oticon Delta 4000 Manual To Fitting And Operation

Hide thumbs
Table of Contents

Advertisement

Quick Links

Delta Success Manual
The Complete Guide to
Delta Fitting and Operations

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Delta 4000 and is the answer not in the manual?

Questions and answers

Related Manuals for oticon Delta 4000

Summary of Contents for oticon Delta 4000

  • Page 1 Delta Success Manual The Complete Guide to Delta Fitting and Operations...

  • Page 2: Table Of Contents

    Table of Contents Introduction Ear Pieces Working with Delta Selecting the dome Choosing the correct dome size Choosing Delta Changing the dome Micro Mold Fitting Delta Attaching the Micro Mold Taking off the Micro Mold Selecting the speaker unit length Attaching the speaker unit Fitting Delta in Genie Replacing the speaker unit...
  • Page 3 Changing dome in Genie during fi tting Overview Changing rationale during fi tting Main device elements End Session Amplifi er unit details Fine tuning Speaker unit details Tools Delta Colors How to change...? Shell color guide Where do I fi nd...? Changing the shell Same-day Instant Fit Instructions to the User...

  • Page 4: Introduction

    Delta and the many new possibilities it offers. fi tting strategy, you can now fi t Delta to any confi guration of hearing loss up to 80 dB HL. Furthermore, with the addition of the new lower priced Delta 4000, you now have 3 price options.

  • Page 5: Working With Delta

    Working with Delta Selecting and Changing Shell Color Choosing Delta Fitting Selecting the Speaker Unit Selecting the Ear Piece...

  • Page 6: Choosing Delta

    Advanced features for more value-conscious people who desire high-end performance, but are willing to trade-off some of the most sophisticated performance features for a lower price. Delta 4000 New Value Option. Attractive design at an attractive price. No need to sacrifi ce on style because of affordability. Standard...
  • Page 7 Delta 4000 Delta 6000 Delta 8000 Directionality Noise reduction Sound quality Fitting fl exibility Cosmetics...

  • Page 8: Fitting Delta

    Fitting Delta For the ideal cosmetic appearance and most comfortable fi t with Delta please consider the following: • Selection of correct speaker unit length • Selection of correct dome size • Correct insertion of speaker in the ear • Use of the ear grip, if necessary...

  • Page 9: Selecting The Speaker Unit Length

    Selecting Speaker Unit Length The speaker unit is available in four lengths and in The speaker should sit comfortably and hidden left/right versions. No. 1 is the shortest and no. 4 is in the ear canal. The wire should be fl ush with the longest.
  • Page 10 Use the measuring tool to select the correct speaker unit length. Place the measuring tool on the ear, as shown. Choose the length corresponding to the size-marking on the measuring tool at the top of the ear canal opening.

  • Page 11: Attaching The Speaker Unit

    Attaching the speaker unit Slide the speaker unit into the plug. Slide only in the direction of the plug. Do not force the speaker unit plug downward. When the plug is in place, give it a fi rm push.

  • Page 12: Replacing The Speaker Unit

    Replacing the speaker unit Gently pull off the speaker unit. Pull only in the direction of the plug. Do not pull upwards as this may damage the plug.

  • Page 13: Attaching The Ear Grip

    Attaching the ear grip The ear grip should be used to obtain a more secure retention in the ear canal. It is available in one version for both left and right ears. Insert the ear grip into the slot in the receiver. Important: Pull the ear grip through the slot until the top of the grip is positioned inside the slot and pointing away from the dome, as illustrated.

  • Page 14: Taking Off The Ear Grip

    Taking off the ear grip If the ear grip seems too long in the concha, you may cut/trim it to the desired length. Take care not to leave a sharp and pointy end when cutting as this can cause irritation in the ear.
  • Page 15 Use a fi nger nail to dislodge the ear grip from the slot then push it through from the other side.

