affect the performance of the airbag system, increasing the risk of injury.
Page 97 Seating and Safety Restraints How does the airbag supplemental restraint system work? The airbag SRS is designed to activate when the vehicle sustains a longitudinal deceleration sufficient to cause the airbag sensors to close an electrical circuit that initiates airbag inflation. The fact that the airbags did not inflate in a collision does not mean that something is wrong with the system.
Page 98 Seating and Safety Restraints • a readiness light and tone • a diagnostic module • and the electrical wiring which connects the components The diagnostic module monitors its own internal circuits and the supplemental airbag electrical system wiring (including the impact sensors), the system wiring, the airbag system readiness light, the airbag back up power and the airbag ignitors.
Page 99 Seating and Safety Restraints • a child or a small person occupies the front passenger seat. For side airbag equipped vehicles, the front passenger sensing system will turn off the passenger seat side airbag if: • the seat is empty and safety belt is unbuckled. The front passenger sensing system uses a passenger airbag off or pass airbag off indicator which will...
Page 100 Seating and Safety Restraints • Restart the vehicle and have the person remain in this position for about two minutes. This will allow the system to detect that person and enable the passenger’s frontal airbag. • If the indicator lamp remains lit even after this, the person should be advised to ride in the rear seat.
Page 101 Seating and Safety Restraints Pass Airbag Off Objects Indicator Lamp Small (i.e. 3 ring Unlit binder, small purse, bottled water) Medium (i.e. heavy briefcase, fully packed luggage) Empty seat, Small or medium object with safety belt buckled If you think that the status of the passenger airbag off indicator lamp is incorrect, check for the following: •...
Page 102 If it is necessary to modify an advanced front airbag system to accommodate a person with disabilities, contact the Ford Customer Relationship Center at the phone number shown in the Customer Assistance section of this Owner’s Guide.
Page 103 Seating and Safety Restraints Do not use accessory seat covers. The use of accessory seat covers may prevent the deployment of the side airbags and increase the risk of injury in an accident. Do not lean your head on the door. The side airbag could injure you as it deploys from the side of the seatback.
Page 104 Seating and Safety Restraints The side airbags are fitted on the outboard side of the seatbacks of the front seats. In certain lateral collisions, the airbag on the side affected by the collision will be inflated. The front passenger sensing system will turn off the passenger seat side airbag if the seat is empty.
Page 105: Child Restraints
Seating and Safety Restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and/or light are repaired. If any of these things happen, even intermittently, have the SRS serviced at an authorized dealer immediately. Unless serviced, the system may not function properly in the event of a collision.
Page 106 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 107 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 108 Seating and Safety Restraints Children and booster seats vary widely in size and shape. Choose a booster that keeps the lap belt low and snug across the hips, never up across the stomach, and lets you adjust the shoulder belt to cross the chest and rest snugly near the center of the shoulder.
Page 109 80 lb. (36 kg) using an upper torso harness and a belt-positioning booster. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with LATCH and...
Page 110 Seating and Safety Restraints tether anchors. For more information on top tether straps and anchors, refer to Attaching safety seats with tether straps in this chapter. For more information of LATCH anchors refer to Attaching safety seats with LATCH (Lower Anchors and Tethers for Children) attachments in this chapter.
Page 111 Seating and Safety Restraints 2. Pull down on the shoulder belt and then grasp the shoulder belt and lap belt together. 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions.
Page 112 Seating and Safety Restraints 5. To put the retractor in the automatic locking mode, grasp the shoulder portion of the belt and pull downward until all of the belt is extracted and a click is heard. 6. Allow the belt to retract. The belt will click as it retracts to indicate it is in the automatic locking mode.
Page 113 Seating and Safety Restraints Attaching child safety seats with tether straps Most new forward-facing child safety seats include a tether strap which goes over the back of the seat and hooks to an anchoring point. Tether straps are available as an accessory for many older safety seats. Contact the manufacturer of your child seat for information about ordering a tether strap.
Page 114 Seating and Safety Restraints For Coupe only: 4. Open the tether anchor covers. 5. Clip the tether strap to the anchor as shown. For Convertible only: The tether anchors on the convertible are located rearward of the seatback in the convertible top sling.
