Reversing The Door Swing Of Your Appliance - Apelson UBWC300B Instruction Manual

Reversing the Door Swing
of Your Appliance
Should you desire to reverse the opening direction,
please follow the instructions below.
Figure 1
Figure 3
① Lock Screws
② Right Lower Hinge
③ Door Shaft Assembly
④ Right Top Hinge
Note: All parts removed must be
saved to do the reinstallation of door.
1. Open the glass door and remove the two
screws under the right bottom corner of the
glass door that are used to hold the right lower
hinge to the door shaft assembly. Be careful to
support the glass door with hands to prevent it
dropping after removing the screws. (Figure 1)
2. Pull down to remove the glass door and place
it on a padded surface to prevent scratching it.
(Figure 2)
3. Remove the right top hinge and right lower
Figure 2
Figure 4
⑤ Door
⑥ Cabinet
⑦ Left Top Hinge
⑧ Left Lower Hinge
hinge. (Figure 3). Remove the left top hinge
and left lower hinge from the plastic bag that
includes the instruction manual then install
them at the designated positions at the left
side of cabinet. (Figure 4)
4. Turn around the glass door 180° and reinstall
it.
8