  • Page 16: Inserting And Placing The Device On The Ear

    Inserting and placing the device on the ear 1. Insert the speaker with an attached dome/Micro The speaker unit with the dome/Micro Mold should Mold into the ear canal. be placed far enough into the ear so that the speaker wire lies fl...
  • Page 17 If the speaker unit is too long, the amplifi er will sit If the speaker unit is too short, it will be diffi cult too low behind the ear and the microphones will to achieve suffi cient depth in the ear canal and the point vertically instead of horizontally.

  • Page 18: Manipulating The Speaker Unit

    Manipulating the speaker unit • Use a hair dryer or hot air blower at low heat setting • Heat for a short time – a matter of seconds • Bend into desired shape and hold in place until wire is cooled off. •...
  • Page 19 “S” Curve • To add length to the speaker, straighten out, or elongate the S portion of the speaker wire. Bend into the Canal • Adjust this bend to stop the wire from bowing S-curve out from the side of the client’s ear, or to increase the depth of speaker insertion.

  • Page 21: Ear Pieces

    Ear Pieces Delta can fi t: New users Experienced users Mild hearing losses Moderate hearing losses All confi gurations of hearing loss up to 80 dB HL 3 price ranges Using: Micro Mold Plus dome Open dome...

  • Page 22: Selecting The Dome

    Selecting the dome Fitting range for domes Fitting range for Micro Mold dB HL dB HL Open dome Micro Mold 6 mm Custom fi t 8 mm 10 mm 125 Hz 250 1000 2000 4000 8000 125 Hz 250 1000 2000 4000 8000 Plus dome One size...
  • Page 23 The Open dome is available in three different sizes: The dome should sit comfortably in the ear canal 6 mm, 8 mm and 10 mm. The most commonly used and support and hold the speaker. Use an otoscope is the medium sized 8 mm dome. The Plus dome is to inspect client’s ear canal to determine dome size.

  • Page 24: Choosing The Correct Dome Size

    Choosing the correct dome size If the dome is too small, the speaker will not be securely positioned in the ear canal and it may also itch or tickle in the ear canal. If the dome is too big, it will be diffi cult to get insert deeply enough into the ear canal or it may collapse in the ear canal and be uncomfortable to wear.

  • Page 25: Changing The Dome

    Changing the dome Remove the old dome using your fi nger nails. Push the new dome onto the speaker. Give it a push to secure it safely.

  • Page 26: Micro Mold

    Micro Mold The Micro Mold is an acrylic custom solution that can be used instead of a dome. Micro Molds are produced from a traditional, deep impression. The adaptor clearly indicates R/L color marking. Up/Down Indicator WaxStop Adaptor...
  • Page 27 Micro Molds can be made with tube-shaped vents, Micro Molds can also be used and selected in Genie as in traditional ear molds, but the length is shorter for mild and moderate high frequency hearing than standard vents. Therefore, the Micro Mold losses, where open domes are prescribed.

  • Page 28: Attaching The Micro Mold

    Attaching the Micro Mold When fi tting Delta with Micro Molds follow the instructions below: 1. Find the correct speaker unit length and attach it to the amplifi er (see Selecting speaker unit length). 2. Carefully insert the receiver into the Micro Mold and click the Micro Mold into place.
  • Page 29 Note: Take care not to insert the speaker unit into the Micro Mold at an angle. Unless it is inserted correctly, the speaker will not lock into place. When placed correctly, you should hear the speaker snap into place with a “click”. Only a little pressure is required.

  • Page 31: Taking Off The Micro Mold

    Taking off the Micro Mold The Micro Mold should not be detached from the speaker without the Micro Mold tool. When detaching the Micro Mold follow the instructions below: 1. Remove the WaxStop. 2. Place the Micro Mold in the tool as illustrated making sure that the cross in the adaptor is aligned with the tap of the tool.

  • Page 32: Fitting Delta In Genie

    Fitting Delta in Genie When connecting Delta to Genie 8, the various prescriptions will be based on the hearing loss type: 1. Mild/moderate high frequency hearing loss 2. Moderate, severe low frequency hearing loss and conductive hearing loss. The prescriptions affect the •...