Page 115 Seating and Safety Restraints Note: The attachments for the convertible boot located on the back of the head restraints are not tether anchors. 4. Access tether anchors located behind the seatback under the vinyl tag marked with the child tether anchor symbol.
Page 116 Seating and Safety Restraints 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6. Install the child safety seat tightly using the LATCH anchors or safety belts.
Page 117 Seating and Safety Restraints Your vehicle has LATCH anchors for child seat installation at the seating positions marked with the child seat symbol. The center of the rear seat is NOT designed as a seating position. The LATCH anchors were not designed to be used with a child seat in the center position and there is no tether anchor available at the...
Page 118 Seating and Safety Restraints lifting the front of the child seat. Keeping the child seat just touching the vehicle seat gives the best protection in a severe crash. Each time you use the safety seat, check that the seat is properly attached to the lower anchors and tether anchor.
Page 119: Tires, Wheels And Loading
10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford Motor Company to give you the following information about tire grades exactly as the government has written it.
Page 120 Tires, Wheels and Loading The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 121 (including spare, if equipped). Inflate all tires to the inflation pressure recommended by Ford Motor Company. Use a tire gauge to check the tire inflation pressure, including the spare (if equipped), at least monthly and before long trips. You are strongly...
Page 122 Always inflate your tires to the Ford recommended inflation pressure even if it is less than the maximum inflation pressure information found on the tire. The Ford recommended tire inflation pressure is found on the Safety Compliance Certification Label or Tire Label which is located on the B-Pillar or the edge of the driver’s door.
Page 123: Tire Information
Tires, Wheels and Loading To check the pressure in your tire(s): 1. Make sure the tires are cool, meaning they are not hot from driving even a mile. Note: If you have to drive a distance to get air for your tire(s), check and record the tire pressure first and add the appropriate air pressure when you get to the pump.
Page 124 Tires, Wheels and Loading Improper or inadequate vehicle maintenance can cause tires to wear abnormally. Inspect all your tires, including the spare, frequently, and replace them if one or more of the following conditions exist: Tire wear When the tread is worn down to 1/16th of an inch (2 mm), tires must be replaced to help prevent your vehicle from skidding and...
Page 125 Only use replacement tires and wheels that are the same size and type (such as P-metric versus LT-metric or all-season versus all-terrain) as those originally provided by Ford. Use of any tire or wheel not recommended by Ford can affect the safety and performance of your vehicle, which could result in an increased risk of loss of vehicle control, vehicle rollover, personal injury and death.
Page 126 Tires, Wheels and Loading Never spin the tires in excess of the 35 mph (55 km/h) point indicated on the speedometer. Highway hazards No matter how carefully you drive there’s always the possibility that you may eventually have a flat tire on the highway. Drive slowly to the closest safe area out of traffic.
Page 127 • Rear Wheel Drive (RWD) vehicles/Four Wheel Drive (4WD)/ All Wheel Drive (AWD) vehicles (front tires at top of diagram) Sometimes irregular tire wear can be corrected by rotating the tires. Note: If your tires show uneven wear ask an authorized dealer to check for and correct any wheel misalignment, tire imbalance or mechanical problem involved before tire rotation.
Page 128 Tires, Wheels and Loading Information on “P” type tires P215/65R15 95H is an example of a tire size, load index and speed rating. The definitions of these items are listed below. (Note that the tire size, load index and speed rating for your vehicle may be different from this example.) 1.
Page 129 Note: You may not find this information on all tires because it is not required by federal law. Letter rating Note: For tires with a maximum speed capability over 149 mph (240 km/h), tire manufacturers sometimes use the letters ZR. For those with a maximum speed capability over 186 mph (299 km/h), tire manufacturers always use the letters ZR.
Page 130 Tires, Wheels and Loading 12. Treadwear, Traction and Temperature Grades • Treadwear: The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 course as a tire graded 100.