  • Page 33: Amplifi Cation Strategies

    Amplifi cation strategies Mild/moderate high frequency hearing losses: Genie prescribes the Clarity rationale. The Clarity rationale is focused in the high frequencies. The overall goal is to enhance speech clarity and improve intelligibility in noise. Moderate, severe low frequency hearing loss including conductive hearing losses: Genie prescribes the VAC rationale.

  • Page 34: Ear Pieces

    Ear pieces You can select disposable domes or customized dB HL Micro Molds when fi tting Delta. Open Dome 6 mm. Open dome and Plus dome 8 mm. 10 mm. When selecting domes, Genie prescribes Open dome or Plus dome based on the prescribed high frequency gain.
  • Page 35 dB HL Micro Mold Micro Mold custom fi t When you select Micro Mold, Genie prescribes the vent size based on the prescribed high frequency gain. Micro Molds allow you to fi t broadband hearing losses within the illustrated fi tting range. 125 Hz 250 1000 2000 4000 8000...

  • Page 37: Fitting Fl Ow

    Fitting fl ow Connect to Genie • The Delta devices are programmed with a standard Oticon #3 cable and a FlexConnect strip.

  • Page 38: Selection

    Selection Detect the instrument • Select Delta 8000, 6000 or 4000 or click Detect Instruments in the Genie selection step.
  • Page 39 • Select the ear piece: Dome or Micro Mold. In • Go to Fitting and you will be prompted to verify the audiogram you will see the fi tting range the Dome/Micro Mold vent size. associated with the two types of ear pieces. •...

  • Page 40: Fitting

    Fitting Connection • The instrument will automatically be connected if you have pressed Detect Instruments in the Selection. Otherwise, press Connection icon.

  • Page 41: Verifying The Setting

    Verifying the setting Set the Adaptation Manager • Step 1: new users • Step 2: semi-experienced and experienced users • Step 3: experienced users • Verify the prescribed setting, for example by using the various built-in sounds and sound environments in Genie.

  • Page 42: Changing The Rationale And Dome Size

    Changing the rationale and dome size You can change the rationale during the fi tting fl ow Suggested solutions: according to client preferences. 1. Change to VAC Rationale in Confi guration in Selection step. Example 1 2. On the Delta speakers: if Genie prescribes the Plus dome, then change the •...
  • Page 43 Suggested solutions: Example 2 1. Change to Clarity rationale in Confi guration in • New user with 35-50 dB HL Broadband hearing Selection step loss. Dome is selected by Genie. 2. If Genie prescribes an Open dome, then change the •...

  • Page 44: Changing Dome In Genie During Fi Tting

    Changing dome in Genie during fi tting Confi guration Dome Options • Open the drop-down in Acoustics and click on • Open the drop-down list and click on the the selected dome type. selected dome type.

  • Page 45: Changing Rationale During Fi Tting

    Changing the rationale during fi tting • You can change the rationale in either • Click on the plus signs to unfold the program Confi guration in the Selection step or Program menu. Manager in the Fitting step. • When you change rationale in Confi guration, Confi...
  • Page 46 Program Manager • Click on the plus signs to expand the program menu.

  • Page 47: End Session

    End Session • This step shows the status of parameters and • Click ‘Save, Program and Exit’ and detach the audiological tools used during the fi tting. instruments.

  • Page 49: Fine Tuning

    Fine tuning Fine tuning of gain controls is usually not • Use Genie Help to learn more about the Fine recommended during the initial fi tting. Tuning Guide. • The tools in this step address concerns that may arise at the initial fi tting, or at subsequent sessions.

  • Page 51: Delta Colors

    Delta Colors Delta Presentation Case...