Page 131 Tires, Wheels and Loading Additional information contained on the tire sidewall for “LT” type tires “LT” type tires have some additional information beyond those of “P” type tires; these differences are described below: 1. LT: Indicates a tire, designated by the Tire and Rim Association (T&RA), that is intended for service on light trucks.
Page 132 Tires, Wheels and Loading Information on “T” type tires “T” type tires have some additional information beyond those of “P” type tires; these differences are described below: T145/80D16 is an example of a tire size. Note: The temporary tire size for your vehicle may be different from this example.
Page 133: Vehicle Loading
Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 134 Tires, Wheels and Loading Payload – is the combined weight of cargo and passengers that the vehicle is carrying. The maximum payload for your vehicle can be found on the Tire Label on the B-Pillar or the edge of the driver’s door (vehicles exported outside the US and Canada may not have a Tire Label).
Page 135 Tires, Wheels and Loading Example only: Cargo Weight – includes all weight added to the Base Curb Weight, including cargo and optional equipment. When towing, trailer tongue load or king pin weight is also part of cargo weight. GAW (Gross Axle Weight) – is the total weight placed on each axle (front and rear) –...
Page 136 Tires, Wheels and Loading GAWR (Gross Axle Weight Rating) – is the maximum allowable weight that can be carried by a single axle (front or rear). These numbers are shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The total load on each axle must never exceed its GAWR.
Page 137 GVWR (Gross Vehicle Weight Rating) – is the maximum allowable weight of the fully loaded vehicle (including all options, equipment, passengers and cargo). The GVWR is shown on the Safety Compliance Certification Label located on the B-Pillar or the edge of the driver’s door. The GVW must never exceed the GVWR.
Page 138 Tires, Wheels and Loading 10–15% (conventional trailer) or king pin weight of 15–25% (fifth wheel trailer), and driver only (150 lb. [68 kg]). Consult your authorized dealer (or the RV and Trailer Towing Guide provided by your authorized dealer) for more detailed information. Do not exceed the GVWR or the GAWR specified on the Safety Compliance Certification Label.
Page 139: Trailer Towing
capacity to carry you, 4 of your friends and all the golf bags? You and four friends average 220 lb. (99 kg) each and the golf bags weigh approximately 30 lb. (13.5 kg) each. The calculation would be: 1400 – (5 x 220) –...
Page 140 Tires, Wheels and Loading Towing trailers beyond the maximum recommended gross trailer weight exceeds the limit of the vehicle and could result in engine damage, transmission damage, structural damage, loss of vehicle control, vehicle rollover and personal injury. Preparing to tow Use the proper equipment for towing a trailer and make sure it is properly attached to your vehicle.
Page 141 Do not splice into the vehicle lamp wiring for trailer lamps. Your vehicle uses an advanced electronic module to control and monitor your vehicle lamps. Splicing into the wiring or attaching wiring to the vehicle bulb. may DISABLE the rear vehicle lamps or cause them not to function properly.
Page 142: Recreational Towing
• Maximum distance is 50 miles (80 km) If a distance of 50 miles (80 km) or a speed of 35 mph (56 km/h) must be exceeded, you must disconnect the driveshaft. Ford Motor Company recommends the driveshaft be removed/installed only by a qualified technician at an authorized dealer.
Page 143: Driving
STARTING Positions of the ignition 1. OFF/LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. Note: The ignition key cannot be removed from the ignition unless the gearshift lever is securely latched in P (Park). 2. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running.
Page 144 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 145 • Make sure the gearshift is in P (Park). • Make sure the parking brake is set. If starting a vehicle with a manual transmission: • Make sure the parking brake is set. • Push the clutch pedal to the floor 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 146 Driving 3. Turn the key to 3 (ON) without turning the key to 4 (START). Some warning lights will briefly illuminate. See Warning lights and chimes in the Instrument Cluster chapter for more information regarding the warning lights. Starting the engine 1.
Page 147: Brakes
Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least one inch (2.5 cm) or adjust the heating or air conditioning to bring in fresh air. USING THE ENGINE BLOCK HEATER (IF EQUIPPED) An engine block heater warms the engine coolant which aids in starting and heater/defroster performance.