  • Page 52: Shell Color Guide

    Combine as You Like Shell color guide SPINE COLORS Delta is available in 17 different shell colors and 4 different spine colors. The shell is interchangeable in your clinic, giving you a huge range of options to satisfy the personal preferences of your clients. Use Dark Grey Spine the presentation display with all the different colors to engage your clients in something that they fi...
  • Page 53 SHELL COLORS Check Chocolate Brown Deep Purple Champagne Beige Cabernet Red Wildlife Shy Violet Samoa Blue Wall Street Charcoal Grey Sunset Orange Diamond Black Racing Green Mother of Pearl Green Chameleon High-tech Silver Midnight Blue...

  • Page 54: Changing The Shell

    Changing the shell 7. Leave the whole amplifi er on the shell change Shell tool. Do not touch the inside of the amplifi er. Use the shell change tool and the shell change 8. Throw away the removed shell. A removed fi...

  • Page 56: Same-Day Instant Fit

    Same-day Instant Fit One-stop fi tting enables many of your clients to receive an immediate, cosmetic, and comfortable solution on “day one”. The Delta Warehouse gives you all you need to customize the fi tting. It comes fully equipped with a variety of domes, speaker units, and a broad choice of shell colors.

  • Page 58: Instructions To The User

    Instructions to the User ✓ Prepare your client with a few practical instructions How to change the battery before using Delta: ✓ ✓ To remove the device before showering, How to place the device on and in the ear ✓ bathing or swimming ✓...
  • Page 59 Maintenance – take good care of your Delta ✓ Change the dome/WaxStop when needed ✓ Inspect the NoWax ✓ Gently wipe the speaker with a dry cloth Do not: ✗ Try to wash the amplifi er ✗ Use the device without a dome ✗...

  • Page 60: Faq

    1. How often should the Dome be 2. How frequently should the WaxStop changed? in the Micro Mold be changed? The dome should be replaced whenever needed. The WaxStop should be changed whenever needed. For most users, this will be once every one or two For most users, this will be once a month or if there months.
  • Page 61 4. What is the difference between the 6. Can I change the shell colors in two wax fi lter systems for Micro Mold my offi ce? clients? If you follow the shell change instruction in this guide, there is no risk when changing the shells. NoWax fi...
  • Page 62 8. What if the dome comes off in the ear canal? Gently take it out, if possible by help of a spouse or relative. The dome is made of a soft, medically approved material, which is not harmful in any way. However, to prevent this situation, remember to change domes frequently, as their natural elasticity will disappear over time.

  • Page 64: Overview

    Overview On the next pages you will fi nd an overview of the different elements of Delta.

  • Page 65: Main Device Elements

    Main device elements Amplifi er Unit Dome Speaker Unit...

  • Page 66: Amplifi Er Unit Details

    Amplifi er unit details Wind Filter Battery Door Plug for Speaker Unit Shell...

  • Page 67: Speaker Unit Details

    Speaker unit details Plug Dome with integrated wax protection Wire Left/Right indicator NoWax Speaker Ear Grip...

  • Page 68: Tools

    Tools Shell Change Tool Measuring Tool Shell Change Fixture Micro Mold Tool...

  • Page 69: How To Change

    How to change...? Battery Door Wind Filter Attach the shell change tool to the battery door and Use a fi nger nail to remove the wind fi lter. Click on push the tool forward to remove it. Click on a new a new wind fi...

  • Page 70: Where Do I Fi Nd

    Where do I fi nd…? 2. Written from the chip in Genie’s End Session Serial Number and Model 1. Marked on Delta 3. On the outer packing 4. On the plastic bag containing the Amplifi er Remove the wind fi lter...
  • Page 71 Speaker Unit L/R-Marking Speaker Unit Size The receiver has a small blue/red band to indicate The length of the speaker unit (1, 2, 3 or 4) is which ear the device is programmed for. indicated on the receiver.
  • Page 73 People fi rst We believe that it takes more than technology and audiology to create the best hearing instruments. That’s why we put the individual needs and wishes of people with hearing loss fi rst in our development of new hearing care solutions.