Page 148 Driving ABS warning lamp The ABS lamp in the instrument cluster momentarily illuminates when the ignition is turned on. If the light does not illuminate during start up, remains on or flashes, the ABS may be disabled and may need to be serviced. Even when the ABS is disabled, normal braking is still effective.
Page 149: Traction Control
Always set the parking brake fully and make sure that the gearshift is securely latched in P (Park) (automatic transmission) or in 1 (First) (manual transmission). If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly. See your authorized dealer as soon as possible.
Page 150 Driving The Traction Control switch, located above the radio, illuminates when the system is off. The Traction Control system will automatically turn on every time the ignition is turned OFF and ON. If you should become stuck in snow or ice or on a very slippery road surface, try switching the Traction Control system off.
Page 151: Transmission Operation
• loose or worn steering components • improper steering alignment A high crown in the road or high crosswinds may also make the steering seem to wander/pull. TRACTION-LOK AXLE (IF EQUIPPED) This axle provides added traction on slippery surfaces, particularly when one wheel is on a poor traction surface.
Page 152 Driving Do not drive your vehicle until you verify that the brakelamps are working. Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle. If the parking brake is fully released, but the brake warning lamp remains illuminated, the brakes may not be working properly.
Page 153 Driving Understanding the gearshift positions of the 5–speed automatic transmission This vehicle is equipped with an Adaptive Transmission Control Strategy. This Adaptive Transmission Control Strategy offers the optimal transmission operation and shift quality. When the vehicle’s battery has been disconnected for any type of service or repair, the transmission will need to relearn the normal shift strategy parameters, much like having to reset your radio stations when your vehicle battery has been disconnected.
Page 154 Driving To put your vehicle in P (Park): • Come to a complete stop • Move the gearshift lever and securely latch it in P (Park) Always set the parking brake fully and make sure the gearshift is latched in P (Park). Turn the ignition to the LOCK position and remove the key whenever you leave your vehicle.
Page 155 • To return to Overdrive mode, press the transmission control switch. The O/D OFF lamp will not be illuminated. • Overdrive mode is automatically returned each time the key is turned off. 3 (Third) This position allows for third gear only. •...
Page 156 Driving Do not rock the vehicle for more than a minute or damage to the transmission and tires may occur, or the engine may overheat. MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch The manual transmission has a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed.
Page 157 Upshift according to the following chart: Upshifts when accelerating (recommended for best fuel economy) 1 - 2 2 - 3 3 - 4 4 - 5 Reverse 1. Make sure that your vehicle is at a complete stop before you shift into R (Reverse).
Page 158 Driving engine or your vehicle may stall. Driving through deep water where the transmission vent tube is submerged may allow water into the transmission and cause internal transmission damage. Once through the water, always dry the brakes by moving your vehicle slowly while applying light pressure on the brake pedal.
Page 159: Roadside Emergencies
(60,000 km), whichever occurs first on Ford and Mercury vehicles, and four years or 50,000 miles (80,000 km) on Lincoln vehicles. Roadside assistance will cover: • a flat tire change with a good spare (except Ford GT which has a tire inflation kit) • battery jump start •...
Page 160 1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1–800–241–3673;...
Page 161: Fuel Pump Shut-Off Switch
Roadside Emergencies FUEL FUEL PUMP SHUT-OFF SWITCH RESET This device stops the electric fuel pump from sending fuel to the engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does not start, this switch may have been activated.
Page 162 Roadside Emergencies Standard fuse amperage rating and color Fuse Mini Standard rating fuses fuses Grey Grey Violet Violet Pink Pink 7.5A Brown Brown Blue Blue Yellow Yellow Natural Natural Green Green — — — — — — — — — —...
Page 163 The fuses are coded as follows: Fuse/Relay Fuse Amp Location Rating Mini relay — — 5A (coupe) (convertible) — — 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus) Roadside Emergencies Passenger Compartment Fuse Panel Description Accessory delay #1 Not used Wiper power Power mirrors Not used...
Page 164 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Do not probe the contacts for the fuses and relays in the power distribution box as damage will occur, causing improper, or loss of, electrical functionality.
Page 165 The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating — 30A* 40A* 30A* 30A* 30A* 30A* 40A* 30A* 30A* 30A* 30A* 40A* 30A* 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus) Roadside Emergencies Power Distribution Box Description Not used Climate control blower...
Page 166 Roadside Emergencies Fuse/Relay Fuse Amp Location Rating — 30A* Mini relay Micro relay Mini relay Micro relay Micro relay Mini relay Mini relay Micro relay Mini relay Mini relay Micro relay Mini relay Mini relay Mini relay Micro relay — —...
Page 167 Fuse/Relay Fuse Amp Location Rating 15A** 15A** 10A** 30A** Diode 10A** — 20A** 20A** 15A** 30A** — 20A** 20A** 30A** 20A** 30A** — 30A** 20A** * Cartridge Fuses ** Mini Fuses Auxiliary relay There is a relay located on the accelerator pedal assembly for the PCM delay.
Page 168 Ford. If the dissimilar spare tire or wheel is damaged, it should be replaced rather than repaired.
Page 169 Roadside Emergencies Use of one of the dissimilar spare tires listed above at any one wheel location can lead to impairment of the following: • Handling, stability and braking performance • Comfort and noise • Ground clearance and parking at curbs •...
Page 170 Roadside Emergencies How to change a flat tire To help prevent the vehicle from moving when you change a tire, be sure the parking brake is set, then block (in both directions) the wheel that is diagonally opposite (other side and end of the vehicle) to the tire being changed.
Page 171 Roadside Emergencies 2. Remove the lug wrench, spare tire and jack. 3. Remove the center ornament (if equipped) from the wheel. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
Page 172: Lug Nut Torque
Roadside Emergencies Never use the rear differential as a jacking point. To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack.
Page 173: Jump Starting
20 * Torque specifications are for nut and bolt threads free of dirt and rust. Use only Ford recommended replacement fasteners. When a wheel is installed, always remove any corrosion, dirt or foreign materials present on the mounting surfaces of the wheel or the surface of the wheel hub, brake drum or brake disc that contacts the wheel.
Page 174 Roadside Emergencies 3. Park the booster vehicle close to the hood of the disabled vehicle making sure the two vehicles do not touch. Set the parking brake on both vehicles and stay clear of the engine cooling fan and other moving parts.
Page 175 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 176 Roadside Emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 177 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 178: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift and dollies or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the front using wheel lift equipment, it is recommended that the rear wheels (drive wheels) be placed on a dolly to prevent damage to the transmission.
Page 179: Customer Assistance
Center at 1-800-392-3673 (FORD). Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 180 If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the authorized dealer could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealer to help you.
Page 181 Customer Assistance In some states (in the U.S.) you must directly notify Ford in writing before pursuing remedies under your state’s warranty laws. Ford is also allowed a final repair attempt in some states. In the United States, a warranty dispute must be submitted to the BBB...
Page 182 You are not bound by the decision but may choose to accept it. If you choose to accept the BBB AUTO LINE decision then Ford must abide by the accepted decision as well. If the arbitrator has decided in...
Page 183 United States and Canada, provided by a network of more than 4,600 participating authorized dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this...
Page 184 The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 185: Reporting Safety Defects (U.s. Only)
Obtaining a French owner’s guide French Owner’s Guides can be obtained from your authorized dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. REPORTING SAFETY DEFECTS (U.S. ONLY)
Page 186: Cleaning
Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral pH shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your authorized dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 187 WAXING Applying Motorcraft Paint Sealant (ZC-45) to your vehicle every six months will assist in reducing minor scratches and paint damage. • Wash the vehicle first. • Do not use waxes that contain abrasives; use Motorcraft Premium Liquid Wax (ZC-53-A), which is available from your authorized dealer, or an equivalent quality product.
Page 188 Cleaning ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal. When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage.
Page 189 • 4.6L 3V SOHC V8 engine • Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. PLASTIC (NON-PAINTED) EXTERIOR PARTS Use only approved products to clean plastic parts. These products are available from your authorized dealer.
Page 190 Cleaning • The wiper blades can be cleaned with isopropyl (rubbing) alcohol or Motorcraft Premium Windshield Washer Concentrate (ZC-32–A), available from your authorized dealer. This washer fluid contains special solution in addition to alcohol which helps to remove the hot wax deposited on the wiper blade and windshield from automated car wash facilities.
Page 191 INTERIOR For fabric, carpets, cloth seats, safety belts and seats equipped with side airbags: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Motorcraft Professional Strength Carpet & Upholstery Cleaner (ZC-54). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 192 Cleaning FORD AND LINCOLN MERCURY CAR CARE PRODUCTS Your Ford or Lincoln Mercury authorized dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 193: Maintenance And Specifications
Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide scheduled maintenance information which makes tracking routine service easy. If your vehicle requires professional service, your authorized dealer can provide the necessary parts and service.
Page 194 Maintenance and Specifications 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral). 2. Block the wheels. Note: Do not start your engine with the air cleaner removed and do not remove it while the engine is running.
Page 195: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.0L SOHC V6 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Engine coolant reservoir 8.
Page 196 Maintenance and Specifications 4.6L 3V SOHC V8 engine 1. Battery 2. Engine oil filler cap 3. Engine oil dipstick 4. Brake fluid reservoir 5. Air filter assembly 6. Power steering fluid reservoir 7. Engine coolant reservoir 8. Windshield washer fluid reservoir 9.
Page 197 In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Do not use any special washer fluid such as windshield water repellent type fluid or bug wash. They may cause squeaking, chatter noise, streaking and smearing.
Page 198: Engine Oil
Maintenance and Specifications CHANGING THE WIPER BLADES 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 199 Maintenance and Specifications • 4.0L V6 engine • 4.6L 3V V8 engine 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the lower and upper holes, the oil level is acceptable.
Page 200 Maintenance and Specifications • 4.0L V6 engine • 4.6L 3V SOHC V8 engine • Oil levels above the upper hole may cause engine damage. Some oil must be removed from the engine by an authorized dealer. 7. Put the indicator back in and ensure it is fully seated. 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 201 Approval Committee (ILSAC), comprised of U.S. and Japanese automobile manufacturers. To protect your engine’s warranty use Motorcraft SAE 5W-20 or an equivalent 5W-20 oil meeting Ford specification WSS-M2C930-A. SAE 5W-20 oil provides optimum fuel economy and durability performance meeting all requirements for your vehicle’s engine.
Page 202 Change your engine oil according to the appropriate schedule listed in the scheduled maintenance information. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 203: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to scheduled maintenance information for the service interval schedules.
Page 204 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 205: Engine Coolant
Maintenance and Specifications will not affect function or durability of the transmission. Over time the adaptive learning process will fully update transmission operation to its optimum shift feel. If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected.
Page 206 Maintenance and Specifications When the engine is cold, check the level of the engine coolant in the reservoir. • The engine coolant should be at the “FULL COLD” level or within the “COLD FILL RANGE” as listed on the engine coolant reservoir (depending upon application).
Page 207 Motorcraft Premium Gold Engine Coolant from yellow to golden tan. • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Specialty Orange Engine Coolant, meeting Ford specification WSS-M97B44-D, with the factory-filled coolant. Mixing Motorcraft Specialty Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection.
Page 208 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 209 Maintenance and Specifications Used engine coolant should be disposed of in an appropriate manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in this section.
Page 210 Maintenance and Specifications What you should know about fail-safe cooling (4.6L V8 engine only) If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred. The “fail-safe” distance depends on ambient temperatures, vehicle load and terrain.
Page 211 Maintenance and Specifications 4. Check the coolant level and replenish if low. Never remove the coolant reservoir cap while the engine is running or hot. 5. Restart the engine and take your vehicle to an authorized dealer. Driving the vehicle without repairing the engine problem increases the chance of engine damage.
Page 212 Maintenance and Specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before refueling your vehicle. • Always turn off the vehicle before refueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 213 Maintenance and Specifications Refueling Fuel vapor burns violently and a fuel fire can cause severe injuries. To help avoid injuries to you and others: • Read and follow all the instructions on the pump island; • Turn off your engine when you are refueling; •...
Page 214 Maintenance and Specifications be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 215 Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse effect on powertrain components.
Page 216 Maintenance and Specifications • The indicator may come on. For more information on the “check engine” or the “service engine soon” indicator, refer to Warning lights and chimes in the Instrument Cluster chapter. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
Page 217 Maintenance and Specifications Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1. Fill the fuel tank completely and record the initial odometer reading (in miles or kilometers). 2. Each time you fill the tank, record the amount of fuel added (in gallons or liters).
Page 218 Maintenance and Specifications • Using the air conditioner or defroster may reduce fuel economy. • You may want to turn off the speed control in hilly terrain if unnecessary shifting between third and fourth gear occurs. Unnecessary shifting of this type could result in reduced fuel economy.
Page 219 If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 220 Maintenance and Specifications Exhaust leaks may result in entry of harmful and potentially lethal fumes into the passenger compartment. Do not make any unauthorized changes to your vehicle or engine. By law, vehicle owners and anyone who manufactures, repairs, services, sells, leases, trades vehicles, or supervises a fleet of vehicles are not permitted to intentionally remove an emission control device or prevent it from working.
Page 221 Maintenance and Specifications description in the Warning lights and chimes section of the Instrument Cluster chapter. Your vehicle may not pass the I/M test with indicator on. If the vehicle’s powertrain system or its battery has just been serviced, the on-board diagnostics system is reset to a “not ready for I/M test” condition.
Page 222 Maintenance and Specifications BRAKE/CLUTCH FLUID Brake and clutch systems are supplied from the same reservoir. The fluid level will drop slowly as the brakes wear, and will rise when the brake components are replaced. Fluid levels between the “MIN” and “MAX”...
Page 223 Maintenance and Specifications Checking and adding manual transmission fluid (if equipped) 1. Clean the filler plug. 2. Remove the filler plug and inspect the fluid level. 3. Note: There are two different manual transmissions used in this vehicle and they have different fluid levels. For vehicles equipped with a V6 engine the correct manual transmission fill level is at the lower edge of the filler hole.
Page 224 4. Add enough fluid through the filler opening to bring the fluid up to the recommended levels. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant specifications in this chapter. 2006 05+ Mustang (197)
Page 225: Part Numbers
PCV valve. Replace the PCV valve with one that meets Ford material and design specifications for your vehicle, such as a Motorcraft or equivalent replacement part. The customer warranty may be void for any damage to the emissions system if such a PCV valve is not used.
Page 226: Refill Capacities
Maintenance and Specifications REFILL CAPACITIES Fluid Ford Part Name Brake fluid and Motorcraft High (clutch fluid if Performance equipped) DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft SAE (includes filter 5W-20 Premium change) Synthetic Blend Motor Oil (US) Motorcraft SAE...
Page 227 Fill 1/4 inch to 9/16 inch (6 mm to 14 mm) below bottom of fill hole. Add 4 oz. (118 ml) of Additive Friction Modifier XL–3 or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles.
Page 228: Lubricant Specifications
Maintenance and Specifications Use of synthetic or synthetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C929-A (4.0L) or WSS-M2C930-A (4.6L) and the API Certification mark. LUBRICANT SPECIFICATIONS Ford part Item name...
Page 229 Maintenance and Specifications Ford part Item name Motorcraft SAE 5W-20 Premium Synthetic Blend Engine oil Motor Oil (US) (4.6L engine) Motorcraft SAE 5W-20 Super Premium Motor Oil (Canada) Motorcraft SAE 5W-30 Premium Synthetic Blend Engine oil Motor Oil (US) (4.0L V6 engine)
Page 230 Ford specification EST-M2C118-A for complete refill of Traction-Lok axles. Ford design rear axles contain a synthetic lubricant that does not require changing unless the axle has been submerged in water. Ensure the correct automatic transmission fluid is used. MERCON and MERCON V are not interchangeable.
Page 231 Maintenance and Specifications VEHICLE DIMENSIONS Vehicle dimensions Base - inches (mm) GT - inches (mm) (1) Vehicle height 55.4 (1408) (2) Tread Width- Front 62.8 (1594) (2) Tread Width- Rear 63.0 (1600) (3) Vehicle width 73.9 (1877) (4) Wheelbase 107.1 (2720) (5) Overall length 187.6 (4765) 2006 05+ Mustang (197)
Page 232 Maintenance and Specifications IDENTIFYING YOUR VEHICLE Safety Compliance Certification Label The National Highway Traffic Safety Administration Regulations require that a Safety Compliance Certification Label be affixed to a vehicle and prescribe where the Safety Compliance Certification Label may be located. The Safety Compliance Certification Label is located on the structure by the trailing edge of the driver’s door or...
Page 233 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. Please note that in the graphic, XXXX is representative of your vehicle identification number. The Vehicle Identification Number (VIN) contains the following information: 1.
Page 234 Maintenance and Specifications TRANSMISSION/TRANSAXLE CODE DESIGNATIONS You can find a transmission/transaxle code on the Safety Compliance Certification Label. The following table tells you which transmission or transaxle each code represents. Description Five-speed manual (T5) Five-speed manual (TR3650) Five-speed automatic (5R55S) 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus)
Page 235: Accessories
GENUINE FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Genuine Ford Accessories are available for your vehicle through your local Ford or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 236 Accessories Lifestyle Bike racks Cargo organization and management Peace of mind First aid and highway safety kits Full vehicle covers Locking gas cap Keyless entry keypad Remote start Vehicle security systems Mobile-ease hands-free communication system Wheel locks For maximum vehicle performance, keep the following information in mind when adding accessories or equipment to your vehicle: •...
Page 237: Index
Accessory delay ...44 Air cleaner filter ...225 Airbag supplemental restraint system ...94–95, 102 and child safety seats ...96 description ...95, 102 disposal ...105 driver airbag ...97, 103 indicator light ...105 operation ...97, 103 passenger airbag ...97, 103 side airbag ...102 Antifreeze (see Engine coolant) ...205 Anti-lock brake system...
Page 238 ...205 refill capacities ...209, 226 specifications ...228, 230 Cruise control (see Speed control) ...46 Customer Assistance ...159 Ford Extended Service Plan ...183 Getting assistance outside the U.S. and Canada ...184 Getting roadside assistance ...159 Getting the service you need ...179...
Page 239 Fluid capacities ...226 Foglamps ...32 Fuel ...211 calculating fuel economy ...57, 216 cap ...213 capacity ...226 choosing the right fuel ...214 comparisons with EPA fuel economy estimates ...219 detergent in fuel ...215 filling your vehicle with fuel ...211, 213, 216 filter, specifications ...211, 225 fuel pump shut-off switch ...161 improving fuel economy ...216...
Page 240 Index daytime running light ...33 fog lamps ...32 headlamps ...32 headlamps, flash to pass ...33 instrument panel, dimming ...33 interior lamps ...35 replacing bulbs ...36 Lane change indicator (see Turn signal) ...35 Lights, warning and indicator ...10 anti-lock brakes (ABS) ...148 Limited slip axle (see Traction Loc) ...151 Load limits ...133...
Page 241 Safety belts (see Safety restraints) ...80, 83–84, 86–87 Safety defects, reporting ...185 Safety restraints ..80, 83–84, 86–88 belt minder ...90 extension assembly ...88 for adults ...84, 86–87 for children ...105 Occupant Classification Sensor ...81 safety belt maintenance ...89 warning light and chime ...89–90 Safety seats for children ...109 Safety Compliance Certification Label ...232...
Page 242 Index Vehicle Identification Number (VIN) ...233 Vehicle loading ...133 Ventilating your vehicle ...147 Warning lights (see Lights) ...10 Washer fluid ...197 2006 05+ Mustang (197) Owners Guide (post-2002-fmt) USA (fus) Water, Driving through ...157 Windows power ...43 Windshield washer fluid and wipers checking and adding fluid ...197 operation ...41...
